iD LR-6
User Guide
R9010342
R59770134/01
27/05/2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iD LR-6 R9010342 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco iD LR-6 R9010342

Summary of Contents for Barco iD LR-6 R9010342

  • Page 1 iD LR-6 User Guide R9010342 R59770134/01 27/05/2011...
  • Page 2 Barco nv Presentations Noordlaan 5, 8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.35.86.51 Support: www.barco.com/esupport Visit us at the web: www.barco.com Printed in Belgium...

  • Page 3: Disposal Information

    The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.
  • Page 4 Trademarks Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders. All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for the products or their manufacturers.

  • Page 5: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Packaging......................5 Unpacking .
  • Page 6 Table of contents 6.4.2 Aspect ratio ........................53 6.4.3 Show native resolution.
  • Page 7 Table of contents Glossary ....................... 125 Index.
  • Page 8 Table of contents R59770134 ID LR-6 27/05/2011...

  • Page 9: Packaging

    1. Packaging 1. PACKAGING Unpacking CEE7/7 European power plug to connect the power cord to the wall outlet. NEMA5 American power plug to connect the power cord to the wall outlet. Content • 1 projector (weight ± 14 kg or 31 lbs) •...
  • Page 10 1. Packaging How to unpack the projector 1. Release the cord straps. PULL TO OPEN Image 1-2 2. Remove the assembly from the pallet 3. Remove the cardboard cover 4. Remove the large cardboard 5. Remove the 8 foam parts 6.

  • Page 11: Installation Guidelines

    It is advised to clean the dustfilters on a regular basis and to replace them at any lamp change. Barco reserves itself the right to refuse warranty replacement of consumables if they have been used in a projector with dirty airfilters.

  • Page 12: What About Ambient Light

    2. Installation guidelines What about ambient light ? The ambient light level of any room is made up of direct or indirect sunlight and the light fixtures in the room. The amount of ambient light will determine how bright the image will appear. So, avoid direct light on the screen. Windows that face the screen should be covered by opaque drapery while the set is being viewed.

  • Page 13: Installation

    3. Installation 3. INSTALLATION Overview • Battery installation in the RCU • Lens installation • Projector configuration • Positioning the projector • Connections Dimensions overview Dimensions are given in mm (1 inch = 25.4 mm) Length with different lenses : see table Cold air IN Cold air IN 487 (length without Cable Basket)

  • Page 14: Battery Installation In The Rcu

    3. Installation Lens Length of projector CLD (1.2-1.6:1) 530 mm CLD (1.6-2.4:1) 525 mm CLD (2.4-4.3:1) 550 mm QCLD (1.1-1.3:1) 580 mm 610 mm QCLD (0.85:1) Battery installation in the RCU How to install the battery Two batteries are packed together with the RCU. Before using your RCU, install first these batteries. 1.

  • Page 15: Lens Installation

    3. Installation Lens installation 3.2.1 Lens installation How to install ? 1. Take the lens out of its packing material 2. Fix the lens by placing it in the housing Image 3-3 Note: In case of a motorized lens the female jack must be in front of the male jack located in the upper-left part of the housing in the projector 3.

  • Page 16: Lens Formulas

    3. Installation Lens Partnumber CLD (2.4-4.3:1) R9849890 QCLD (1.1-1.3:1) R9849850 QCLD (0.85:1) R9849860 See the Maintenance appendix for more information about lens cleaning. 3.2.4 Lens Formulas Formulas Lenses Metric Formulas (meter) Inch formulas (inch) QCLD (0.85:1) PD = 0.86 X SW + 0.06 PD = 0.86 X SW + 2.36 QCLD (1.1-1.3:1) = 1.1 X SW + 0.05...

