MODE DISPLAY
• It displays the operating mode.
TEMP./TIMER DISPLAY
• It displays the temperature and the timer.
FAN SPEED
• Everytime you push this button, It is selected as
follow. (High Mid Low High)
AUTO SWING
• Everytime you push this button, the auto swing mode is toggled.
MODE SELECT
• Everytime you push this button, It is selected as
follow. (Cooling Turbo Fan Cooling)
REMOTE SIGNAL RECEIVER
Room Air-conditioner
Fan Room temp
Turbo Desired temp
Cooling Timer
MODE FAN SPEED AUTO SWING
TEMPERATURE SET
• It is the button to set the desired
room temperature.
The temperature can be set
within a range from 16°C (60°F)
to 32°C (90°F) by 1°C (1°F)
SENSOR
TEMP
POWER
POWER ON/OFF SWITCH
• To turn the unit ON, push this button.
To turn the unit OFF, push this button
again.
7
