On the bottom of each Receiver unit, there are four (4) DIP switches. Each DIP
switch performs a different function.
Before modifying DIP switch settings, disconnect the power from the Receiver
unit. After the DIP switches have been confi gured, reconnect the power.
DIP SWITCH CONFIGURATION
DIP Switch Location
(Matrix Mode / Stand-alone Mode)
Receiver Unit (bottom)
DIP Switch
Bank
Default settings for DIP switches
DIP Switch
1
2
3
4
NOTE: By default, all DIP
switches are set to the OFF
position.
Position
OFF
OFF
OFF
OFF
18