  • Page 17: Positioning The Projector

    3. Installation Image 3-6 The configuration should also be communicated to the projector. This is done in the Installation menu through the Projector Configuration parameter. (See Setup section) Positioning the projector On-Axis projection Projection where the projector is positioned so as to have the centre of the lens coinciding with the centre of the screen. Positioning the projector The position of the projector with reference to the screen may also be different depending on the installation.
  • Page 18 3. Installation front plate CD=SH/2+B-A Image 3-7 R59770134 ID LR-6 27/05/2011...
  • Page 19 3. Installation front plate CD=B-A Image 3-8 A 100% Off-Axis position means that the position of the centre of the lens is shifted by half the screen height. Never use a short throw lens in an Off-Axis installation. Shifting the lens will not guarantee optimal image quality.

  • Page 20: Connections

    3. Installation AUTION Never place the projector on either side ! Floor Floor Image 3-9 Connections 3.5.1 Power connection AC power (mains) cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. The power input is auto-ranging from 90 to 240 VAC.

  • Page 21: Input Section

    3. Installation 3.5.2.1 Input section Input Layers The input section is divided in layers, each of them regrouping several inputs, this architecture allows the input section to be upgraded at any time with an optional analog or digital layer. Layer 1: analog layer containing analog data and video inputs Layer 2: a hybrid layer containing 2 digital and 1 analog input Layer 3 : is an optional layer, it may be an Audio &...

  • Page 22: 5-Cable Input

    3. Installation Layer 3 can be an optional audio&video layer or an optional SDI (SDI Input/Output) Image 3-10 source input section with optional SDI layer A cable cover is supplied with the projector and can be fitted on the front of the projector Image 3-11 Cable basket : the white arrow shows the cables leaving the projector Front view...

  • Page 23: Composite Video Input

    3. Installation Image 3-12 Component Video In Component Video the term component describes a number of elements that are needed to make up the video pic- ture, these components are PR/Y/PB. A composite video signal on the other hand contains all the information needed for the color picture in a single channel of information Which signals can be connected ? Signals/Input BNC...

  • Page 24: S-Video Input

    3. Installation How to select a Composite Video Input ? 1. Press 3 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. 3.5.2.5 S-Video input Input specification Image 3-14 Which signal can be connected ? Standard S-Video (S-VHS) with separate Y(luma) and C (chroma) signals.

  • Page 25: Computer Input

    3. Installation Image 3-15 DVI-I type connector, analog link (4 pins at the right side of the connector) not supported How to select the DVI Input ? 1. Press 5 on the RCU Note: Another way for selecting this input is via the Menu. 3.5.2.7 Computer input Input specification...

  • Page 26: Audio Input/Output (Optional)

    3. Installation Input specifications SDI input : BNC SDI output : BNC (=loop through) typical : 0.8 Vpp 75Ω terminated output impedance: 75Ω Image 3-17 How to select the SDI input 1. Press 7 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. The SDI is located on Layer3 which is an optional Layer.

  • Page 27: Communications Connections

    3. Installation Image 3-18 3.5.2.10 Communications Connections Overview • RS232 IN connection 3.5.2.10.1 RS232 IN connection What can be connected to the RS232 IN connection ? The RS 232 IN connections allows the projector to communicate with a Computer e.g. IBM PC or Apple Macintosh. Image 3-19 Applications of the RS232 connection Remote control:...
  • Page 28 3. Installation R59770134 ID LR-6 27/05/2011...

  • Page 29: Setup

    4. Setup 4. SETUP Overview • RCU & Local keypad • Terminology overview • Switching on • Setting the RCU address • Projector address • Orientation • Adjusting the lens • Preferences RCU & Local keypad How controlling the projector ? The projector can be controlled by the local keypad or by the remote control unit.

  • Page 30: Terminology Overview

    4. Setup Remote control functions. This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely. This remote control is used for source selection, control, adaptation and set up. It includes automatic storing of picture controls (Bright- ness, Sharpness...) and settings.
  • Page 31 4. Setup Image 4-2 Function keys user programmable keys with functions for direct access. MENU Menu key, to enter or exit the Toolbar menu. Address key (recessed key), to enter the address of the projector (between 0 and 9). Press the recessed address key with a pencil, followed by pressing one digit button between 0 and 9.

  • Page 32: Switching On

    4. Setup ENTER to confirm an adjustment or selection in the MENU. On the local keypad the ENTER button additionally accesses the PIP window resize function Cursor keys Cursor Keys on RCU or on the local keypad : to make menu selections or to access the toolbar.

