Main Panel
All lowpass filters in ABSYNTH 5 contain the following parameters on their Main panel:
•
Frequency control and Frequency menu: The Frequency control allows you to set the cut-
off frequency in semitones (Trans) or in Hertz (Hz), upon the selection in the nearby
Frequency menu.
•
Resonance control: Sets the resonance at the cutoff frequency.
•
Damping control: Allows you to balance out the volume level. If the signal level at the
filter output seems too weak, increase this value.
Feedback Panel
Furthermore, the filter types LPF 2 Pole, LPF 4 Pole and LPF 8 Pole are equipped with a
feedback loop. Its function and parameters are detailed at section
and Feedback Panel"

5.5.5 Highpass

Highpass Filter HPF -12dB
Highpass filters permit all frequencies above a cutoff frequency and suppress the frequencies
below it. Their remaining functions are identical to those described for the lowpass filters in
the section 5.5.4, "Lowpass", above.
The following highpass filters are available in the Type menu:
•
HPF -6dB: 1-pole highpass filter.
•
HPF -12dB: 2-pole highpass filter with resonance control.
above.
5.5.3 "Feedback Loop
ABSYNTH 5 Reference Manual – 68
