B3
E S T A T E S E R I E S
MASTER / SLAVE SYSTEMS
MODEL SL 1000-B3, SW 2000-B3 & BG 3000-B3
SLIDE, SWING, AND BARRIER GATE OPERATORS
MODEL SL 1000-B3
MODEL BG 3000-B3
MODEL SW 2000-B3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL 1000-B3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Chamberlain SL 1000-B3

  • Page 1 E S T A T E S E R I E S MASTER / SLAVE SYSTEMS MODEL SL 1000-B3, SW 2000-B3 & BG 3000-B3 SLIDE, SWING, AND BARRIER GATE OPERATORS MODEL SL 1000-B3 MODEL BG 3000-B3 MODEL SW 2000-B3...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY SUMMARY ..........................1 BASIC INSTALLATION HINTS AND RULES ..................2 PART 1 MASTER/SLAVE OPERATION .................... 3 A. WHAT IS MASTER/SLAVE OPERATION?....................3 B. MASTER/SLAVE GATE CONFIGURATIONS...................3 C. MASTER/SLAVE INSTALLATION DETAILS ....................3 PART 2 MASTER/SLAVE LAYOUTS AND WIRING ............... 10 A.
  • Page 3 TABLE OF FIGURES Figure 1. Master/Slave Gate Configurations......................3 Figure 2. Typical Bi-Parting Gate Installation......................4 Figure 3. Typical Bi-Parting Latch Gate Installation.....................5 Figure 4. Typical Trap Gate Installation.......................6 Figure 5. Typical Tandem Gate Installation......................8 Figure 6. Biparting Slide Gate Photo-Sensor Layout..................10 Figure 7.
  • Page 4: Safety Summary

    SAFETY SUMMARY It is important for everyone involved in the installation and operation of the LiftMaster models SL 1000, SW 2000, and BG 3000 Master/Slave systems to read the following warnings. WARNING! • A vehicle gate is a large, heavy object that is moved by an electric motor. A moving gate can cause serious injury or death! The safety and well-being of others depends on the installation of a safe system.
  • Page 5: Basic Installation Hints And Rules

    BASIC INSTALLATION HINTS AND RULES READ THIS SECTION CAREFULLY BEFORE BEGINNING YOUR INSTALLATION UNDERSTAND THE SYSTEM AND INSTALLATION SITE THOROUGHLY. The B3 series are flexible and reliable gate operator systems, but the quality of service depends directly on the quality of installation.
  • Page 6: Part 1 Master/Slave Operation

    PART 1 MASTER/SLAVE OPERATION A. WHAT IS MASTER/SLAVE OPERATION? The easy way to understand master/slave operation is by the computer terms “smart” and “dumb”. • “Smart” machines are controlled by a computer or dedicated microprocessor, such as microwave ovens and new-style washing machines. •...
  • Page 7: Master/Slave Installation Details

    C. MASTER/SLAVE INSTALLATION DETAILS BI-PARTING GATE DETAILS The simple Bi-Parting Gate is typically used in low traffic residential sites due to its ease of use. The Bi- Parting configuration can consist of any combination of models SL 1000-B3 (slide gate), SW 2000-B3 (swing gate), and BG 3000-B3 (barrier gate).
  • Page 8: Figure 3. Typical Bi-Parting Latch Gate Installation

    2. BI-PARTING LATCH GATE DETAILS The Bi-Parting Latch Gate is typically used in low traffic residential sites due to ease of use and added security of magnetic locking. The Bi-Parting Latch configuration can consist of any combination of models SL 1000-B3 (slide gate), SW 2000-B3 (swing gate), and BG 3000-B3 (barrier gate). ADDITIONAL INPUTS: Radio...
  • Page 9: Figure 4. Typical Trap Gate Installation

    3. TRAP GATE DETAILS The Trap gate is typically used in secured sites for screening incoming and/or outgoing traffic. In the Trap configuration, only one gate opens at a time, “trapping” the vehicle between gates. Due to ease of use, Slide Gates are the most popular for the Trap configuration. The Trap configuration can consist of any LiftMaster model for the Master, and a model SL 1000-B3 (slide gate), or BG 3000-B3 (barrier gate) for the Slave.
  • Page 10 There are 2 different ways to close the gate (entering or exiting): Reclose Timer: When the Reclose Timer expires, gate closes automatically (Master or Slave). Interrupt Loop: clearing the Inside Interrupt Loops cause the gates to close (Master or Slave). NOTE: To ensure gate closure, set Reclose Timer = ON in both Master and Slave units.
  • Page 11: Figure 5. Typical Tandem Gate Installation

    4. TANDEM GATE DETAILS The Tandem gate is typically used in high traffic situations where some control of incoming and/or outgoing traffic is required. The outside gate (slave) is usually a less expensive fast moving barrier gate (or light slide gate) which protects the more expensive and less mobile Slide or Swing inside gate (master).
  • Page 12 HOW IT WORKS: • When a vehicle is entering or exiting, the inside Master gate opens first. When the Master is completely open, the outside Slave gate opens, allowing the vehicle to enter or exit. • The Master unit Reclose Timer (if enabled) does not start counting down until the Slave gate is fully closed.
  • Page 13: Part 2 Master/Slave Layouts And Wiring