  • Page 33: Setting The Rcu Address

    4. Setup Setting the RCU address What has to be done ? To allow the communication between the RCU and the projector the RCU has to be programmed with the same address as the projector. This address must be in the range 0–9. To know the address of the projector, one can visualize it in projection mode (on screen) as well as in standby mode (shown with the LED’s on top cover of the projector).

  • Page 34: Projector Address

    4. Setup Projector address What can be done ? The projector is shipped with projector address set to ”0” In some cases the projector address must be changed, for example if an unique RCU is used to control 2 or more projectors (inde- pendently).

  • Page 35: Orientation

    4. Setup A dialog box appears on the screen. Entering the new common address ? 1. Enter the new projector address with the digit keys on the RCU, the local keypad or the cursor keys. This address must be between 0 or 1. Orientation Projector orientations Depending on how the projector is oriented, the projector’s internal settings have to be adapted.
  • Page 36 4. Setup The lens can also be adjusted via the dedicated keys on the remote. How to Zoom/focus or shift via the RCU (or keypad) 1. Press LENS ZOOM or LENS FOCUS or LENS SHIFT on the RCU B R I H T N N T R L E N...

  • Page 37: Preferences

    4. Setup A textbox appears on the screen, follow the instructions. Image 4-13 Image 4-12 The use of a sheet of paper held in front of the screen can be useful to determine the focus plane (position for best focus) Vertical shift range : -120% to 120% Preferences 4.8.1...

  • Page 38: Quick Access Keys

    4. Setup 7. Press ENTER The language is adapted and a black bullet shows the active configuration. 4.8.2 Quick access keys What can be done ? The 3 function keys on top of the RCU can be associated with a particular item in one of the menus. Each function which is not password protected or does not have a key on the RCU can be associated to a function key.
  • Page 39 4. Setup This means that the automatic startup allows immediate restart of the projector after a power failure (breakdown), i.e. without passing through the standby state, by recovering the previous settings (previous source,...). This function can be disabled if undesired or inadequate for safety reasons, etc. AUTION If the Automatic startup function is enabled one must be aware of the fact that it involves safety precautions...
  • Page 40 4. Setup R59770134 ID LR-6 27/05/2011...

  • Page 41: Getting Started

    5. Getting started 5. GETTING STARTED Start up How to start up the projector ? 1. Press the Standby button on the RCU or the local keypad M E N T E R U SE O G O Image 5-1 The last selected source is displayed Creating your personal PiP Layout As an example: the layout to be created must contain :...

  • Page 42: Video/Data Pip Layout

    5. Getting started Image 5-3 Image 5-4 3. Follow the instruction wizard (size, position, order) 4. Repeat the previous steps to add the RGB source 5. Save the PiP layout in the PiP layout/Save as menu by typing a new name Image 5-5 Video/Data PiP layout The added source(s) should be displayed with the right settings thanks to AutoImage.

  • Page 43: Adjusting The Image

    5. Getting started Adjusting the image How to adjust the image 1. Use the PiP adjust button on the RCU to select the desired window M E N Image 5-6 2. Use the Image setting buttons on the RCU PH A T I N T B R I H T N...
  • Page 44 5. Getting started R59770134 ID LR-6 27/05/2011...

  • Page 45: Advanced

    6. Advanced 6. ADVANCED Using the Dialog boxes How to use the dialog boxes ? Some parameters are modified by means of a dialog box, where selections can be made and/or values can be entered. The values can be entered in several ways: Entering numeric values using the numeric keys on the remote control 1.

  • Page 46: Source Selection

    6. Advanced Source Selection Overview • Source selection • Composite Video • S-Video 6.2.1 Source selection Selecting a source The Source selection menu allows to select one of the different sources. Another method to select an input source is via the remote control using the numeric keys or by using the local keypad.

  • Page 47: Composite Video

    6. Advanced On the screen appears now the selected source. The Barco logo on the menu indicates the presence of a signal, the digit indicates the shortcut key on the RCU. The 3 first sources (Data on BNC’s, Component Video & RG(s)B) refer to the 5-cable input, the position of the indication “1”...

