Part List

MAIN PCB ASS'Y(3104302300)
NO PART NAME
1 IC MICOM
2 IC DRIVE
3 IC DRIVE
4 IC REGULATOR
5 IC REGULATOR
6 IC RESET
7 FUSE CLIP
8 FUSE
9 RELAY
10 RELAY POWER
11 RESONATIOR
12 VARISTOR
13 DIODE
14 DIODE
15 HEAT SINK
16 PCB
17 BUZZER
18 TR
19 WAFER
20 WAFER
21 WAFER
22 WAFER
23 WAFER
24 WAFER
25 WAFER
26 WAFER
27 PIN
28 RESISTOR
29 RESISTOR
30 RESISTOR
31 RESISTOR
32 RESISTOR
33 RESISTOR
34 RESISTOR ARRY
35 RESISTOR ARRY
36 C-ELEC
37 C-ELEC
38 C-ELEC
39 C-ELEC
40 C-ELEC
41 C-CERA
42 C-CERA
43 JUMPER
44 JUMPER
SPEC
TMP47P443N
TD62004AP
TD62783AP
KIA7812P
KIA7805P
KIA7042P
AFC-520
250V, 3.15A
CS11-12SH
G4A-1A
CST8.00MTW
15G561K
1N4004
1N4148
22(H)X23X17
FR-1
BM-20K
KRC3198Y
YW396-03AV
YPW500-04
YW396-03AV(BK)
YW500-02V
SMW250-02
SMW250-08
SMW250-10
YF254S-02
GP881206-2
300, 1/4W, 5%
1K, 1/4W, 5%
5.6K, 1/4W, 5%
10K, 1/4W, 5%
12.7K, 1/4W, 5%
300, 1/2W, 5%
9A 103J
8A 102J
1000µF 35V SD
470µF 25V SD
100µF 16V SD
10µF 50V SD
4.7µF 50V SD
103Z 50VDC
104Z 25VDC
10MM
6MM
16
PART CODE
13GSHK64--
13GT62004A
13GT62783A
1KA7812AP-
1KA7805AP-
1KA7042P--
3107000600
5FULB3152L
5SC0101128
5SC010141A
4850L03610
D15G561K--
DZN4004A--
DZN4148A--
3105797200
3104302100
3105698100
TZTC3198Y-
3108802500
3108805500
3108802700
3108803000
3108804200
3108804000
3108802100
3108804300
3108803500
RD-4K301J-
RD-4K102J-
RD-4K562J-
RD-4K103J-
RD-4K1272F
RD-2K301J-
RA8K8103J-
RA8K7102J-
CEXE1V108C
CEXE1E477C
CEXE1C107C
CEXE1C106C
CEXE1H475C
CCXE1H103M
CCXE1EH104M
3109400100
3109400200
Q'TY REMARK
1 U1
1 U3
1 U2
1 U4
1 U5
1 U6
2 FUSE
1
4 RL2
1 RL1
1 OSC1
1 VAR1
4 D1-4
1 D5
1
1
1 BZ
1 Q1
1 CN4
1 CN5
1 CN6
1 CN7
1 CN3
1 CN2
1 CN1
1 TEST
1 POWER
1 R4
1 R7
1 R1
5 R2,3,6,15,16
1 R5
7 R8-14
1 RA1
1 RA2
1 C2
1 C5
1 C7
1 C10
1 C11
1 C13
C2-4,6,
7
9,12,13
J1-6,9,12
14
J14-16,18
4 J7-8,13,17
