Programmer's Guide, cont'd
Space
Figure 5-1 — ASCII-to-hexadecimal conversion table
COMMAND ASCII
Left Edge Size
Left edge size right
Left edge size left
Top Edge Size
Top edge size down
Top edge size up
Right Edge Size
Right edge size right
Right edge size left
Bottom Edge Size
Bottom edge size down
Bottom edge size up
Top Blanking
Specific value
Increment up
Decrement down
Bottom Blanking
Specific value
Increment up
Decrement down
Left Blanking
Specific value
Increment up
Decrement down
Right Blanking
Specific value
Increment up
Decrement down
5-4 MVP 104GX Programmer's Guide
ASCII to HEX Conversion Table

COMMAND/RESPONSE TABLE

RESPONSE
+H Hph
–H Hph
+/ Vph
–/ Vph
+: Hsz
–: Hsz
+; Vsz
–; Vsz
* =T Blt
+=T Blt
–=T Blt
* =B Blb
+=B Blb
–=B Blb
* =L Bll
+=L Bll
–=L Bll
* =R Blr
+=R Blr
–=R Blr
DESCRIPTION
Size left edge of input image to the right
Size left edge of input image to the left
Size top edge of input image down
Size top edge of input image up
Size right edge of input
Size right edge of input
Size bottom edge of input
Size bottom edge input
Sets input top blanking to
Increment input top blanking one step
Decrement input top blanking one step
Sets input bottom blanking to
Increment input bottom blanking one step
Decrement input bottom blanking one step
Sets input left blanking to
Increment input left blanking one step
Decrement input left blanking one step
Sets input right blanking to
Increment input right blanking one step
Decrement input right blanking one step
image to the right
image to the left
image down
image up