  • Page 48: S-Video

    6. Advanced The composite video sources can also be selected using the video selector or via the dedicated key 3 on the RCU. Key 3 allows to browse through the active video inputs when the extended mode is checked in Video Selector..

  • Page 49: Pause

    6. Advanced 6.3.1 Pause Interrupting the image projection With the Pause function, the image projection can be stopped, the projector remains with full power for immediate restart. How to interrupt the image projection ? 1. Press MENU to activate the Tool bar 2.

  • Page 50: Standby Timer

    6. Advanced 6.3.3 Standby Timer Purpose of the Standby Timer If there is no signal, and the standby timer is enabled, a dialogbox is displayed and the projector will shut down after a determined time. The countdown time can be set in a dialog box in a range from 180 to 3600 seconds (default value = 300). The Timer can also be disabled.

  • Page 51: Audio Settings

    6. Advanced 3. Press ↓ to Pull down the General menu 4. Use ↑ or ↓ to select Audio setup Image 6-11 5. Press ENTER A dialog box is displayed Image 6-12 LED is red : audio input is mute LED is green : input is active (linked image source is selected) LED is orange : image source is not selected How to mute an Audio channel ?

  • Page 52: Identification

    6. Advanced Image 6-13 5. Press ENTER A dialog box is displayed Image 6-14 6. Use the arrow keys to select and change the settings Note: The default value for the volume is 43, this corresponds to a gain factor of 1 (volume in = volume out). 6.3.5 Identification The projector’s identification screen...

  • Page 53: Image Menu

    6. Advanced On the screen appears a text box. In this case the projector is an iDR500 Image 6-16 6. Press MENU or BACK to exit or to go back to the previous menu Image menu Overview • Settings • Aspect ratio •...

  • Page 54: Contrast

    6. Advanced Image 6-17 Image 6-18 6.4.1.1 Contrast Contrast adjustment Adjust the contrast to “brighten” the white parts of the image. It is recommended to adjust the brightness before adjusting the contrast. How to change the contrast 1. Press MENU to activate the Toolbar 2.

  • Page 55: Brightness

    6. Advanced 6.4.1.2 Brightness Brightness adjustment Adjusting the brightness will affect the dark areas of the image. Increase the brightness to “lighten” up the parts that are too dark. How to change the Brightness ? 1. Press MENU to activate the Toolbar 2.

  • Page 56: Sharpness

    6. Advanced 6. Use ↓ or ↑ to select Tint 7. Press ENTER On the screen appears now a sliderbox 8. Use ←or → , the numeric keys on the remote, or the keypad to change the Tint 6.4.1.5 Sharpness How to change the sharpness ? 1.

  • Page 57: Noise Reduction

    6. Advanced On the screen appears now a sliderbox Image 6-22 8. Use ←or → , the numeric keys on the remote, or the keypad to change the Phase 6.4.1.8 Noise reduction How to change the Noise reduction ? 1. Press MENU to activate the Toolbar 2.

  • Page 58: Possible Aspect Ratio Settings And Their Effect On Different Sources In The Iq

    6. Advanced • • 16:9 • • Auto The settings do not refer to the aspect ratio of the source ! Projector setting Source 16:9 16:9 2.35:1 16:9 anamorphic 2.35:1 anamorphic Image 6-25 Possible aspect ratio settings and their effect on different sources in the iQ. We can conclude that the thumb rule for DVD projection is to always leave the projector in 4:3 format except when dealing with anamorphic sources where the 16:9 setting allows the best reproduction.

  • Page 59: Show Native Resolution

    6. Advanced Image 6-26 4. Use ↑ or ↓ to select Aspect ratio 5. Use → open the Aspect ratio menu 6. Use ↑ or ↓ to select the desired ratio 7. Press ENTER to confirm The aspect ratio settings are greyed out in case the Show native resolution or the Full screen representation setting is enabled.
  • Page 60 6. Advanced What can be done ? The aim here is to always show the resolution of the source independently of the resolution of the LCD panels. This way better image reproduction is obtained since no up or down scaling is done on the source. Note that native resolution refers here to the source and does thus only have sense when handling data sources (greyed out for video sources).

