Daewoo DWC-121R Service Manual page 18

Front PCB ASS'Y(3104302400)
NO PART NAME
1 LED DISPLAY
2 C-CERA
3 RECEIVE MODULE
4 LED
5 LED
6 SWITCH TACT
7 DIODE
8 WAFER
9 WAFER
10 PCB
11 JUMPER
Remocon ASS'Y(3108402900)
NO PART NAME
1 CASE-A
2 CASE-B
3 CUSHION KEY
4 SPRING A
5 SPRING B
6 COMMON SPRING
7 SCREW A
8 RESONATOR
ELEC
9
CONDENSOR
10 CHIP CONDENSOR
11 CHIP RESISTOR
12 CHIP RESISTOR
13 TRANSISTOR
14 LED IR
15 IC REMOCON
16 COVER BTRY
17 PCB REMOCON
HOLDER
18
REMOCON
SPEC
88
103Z 50VDC
PIC-26043TH2
DLSO-5031D
DLG-5031D
JTP1212
1N4148
SMAW250-08
SMAW250-10
FR-1
10mm
SPEC
ABS380
BAS380
SILICON 6U
SUS304
SUS304
SUS304
M1.9*6.5
RJ-455BL
10VB 47M
CETMK212F221Z-T
1/10W 1.5 OHM
1/10W100K OHM
STN2222
SI5312-H
PT2221
ABS
FR-1
ABS
17
PART CODE
3103003700
CXCH1H103M
1PC26043TH
DDLS05031D
DDLG5031D-
3109300900
DZN4148A--
3108804800
3108802400
3104302200
3109400100
PART CODE
3101100510
3101100600
3101405900
3105100600
3105100700
3105100800
3108495110
5ZAR455---
CEAF10475M
HCQD220MQ
HRFT159JCP
HRFT104JCP
TSTN2222-
DS5312-H--
14EZPT2221
3101405900
3104302000
3103003400
Q'TY REMARK
1 DISP
1 C1
1 REMO
3
3
6
6 D1-6
1 CN1
1 CN2
1
7 J1-7
Q'TY REMARK
1
1
1
1
1
1
3
1 X1
1 C1
2 C2,3
1 R1
3 R2,3,4
1 Q1
1 IR1
1 U1
1
1
1
