ZEUS Technical Manual
GPIO
No AF Signal name Dir
52 0 MMC_WP
53 0 MMC_CD
54 2 CB_PCE2#
55 2
CB_PREG#
56 1 CB_WAIT#
57 1
CB_PIOIS16#
58 2 LCD_D0
59 2 LCD_D1
60 2 LCD_D2
61 2 LCD_D3
62 2 LCD_D4
63 2 LCD_D5
64 2 LCD_D6
65 2 LCD_D7
66 2 LCD_D8
67 2 LCD_D9
68 2 LCD_D10
69 2 LCD_D11
70 2 LCD_D12
71 2 LCD_D13
72 2 LCD_D14
73 2 LCD_D15
74 2 LCD_FCLK
75 2 LCD_LCLK
76 2 LCD_PCLK
77 2 LCD_BIAS
© 2007 Eurotech Ltd Issue D
Active Function
Input
Low SDIO Write Protect Status
SDIO Card Detect IRQ
Input
Output Low Card Bus High Byte Enable
Card Bus Register Space
Output Low
Select
Input
Low Card Bus WAIT#
Low Card Bus IOIS16#
Input
Output NA LCD Data Bit 0
Output NA LCD Data Bit 1
Output NA LCD Data Bit 2
Output NA LCD Data Bit 3
Output NA LCD Data Bit 4
Output NA LCD Data Bit 5
Output NA LCD Data Bit 6
Output NA LCD Data Bit 7
Output NA LCD Data Bit 8
NA LCD Data Bit 9
Output
NA LCD Data Bit 10
Output
Output
NA LCD Data Bit 11
Output
NA LCD Data Bit 12
Output
NA LCD Data Bit 13
Output
NA LCD Data Bit 14
Output
NA LCD Data Bit 15
LCD Frame Clock (STN) /
Output NA
Vertical Sync (TFT)
LCD Line Clock (STN) /
Output NA
Horizontal Sync (TFT)
LCD Pixel Clock (STN) /
Output NA
Clock (TFT)
LCD Bias (STN) / Data
Output NA
Enable (TFT)
Detailed hardware description
Wake-up
source See section...
SDIO, page 39
Expansion interfaces,
page 38
Flat panel display,
page 44
continued...
25
