Daewoo DWC-121R Service Manual page 36

NO CODE
40 3104302300 PCB MAIN AS
41 3104302400 PCB FRONT AS
5EPU04000 TRANSFORMER
42 5EPU04100 TRANSFORMER
5EPN04300 TRANSFORMER
3101300300 POWER CORD
43 3103001600 POWER CORD
3101300600 POWER CORD
3109503100 CAPACITOR
3109503110 CAPACITOR
3109503200 CAPACITOR
3109503210 CAPACITOR
3109505100 CAPACITOR
44 3109505110 CAPACITOR
3109507700 CAPACITOR
3109507710 CAPACITOR
3109507000 CAPACITOR
3109507010 CAPACITOR
3109503410 CAPACITOR
45 3101201600 CLAMP CAPACITOR
3108004800 MOTOR SWING
46 3108009700 MOTOR SWING
47 3100508510 BOX CONTROL
48 3106600500 SCROLL UPPER
49 3103002800 HOLDER SCROLL
50 3104409300 PIPE RUBBER BUTYL
3102707500 HANESS COMP AS
51 3102708801 HANESS COMP AS
52 3103200500 CAP DRAIN
53 3102708500 HARNESS DISPLAY 1
54 3102708600 HARNESS DISPLAY 2
55 3101404200 COVER ORIFICE
NOTE: A or B or C
COMPONENTS Q'TY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
SPECIFICATION
–
–
DWA-220B(115V/60Hz)
DWA-230A(220V/60Hz)
DWA-230V(230V/50Hz)
KKP-30B,13A 125V
WS-001I 250V 13A
KKP-4819R 250V 10A
12/40µF,370VAC
12/40µF,370VAC
5/25µF,370VAC
5/25µF,370VAC
5/35µF,400VAC
5/35µF,400VAC
5/35µF,400VAC
5/35µF,400VAC
5/30µF,400VAC
5/30µF,400VAC
4/25µF,370VAC
SGCC T0.8
120VAC 60HZ
200/220V 50/60HZ
SGCC T0.8
EPS
SGCC
UL1015-14,BLK,RED,WHT
UL1015-16,BLK,RED,WHT
ABS
UL1007-22(8COLOR)
UL1007-22(10COLOR)
PP(H-540)
35
REMARK
DWC-121R,124R(ONLY)
DWA-121R,122R,124R,150R,151R,152R(ONLY)
DWB-121R,DWB-122R,123R,124R(ONLY)
DWC-121R,124R(ONLY)
DWA-121R,122R,124R,150R,151R,152R(ONLY)
DWB-121R,DWB-122R,123R,124R(ONLY)
DWC-121R,124R(ONLY)
DWC-121R,124R(ONLY)
DWA-121R,DWA-122R,124R(ONLY)
DWA-121R,DWA-122R,124R(ONLY)
DWB-121R,123R(ONLY)
DWB-121R,123R(ONLY)
DWB-121R,123R(ONLY)
DWB-121R,123R(ONLY)
DWB-122R,124R(ONLY)
DWB-122R,124R(ONLY)
DWA-150R,151R,152R(ONLY)
DWC-121R,124R(ONLY)
DWA-121R,122R,124R,150R,151R,152R
DWB-121R,122R,123R,124R(ONLY)
DWC-121R,124R(ONLY)
DWA-121R,122R,124R,150R,151R,152R
DWB-121R,122R,123R,124R(ONLY)
