4.1.5 Input and Output Level Meters

The Input and Output Level meters indicate the levels of the incoming and outgoing audi signals:
Input Output Llevel meters
The four LED chains labeled In indicate when a signal is going into an Oscillator module. You can
read the levels of the outgoing signals on the eight LED chains labeled Out. As explained in the
section on surround configurations in the Options dialog (see 3.4 above), ABSYNTH 5 can handle
up to eight simultaneous audio outputs. Each of these eight outputs has its own LED chain.

4.1.6 Panic Button

Panic button
The Panic button allows you to interrupt the audio playback in ABSYNTH 5, in case some-
thing goes wrong and unwanted sound is being produced. Click on the Panic button to reset
the audio engine of ABSYNTH 5 and to stop the playback process. All of the MIDI notes that
have been "left hanging" will also reset.

4.1.7 NI Logo

Interactive NI logo
Clicking on the NI logo has the same effect as clicking on the ABSYNTH 5 logo: it opens the
About screen. This About screen contains some important information: the version number,
license type and serial number of your copy of ABSYNTH 5, along with the list of all the
people who worked on this great synth!
ABSYNTH 5 Reference Manual – 32