    PART 2 MASTER/SLAVE LAYOUTS AND WIRING A. PHOTO-SENSOR INSTALLATION FOR BIPARTING GATE CONFIGURATION BIPARTING SLIDE GATES Figure 6. Biparting Slide Gate Photo-Sensor Layout. WARNING Buy only UL-approved photo-sensors made for use with vehicular gate operators or system. Otherwise, safe gate operation may be compromised. IMPORTANT NOTE: The installation shown in Figure 6 above is a suggested layout using emitters and receivers.
  • Page 14: Figure 7. Biparting Swing Gates Photo-Sensor Layout

    BIPARTING SWING GATES Figure 7. Biparting Swing Gates Photo-Sensor Layout. WARNING Buy only UL-approved photo-sensors made for use with vehicular gate operators or system. Otherwise, safe gate operation may be compromised. IMPORTANT NOTE: The installation shown in Figure 7 above is a suggested layout using emitters and receivers.
  • Page 15: Photo-Sensor Installation For Trap/Tandem Gate Configuration

    BIPARTING BARRIER GATES Figure 8. Biparting Barrier Gates Photo-Sensor Layout. WARNING Buy only UL-approved photo-sensors made for use with vehicular gate operators or system. Otherwise, safe gate operation may be compromised. IMPORTANT NOTE: The installation shown in Figure 8 above is a suggested layout using emitters and receivers.
  • Page 16: Connecting Input Wiring

    C. CONNECTING INPUT WIRING Figure 9. Control Board Wiring. IMPORTANT Before proceeding, see NOTES on the next page. Rev E Doc 01-20201 13 of 33...
  • Page 17 NOTES Disconnecting the STOP terminal from the COMMON terminal stops the gate and prevents all commands from having any effect. Manual Open does not activate the Reclose Timer. If gate(s) are used for bi-directional traffic, the Exit Loop should be a directional loop detector. Inside and Outside Interrupt Loops: ♦...
  • Page 18: Master/Slave Interconnection

    D. MASTER/SLAVE INTERCONNECTION • A conduit between the Master and Slave units should be provided for the Master/Slave interconnection cable. • Two shielded twisted pair wire 16 AWG to 24 AWG will be connected between the two units at TB1 on the controller Board NOTES: 1.
  • Page 19: Switch S1 Master Slave Configurations And Gate Controls Settings

    F. SWITCH S1 MASTER SLAVE CONFIGURATIONS AND GATE CONTROLS SETTINGS: MASTER/SLAVE CONFIGURATIONS: Figure 11. Switch S1 Settings for Master/Slave Systems. Rev E Doc 01-20201 16 of 33...
  • Page 20: System Layouts And Control Wiring

    G. SYSTEM LAYOUTS AND CONTROL WIRING Additional Master Wiring Can use Radio or Cycle if Can use Radio or Cycle if Can use Radio or Cycle if (if needed): Exit Loop is not used. Exit Loop is not used. Exit Loop is not used. Fire Manual Inputs Interrupt Bar...
  • Page 21: Figure 14. Bi-Part, Uni-Directional Gate System (Swing Gate Opens Out)

    Additional Master Wiring Can use Radio or Cycle if Exit Loop is not used. (if needed): Fire Manual Inputs Exit Loop Interrupt Bar Photo-Sensors MagLock Outside Interrupt Loop Warning Relay Tel. Line Swing Gate Swing Gate Gate Gate Master/Slave Cable Operator Operator Master...
  • Page 22: Figure 16. Bi-Part Latch, Uni-Direction Gate System (Swing Gate, If Used, Opens In)

    Additional Master Wiring (if needed): Can use Radio* or Cycle if Exit Loop is not used. Fire Manual Inputs Interrupt Bar Exit Loop Photo-Sensor Swing gate open MagLock direction and its Warning Relay Inside Interrupt Loop maximum arc. Tel. Line Shadow Loop Gate Gate...
  • Page 23 Additional Master Wiring Can use Radio or Cycle if (if needed): Exit Loop is not used. Fire Manual Inputs Directional Exit Loop Interrupt Bar Photo-Sensors MagLock Inside Interrupt Loop Tel. Line Shadow Loop Gate (swing gates only) Swing gate open Operator direction and its Master...
  • Page 24: Figure 19. Bi-Directional Trap Gate System (Swing Gate Opens Out)

    Can use Radio or Cycle if Additional Exit Loop is not used. Master Wiring (if needed): Directional Exit Loop Fire Manual Inputs Interrupt Bar Outside Interrupt Loop Photo-Sensors MagLock Tel. Line Slide, Barrier or Swing Gate Gate Swing gate open Operator direction and its Shadow Loop...
  • Page 25: Figure 20. Uni-Directional Trap Gate System (Internal Swing Gate, If Used, Opens In)

