PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER
Please observe the following instructions.
1. Operate the Selector Switch to run or stop the unit.
- Do not use Main Power Switch or Auxiliary Power Switch to operate unit.
2. Do not stick anything into the air outlet or inlet.
- It is dangerous and it can cause injury or damage.
3. Avoid exposing your body directly to a continuous cool air - flow for long periods.
- It is not good for your health.
4. Do not pour water on the unit to clean it.
- It is dangerous and it can cause injury or damage.
Never use solvents or harsh chemicals when cleaning the unit.
When the air inlet grill and cabinet are dirty, wipe with luke - warm water (below 104°F or 40°C)
5. Avoid placing any obstacles near the inlet or outlet.
- If the inlet or outlet is blocked with any obstacle, it may cause damage to the unit.
6. Do not run or stop the unit frequently.
- If you run or stop the unit more then 4-5 times an hour, it can cause damage to the unit.
7. Wait at least 3 minutes before restarting the unit or in the case of power failure.
- If you turn on the unit within 3 minutes after power off, this can cause damage to the unit.
8. If the air conditioner is operated without an air filter, dust is not removed from the air, and resultant
accumulation in the unit may lead to a failure.
- Do not forget to install the air filter.
9. The air filter should be cleaned at least once every two weeks.
10. When the unit is cleaned, set the Selector Switch at off position.
- And then unplug the power plug.
11. Never store gasoline or other flammable liquid near the air conditioner.
- It is very dangerous.
12. Do not force the controls on the front panel too much.
- It can cause damage the controls and the unit.
13. Set a comfortable temperature.
- Very low temperature setting considerably increase power consumption.
14. Be careful to keep room temperature comfortable.
- Avoid continuous direct air flow on you or a sick person while sleeping.
15. Do not remove the plug by pulling the power cord.
- Damage to the cord and may cause shock hazard.
16. This air-conditioner must be used 20°C(min)~43°C(max) outdoor and 20°C(min)~32°C(max) indoor on
the temperature range.
17. The appliance is not intended for use by young children or infirm persons without supervision.
18. Young children should be supervised to ensure that they do not play with the appliance.
1
Advertisement
Table of Contents
Related Manuals for Daewoo DWC-100R
Summary of Contents for Daewoo DWC-100R
- Page 1 PRECAUTIONS FOR PROPER USE OF AIR CONDITIONER Please observe the following instructions. 1. Operate the Selector Switch to run or stop the unit. - Do not use Main Power Switch or Auxiliary Power Switch to operate unit. 2. Do not stick anything into the air outlet or inlet. - It is dangerous and it can cause injury or damage.
-
Page 2: Table Of Contents
• CLEANING THE AIR CONDITIONER 7. ELECTRICAL REQUIREMENTS......................19 • ELECTRICAL GROUNDING INSTRUCTIONS. • USE OF EXTENSION CORDS 8. BEFORE CALLING FOR SERVICE......................20 GENERAL SPECIFICATIONS ITEM DWC-100R DWC-121R DWA-122R DWA-150R DWA-151R POWER SOURCE AC 115V, 60Hz, SINGLE PHASE AC 208~230V, 60Hz, SINGLE PHASE 23.6(W) x 14.9(H) x 21.0(D) inch... -
Page 3: Installation Instructions
1. Install an exclusive main power switch (main circuit breaker) or GFI (Ground Fault Interrupted) switch. 2. Be sure to use grounded power source. 3. Power source for DWC-100R, DWC-121R is 115V and DWA-122R, DWA-150R, DWA-151R is 208~230V. 4. Consumer must pay charges for wiring and installation. -
Page 4: Before Installation
• SAFETY INSTRUCTIONS (CONTINUED) The receptacle should be an individual branch circuit used only for this air conditioner. Be sure the electrical service is adequate for the model air conditioner you have chosen. The complete electrical rating of your air conditioner is stated on the name plate located at the unit’s side. -
Page 5: Step1-Prepare Components For Installation
• Step 1 - Prepare Components For Installation Parts for installation are as follows; • SCREW TYPE • Sill Bracket (2 pieces) Type A Type B Type C Type D Type E • Window Kit Left side (Frame ‘L+Shutter) - (1 piece) •... - Page 6 3. Disassemble Front Grille from Chassis. – Front Grille and chassis are fixed with snap-fit. 1) Release right-lower snap-fit. – Push the right lower side of chassis to the left, with pushing left side of Front Grille to the right until the snap-fit is released. Push Push 2) Release left-lower snap-fit.
- Page 7 4. Reinstall the unit, side screws, front grille. CAUTION • When the front grille is reinstalled, the DOOR VENT should be in position first so that it would not be bent by grille. Door Vent...
