To use the RMT-4-IR Remote, remove the battery cover on the back of the
remote to reveal the battery compartment. Insert the included battery into the
open battery slot. The positive (+) side should be facing up. Ensure that both
DIP switches are set to the OFF position. Replace the battery cover and the IR
Remote is ready for action.
The IR Remote ships with 2 batteries. One battery is required for operation and
the other battery is a spare.
RMT-4-IR REMOTE INSTALLATION
Installing the RMT-4-IR Battery
Battery Slot
I/R Code DIP Switches
9
