HP StorageWorks 1510i - Modular Smart Array User Manual page 66

d.
Expand the drop-down boxes and enter the following settings:
• Local adapter: Microsoft iSCSI Initiator
• Source IP: Enter the IP address of the NIC that has access to the target portal that you
want to connect to (and will enter in the next step).
• Target Portal: Select the destination target portal you want to connect to.
(Example: 100.10.1.20:3260)
IMPORTANT:
Several Target Portal IP addresses may be presented. Be sure that the Source IP address
and the corresponding Target Portal have a viable path. The ping command can be
used to verify that the path is accessible.
e. Click OK.
The Targets tab is updated and redisplayed.
66
Configuration