-
Page 8: Step4-Placing Chassis
• Step 4 - Placing Chassis FRAME Screw (Type E, both side) 1. Insert narrow side of ‘Frame Guide Lower’ to rectangle holes Guide Lower located in bottom of chassis, and fasten it with Screw (Type E). 2. Insert Window Kit Frames to Top Guide and Lower Guide. 3. -
Page 9: Step6-Recheck Installation
• Step 6 - Recheck Installation To be sure you have correctly installed your Room Air Conditioner, review the steps and make sure all of the parts are securely fastened in the window as the instructions show. A tight seal is essential. Read through the Use &... -
Page 10: Names Of Major Components
NAMES OF MAJOR COMPONENTS PART NAME PART NAME AIR FILTER BLADE HORIZENTAL GRILLE FRONT AIR VENT CABINET FRAME GUIDE TOP BLADE VERTICAL FRAME WINDOW KIT PANEL CONTROL SHUTTER WINDOW REMOTE CONTROLLER... -
Page 11: Operation Instructions
OPERATION INSTRUCTIONS • DISPLAY MODE DISPLAY • It displays the operating mode. TEMP./TIMER DISPLAY • It displays the temperature and the timer. REMOTE SIGNAL RECEIVER TEMPERATURE SET • It is the button to set the desired room temperature. The temperature can be set within a range from 16°C (60°F) to 32°C (90°F) by 1°C (1°F) SENSOR... -
Page 12: Remote Control
• REMOTE CONTROL REMOTE SIGNAL TRANSMITTER TIMER/CANCEL • Everytime you push this button, timer is set as follow. (1Hr 2Hr 3Hr 4Hr 5Hr 6Hr 8Hr 10Hr 12Hr 16Hr 20Hr 24Hr CANCEL). SLEEP After the unit is timed, if this TIMER/ •... - Page 13 FUNCTION OPERATION DISPLAY POWER ON 1. The unit starts working. 1. Current room temperature is (It is delayed 3 minutes after main displayed. power source is supplied.) 2. ‘Cooling’ lamp lights. 2. Default mode is ‘Cooling’ mode. 3. Default desired room temperature is POWER ‘26°C’...
- Page 14 FUNCTION OPERATION DISPLAY FAN MODE 1. The Fan works only. 1. Current room temperature is 2. In this mode, the unit circulate room air. displayed. MODE 3. Fan speed can be changed. 2. ‘Fan’ lamp lights. MODE Push the ‘MODE’ button until ‘Fan’...
- Page 15 FUNCTION OPERATION DISPLAY ON TIMER 1. Timer is changed to as follows by 1. ‘Timer’ lamp lights. pushing “TIMER/CANCEL” button. 2. Setting time is displayed. TIMER/ CANCEL (1hr 2hr 3hr 4hr 5hr 6hr 8hr 10hr 12hr 16hr 20hr 24hr cancel) 2.
-
Page 16: How To Insert Batteries
• HOW TO INSERT BATTERIES Remove the COVER from Insert two batteries. Re-attach the cover. the back of the remote • Be sure that the (+) and (–) • Slide it back into position controller. directions are correct • Slide the Cover according to •... -
Page 17: General Information
GENERAL INFORMATION • AIR FLOW AROUND UNIT Check in door grill and outdoor louvers for air flow obstructions. Do not block air flow to and from unit. The outdoor coil should be checked and periodically cleaned for debris that may collect and block unit air flow. If air flow is obstructed or deflected back into unit, the compressor may cycle on and off rapidly, causing early compressor failure. -
Page 18: Care And Maintenance
CARE AND MAINTENANCE CAUTION To avoid death or personal injury due to electrical shock, turn fan control OFF and unplug power cord before cleaning or performing maintenance. After cleaning or performing maintenance, reconnect power. • AIR FILTER Clean the air filter, which removes dust inside the room. It should be washed at least once every week during operation. -
Page 19: Electrical Requirements
3-wire grounding type appliance extension cord rated has a 3-blade grounding plug and a 3-slot receptacle that will plug into the appliance. The marked rating of the extension cord should be 125V/13A minimum for DWC-100R, DWC-121R and 250V/10A minimum for DWA-122R, DWA-150R, DWA-151R. WARNING : To avoid death, personal injury or properly damage due to electrical shock, do not use an extension cord or pinch the power cord. -
Page 20: Before Calling For Service
BEFORE CALLING FOR SERVICE When you find something wrong with your room air conditioner, please carefully check the following items. If you are unable to find the cause of trouble, contact your service dealer. Difficulty Possible Cause Suggested Solution • Air conditioner does •... -
Page 21: Limited Warranty
Daewoo authorized service center. To establish and receive warranty service at our store, dealer or our authorized service center, a sales receipt or bill of sales is required for proof of purchase. -
Page 22: Room Air Conditioner
ROOM AIR CONDITIONER USE & CARE MANUAL WINDOW TYPE ROOM AIR CONDITIONER DWC-100R MODEL #: DWC-121R DWA-122R DWA-150R DWA-151R UL and CUL listed LISTED Please read carefully and thoroughly this manual before operating the unit. If you still have any difficulties or problems, consult your dealer for help or ELECTRONICS.