    Additional Master Wiring Can use Radio* or Cycle if (if needed): Exit Loop is not used. Fire Manual Inputs Exit Loop Interrupt Bar Photo-Sensors MagLock Inside Interrupt Loop Tel. Line Shadow Loop Gate (swing gates only) Swing gate open Operator direction and its Master maximum arc.
  • Page 26: Figure 21. Uni-Directional Trap Gate System (Internal Swing Gate Opens Out)

    Can use Radio* or Cycle if Additional Exit Loop is not used. Master Wiring (if needed): Exit Loop Fire Manual Inputs Interrupt Bar Outside Interrupt Loop Photo-Sensors MagLock Tel. Line Swing Gate Gate Swing gate open Operator direction and its Shadow Loop maximum arc.
  • Page 27: Figure 22. Uni-Directional Trap Gate System (External Swing Gate, If Used, Opens In)

    Additional Master Wiring (if needed): Fire Manual Inputs Interrupt Bar Outside Interrupt Loop Photo-Sensors MagLock Tel. Line Slide, Barrier or Swing Gate Gate Swing gate open Operator direction and its Shadow Loop maximum arc. (Swing gate only) Master Inside Interrupt Loop Additional Master/ Slave Wiring...
  • Page 28: Figure 23. Uni-Directional Trap Gate System (External Swing Gate Opens Out)

    Additional Master Wiring (if needed): Fire Manual Inputs Interrupt Bar Photo-Sensors MagLock Inside Interrupt Loop Tel. Line Gate Shadow Loop Swing gate open Operator direction and its Master maximum arc. Swing Gate Outside Interrupt Loop Additional Slave Wiring Master/ (if needed): Slave Interrupt Bar Cable...
  • Page 29: Figure 24. Bi-Directional Tandem Gate System (Swing Gate, If Used, Opens In)

    Additional Master Wiring (if needed): Can use Radio or Cycle if Fire Exit Loop is not used. Manual Inputs Interrupt Bar Directional Exit Loop Photo-Sensors MagLock Warning Relay Inside Interrupt Loop Tel. Line Gate Shadow Loop (swing gates only) Operator Swing gate open direction and its Master...
  • Page 30: Figure 25. Bi-Directional Tandem Gate System (Swing Gate Opens Out)

    Additional Can use Radio or Cycle if Master Wiring Exit Loop is not used. (if needed): Fire Directional Exit Loop Manual Inputs Interrupt Bar Photo-Sensors Outside Interrupt Loop MagLock Warning Relay Tel. Line Swing Gate Gate Swing gate open Operator direction and its Shadow Loop maximum arc.
  • Page 31: Figure 26. Uni-Directional Tandem Gate System (Swing Gate, If Used, Opens In)

    Additional Master Wiring (if needed): Fire Manual Inputs Interrupt Bar Photo-Sensors Outside Interrupt Loop MagLock Warning Relay Tel. Line Slide, Barrier or Swing Gate Gate Swing gate open Operator direction and its Shadow Loop Master maximum arc. (Swing gates only) Inside Interrupt Loop Additional Master/...
  • Page 32: Figure 27. Uni-Directional Tandem Gate System (Swing Gate Opens Out)

    Additional Master Wiring (if needed): Fire Manual Inputs Interrupt Bar Photo-Sensors MagLock Warning Relay Inside Interrupt Loop Tel. Line Gate Shadow Loop Swing gate open Operator direction and its Master maximum arc. Swing Gate Outside Interrupt Loop Additional Slave Wiring Master/ (if needed): Slave...
  • Page 33: Troubleshooting

    H. TROUBLESHOOTING Units work as stand-alone: Miswired or disonnected Master/Slave interconnect cable. Improper Master/Slave switch S1 setting. Bad Control board. Units are not synchronized: Improper Operator Pair setting. See programming step 02, Operator Type. One gate braking to stop causes a fault in the other (moving) gate: Both units are wired to the same circuit breaker.
  • Page 34: Fcc Requirements

    FCC REQUIREMENTS INSTALLATION When you are ready to install this system, call your telephone company and give them the following information: 1. The telephone number of the line to which you will connect the system. 2. The FCC registration number for the system, which is DS83E7 - 17196 - ALE. 3.
  • Page 35: Notice To Canadian Users

    NOTICE TO CANADIAN USERS NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operation and safety requirements as prescribed in the appropriate Terminal Equipment Requirements document(s). The Department does not guarantee the equipment to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
  • Page 36 COPYRIGHT 2002 ALL RIGHTS RESERVED This document is protected by copyright and may not be copied or adapted without the prior written consent of LiftMaster. This documentation contains information proprietary to LiftMaster and such information may not be distributed without the prior written consent of LiftMaster. The software and firmware included in the LiftMaster product as they relate to this documentation are also protected by copyright and contain information proprietary to LiftMaster.
