PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER
Please observe the following instructions.
1. Operate the Selector Switch to run or stop the unit.
- Do not use Main Power Switch or Auxiliary Power Switch to operate unit.
2. Do not stick anything into the air outlet or inlet.
- It is dangerous and it can cause injury or damage.
3. Avoid exposing your body directly to a continuous cool air - flow for long periods.
- It is not good for your health.
4. Do not pour water on the unit to clean it.
- It is dangerous and it can cause injury or damage.
Never use solvents or harsh chemicals when cleaning the unit.
When the air inlet grill and cabinet are dirty, wipe with luke - warm water (below 104°F or 40°C)
5. Avoid placing any obstacles near the inlet or outlet.
- If the inlet or outlet is blocked with any obstacle, it may cause damage to the unit.
6. Do not run or stop the unit frequently.
- If you run or stop the unit more then 4-5 times an hour, it can cause damage to the unit.
7. Wait at least 3 minutes before restarting the unit or in the case of power failure.
- If you turn on the unit within 3 minutes after power off, this can cause damage to the unit.
8. If the air conditioner is operated without an air filter, dust is not removed from the air, and resultant
accumulation in the unit may lead to a failure.
- Do not forget to install the air filter.
9. The air filter should be cleaned at least once every two weeks.
10. When the unit is cleaned, set the Selector Switch at off position.
- And then unplug the power plug.
11. Never store gasoline or other flammable liquid near the air conditioner.
- It is very dangerous.
12. Do not force the controls on the front panel too much.
- It can cause damage the controls and the unit.
13. Set a comfortable temperature.
- Very low temperature setting considerably increase power consumption.
14. Be careful to keep room temperature comfortable.
- Avoid continuous direct air flow on you or a sick person while sleeping.
15. Do not remove the plug by pulling the power cord.
- Damage to the cord and may cause shock hazard.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWC121R1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWC121R1

Summary of Contents for Daewoo DWC121R1

  • Page 1 PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER Please observe the following instructions. 1. Operate the Selector Switch to run or stop the unit. - Do not use Main Power Switch or Auxiliary Power Switch to operate unit. 2. Do not stick anything into the air outlet or inlet. - It is dangerous and it can cause injury or damage.

  • Page 2: Table Of Contents

    1. GENERAL SPECIFICATIONS ...2 2. INSTALLATION INSTRUCTIONS...3~8 • WINDOW REQUIREMENTS • BASIC TOOLS NEEDED • SAFETY INSTRUCTIONS • BEFORE INSTALLATION • STEP1-PREPARE COMPONENTS FOR INSTALLATION • STEP2-PREPARE WINDOW FOR INSTALLATION • STEP3-PREPARATION OF CHASSIS • STEP4-PLACING CHASSIS • STEP5-SECURE WINDOW SHUTTER •...

  • Page 3: Installation Instructions

    INSTALLATION INSTRUCTIONS • WINDOW REQUIREMENTS These instructions are provided for a standard double hung window or mobile home double hung window installation in windows 27.5 inch (699mm) to 36 in (914mm). The upper and lower sash must open sufficiently to allow a clear vertical opening of 15 in (381mm) from the bottom of the sash to the window sill.

  • Page 4: Before Installation

    • SAFETY INSTRUCTIONS (CONTINUED) The receptacle should be an individual branch circuit used only for this air conditioner. Be sure the electrical service is adequate for the model air conditioner you have chosen. The complete electrical rating of your air conditioner is stated on the name plate located at the unit’s side.

  • Page 5: Step1-Prepare Components For Installation

    • Step 1 - Prepare Components For Installation Parts for installation are as follows; • Sill Bracket (2 pieces) • Window Kit Left side (Frame ‘L+Shutter) - (1 piece) • Window Kit Right side (Frame ‘R+Shutter) - (1 piece) • Sash Bracket (1 piece) •...
  • Page 6 3. Disassemble Front Grille from Chassis. – Front Grille and chassis are fixed with snap-fit. 1) Release right-lower snap-fit. – Push the right lower side of chassis to the left, with pushing left side of Front Grille to the right until the snap-fit is released. 2) Release left-lower snap-fit.

  • Page 7: Step4-Placing Chassis

    • Step 4 - Placing Chassis 1. Insert narrow side of ‘Frame Guide Lower’ to rectangle holes located in bottom of chassis, and fasten it with Screw (Type E). 2. Insert Window Kit Frames to Top Guide and Lower Guide. 3.

