User's Manual
Right Side View
Phone Jack
The RJ-11 phone jack is used to support a built-in 56K MDC modem.
For more information on the phone jack please refer to Chapter 3
"Attaching Peripherals".
Hard Disk Drive
The computer accepts any 2.5" hard disk drive with 9.5mm/12.7mm/
17.0mm height. The hard disk drive is removable and can be re-
placed. For more information please refer to Chapter 2 "Using the
Computer".
PC Card Slot
There are two PC card slots (PCMCIA) located on the computer,
which accepts two Type II PC cards or one Type III PC card to
expand the computer's capability. To remove the PC card, press the
PC-Card eject button.
Floppy Disk Drive
The computer comes standard with a 1.44MB floppy disk drive
installed. The floppy-disk-drive module can be replaced with other
disk-drive units, such as a secondary 2.5" 12.7mm(h)/12.5mm(h)
hard disk drive or a 15mm(h) Zip 100/250MB drive. For more infor-
mation please refer to Chapter 2 "Using the Computer".
1-6
