- Page 4 CONTENTS Introduction Operation Notes Features Sender Panel Layout Sender Panel Descriptions Receiver Panel Layout Receiver Panel Descriptions Connecting And Operating The Extender DIP Switch Confi guration 11 Network Cable Wiring Diagram 12 Specifi cations 13 Warranty...
-
Page 6: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE EXTENDER FOR HDMI 1.3 OVER ONE CAT6 • The Extender for HDMI 1.3 over one CAT6 was designed for use with high quality CAT-6a (augmented) cabling. This unit will either not perform to specifi... -
Page 12: Connecting And Operating The Extender
CONNECTING AND OPERATING THE EXTENDER How to Connect the Extender for HDMI 1.3 over one CAT6 Connect a HDMI cable (one is supplied) between the HDMI output on a HDMI source device and the HDMI input on the Extender for HDMI 1.3 over one CAT6 Sender unit. -
Page 14: Dip Switch Configuration
DIP SWITCH CONFIGURATION DIP SWITCH CONFIGURATION – EDID Under normal circumstances, a source device (digital and analog) will require information about a connected device/display to assess what resolutions and features are available. The source can then cater its output to send only resolutions and features that are compatible with the attached device/display. -
Page 16: Specifications
SPECIFICATIONS Video Amplifi er Bandwidth ............... 225 MHz Single Link Max. Resolution .......1920x1200 and 1080p/60, 12 bit color Input DDC Signal ................5V p-p (TTL) Input Video Signal ..................1.2V p-p HDMI Connector ..............Type A, 19 Pin Female Link Connector ................RJ-45 Shielded Power Supply ....................
