2 Programming with SPM
Using SPM
To initiate Pass-Thru, establish a modem connection between the SPM PC and
the control unit.
If the IS II/III PC does not respond to the Pass-Thru request from the control unit
(for example, because the PC is turned off), you see the following message:
If the connection between the control unit and the IS II/III PC fails, the connection
between the control unit and the SPM PC is dropped. You see the following
message:
When you press
Follow the steps below to initiate the Pass-Thru.
At the SPM Main Menu, press
The display area changes to 24-lines by 80-characters, which is much larger than the
display area on the console simulation window (7-lines by 24-characters).
Type your login name, and press
Type the IS II/III password, and press
you return to the SPM Main Menu.
to select
.
.
