Remote Controller - Daewoo DWC-121R Service Manual

2

REMOTE CONTROLLER

TIMER/CANCEL
• Everytime you push this button,
timer is set as follow.
(1Hr 2Hr 3Hr 4Hr 5Hr 6Hr 8
Hr 10Hr 12Hr 16Hr 20Hr 24Hr
CANCEL).
After the unit is timed, if this button is
pushed, timer is canceled.
FAN SPEED
• Everytime you push this button,
it is selected as follow.
(High Mid Low High)
TEMPERATURE
• It is the button to set the room in
the desired room temp.
The temp can be set within a
range from 16°C (60°F) to 32°C
(90°F) by 1°C (1°F)
POWER ON/OFF
• To turn the unit ON, push this
button. To turn the unit OFF,
push this button, again.
REMOCON SIGNAL TRANSMITTER
TIMER/
CANCEL SLEEP
AUTO
SWING
FAN SPEED
TEMP
5
SLEEP
• SLEEP mode is selected as
follow. (L1 L2 Cancel)
MODE
MODE
• Everytime you push this button,
it is selected as follow.
(COOLING TURBO FAN
COOLING)
AUTO SWING
• Everytime you push this button,
the auto swing mode is toggled.