  • Page 8: Step6-Recheck Installation

    • Step 6 - Recheck Installation To be sure you have correctly installed your Room Air Conditioner, review the steps and make sure all of the parts are securely fastened in the window as the instructions show. A tight seal is essential. Read through the Use &...

  • Page 9: Names Of Major Components

    NAMES OF MAJOR COMPONENTS • DWC-121R / DWA-150R PART NAME AIR FILTER GRILLE FRONT CABINET BLADE VERTICAL PANEL CONTROL REMOTE CONTROLLER PART NAME BLADE HORIZENTAL AIR VENT FRAME GUIDE TOP FRAME WINDOW KIT SHUTTER WINDOW...

  • Page 10: Operation Instructions

    • DISPLAY MODE DISPLAY • It displays the operating mode. TEMP./TIMER DISPLAY • It displays the temperature and the timer. Room Air-conditioner TURBO COOLING MODE FAN SPEED • Everytime you push this button, It is selected as follow. (High Mid Low High) AUTO SWING •...

  • Page 11: Remote Control

    • REMOTE CONTROL TIMER/CANCEL • Everytime you push this button, timer is set as follow. (1Hr 2Hr 3Hr 4Hr 5Hr 6Hr 8Hr 10Hr 12Hr 16Hr 20Hr 24Hr CANCEL). After the unit is timed, if this button is pushed, timer is canceled.

  • Page 12: Operation

    FUNCTION POWER ON POWER Push POWER button COOLING MODE MODE MODE Push the ‘MODE’ button until ‘COOLING’ lamp lights. Change desired room temperature TEMP TEMP Push the ‘TEMP ’ button. Change ‘FAN SPEED’ FAN SPEED SPEED Push the ‘FAN SPEED’ button.
  • Page 13 FUNCTION FAN MODE 1. The Fan works only. 2. In this mode, the unit circulate room air. MODE 3. Fan speed can be changed. MODE Push the ‘MODE’ button until ‘FAN’ lamp lights. ON/OFF AUTO SWING 1. Auto swing function is toggled. 2.

  • Page 14: Display Temperature

    FUNCTION ON TIMER TIMER/ CANCEL Push the ‘TIMER/CANCEL’ button when unit is off. (REMOCON ONLY) SLEEP MODE SLEEP Push the ‘SLEEP’ button in ‘COOLING’ mode. (REMOCON ONLY) • ROOM TEMPERATURE DISPLAY. Over 45°C or 100°F 5°C~45°C or 41°F~99°F Below 5°C (41°F) OPERATION 1.

  • Page 15: How To Insert Batteries

    • HOW TO INSERT BATTERIES Remove the COVER from the back of the remote controller. • Slide the Cover according to the arrow direction • Do not use rechargeable batteries such batteries differ from standard dry cells in shape, dimensions, and performance.

  • Page 16: General Information

    • AIR FLOW AROUND UNIT Check in door grill and outdoor louvers for air flow obstructions. Do not block air flow to and from unit. The outdoor coil should be checked and periodically cleaned for debris that may collect and block unit air flow. If air flow is obstructed or deflected back into unit, the compressor may cycle on and off rapidly, causing early compressor failure.

  • Page 17: Care And Maintenance

    CAUTION To avoid death or personal injury due to electrical shock, turn fan control OFF and unplug power cord before cleaning or performing maintenance. After cleaning or performing maintenance, reconnect power. • AIR FILTER Clean the air filter, which removes dust inside the room. It should be washed at least once every week during operation.

  • Page 18: Electrical Requirements

    • ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three-prong(grounding) plug for protection against possible shock hazards. If a two-prong wall receptacle is encountered, the customer is required to contact a qualified electrician and have the two-prong wall receptacle replaced with a properly grounded three-prong wall receptacle in accordance with the National Electrical Code.

  • Page 19: Before Calling For Service

    BEFORE CALLING FOR SERVICE When you find something wrong with your room air conditioner, please carefully check the following items. If you are unable to find the cause of trouble, contact your service dealer. Difficulty • Air conditioner does not operate. •...

  • Page 20: Limited Warranty

    Daewoo authorized service center. To establish and receive warranty service at our store, dealer or our authorized service center, a sales receipt or bill of sales is required for proof of purchase.

  • Page 21: Room Air Conditioner

    ROOM AIR CONDITIONER USE & CARE MANUAL WINDOW TYPE ROOM AIR CONDITIONER DWC-121R MODEL #: DWA-150R UL and CUL listed LISTED Please read carefully and thoroughly this manual before operating the unit. If you still have any difficulties or problems, consult your dealer for help or ELECTRONICS.