  • Page 61: Keystone

    6. Advanced When show native resolution is ON and the resolution of the source is higher than the panel resolution , use the arrow keys to scroll through the image (pan). 6.4.4 Keystone What can be done ? The Keystone adjustment is used to align the image, this can be necessary when projecting under a non standard angle How to perform a Keystone correction ? 1.

  • Page 62: Color Temperature

    6. Advanced 6.4.5 Color temperature What can be done ? The color temperature can be selected according to the type of source: There are 4 different preset color temperatures: • Projector white • computer : 9300 K • Video : 6500 K •...

  • Page 63: Film To Video Conversion: 2/2 And 2/3 Pull Down Method

    6. Advanced NTSC VIDEO VIDEO PAL FILM 60 f/s 50f/s 24 f/s 1/30s 1/20s Image 6-35 film to video conversion: 2/2 and 2/3 pull down method Image 6-36 The filmmode detection insures that these converted signals are shown without artefacts, especially motion artefacts due to bad de-interlacing.

  • Page 64: White Peaking

    6. Advanced Image 6-37 7. Press ENTER A white bullet shows the active setting 6.4.7 White peaking White peaking White peaking function will allow you to adjust the “white level” of the colors i.e. increasing the white peaking will increase the overall brightness of the image.

  • Page 65: Dynacolor

    6. Advanced A slider box is displayed Image 6-39 6. Adjust the white peaking to the desired value 6.4.8 Dynacolor™ What can be done? DynaColor™ will eliminate channel-to-channel color variations. How to define color? The CIE chromaticity diagram is one way to plot the colors the human eye can see. Image 6-40 The CIE chromaticity diagram A projector can only reproduce a certain color gamut within this diagram.

  • Page 66: The Color Gamut Of Each Projector Will Differ

    6. Advanced Image 6-42 The color gamut of each projector will differ When working with a multichannel setup, these color differences between different projectors can be smoothed out by matching the color gamuts of the different projectors to a Common Color Gamut. Image 6-43 Common Color Gamut The Common Color Gamut...

  • Page 67: The Common Color Gamut

    6. Advanced Image 6-44 The Common Color Gamut Red projector 1 Red projector 2 Green Projector 1 Green Projector 2 Blue Projector 1 Blue Projector 2 W1 White Projector 1 W2 White Projector 2 Red Common Color Gamut Green Common Color Gamut Blue Common Color Gamut Cyan Common Color Gamut Magenta Common Color Gamut...
  • Page 68 6. Advanced Image 6-45 R59770134 ID LR-6 27/05/2011...
  • Page 69 6. Advanced The Dynacolor dialog box will be displayed. Image 6-46 5. Push the cursor key ← or → select enable/diasable and then ENTER. Dynacolor™ g (Light Output) Value The value g in the Dyancolor™ interface represents a relative light output. g=1 is the maximum available light output.
  • Page 70 6. Advanced Important ! In the projectors iD R600 and iD Pro R600 (R9010340 and R9010350) the measuring is done with white peaking = 0. In the projectors iD R600+ and iD Pro R600+(R9010341 and R9010351) however, the white peaking must be 10 during the measurement.
  • Page 71 6. Advanced Image 6-47 3. Assume the second projector has the following measured values. R59770134 ID LR-6 27/05/2011...
  • Page 72 6. Advanced Image 6-48 R59770134 ID LR-6 27/05/2011...

  • Page 73: Red Coordinates For Both Projectors

    6. Advanced 4. We start by setting both projectors to the common red coordinate. Tip: Draw a quick sketch of both gamuts as a graphical help. Image 6-49 Red coordinates for both projectors 5. Display the internal color bar pattern on both projectors. 6.

  • Page 74: Blanking

    7. Repeat step 5 to 6 for all coordinates on both projectors. Both projectors will now operate within the same color gamut. Another way to determine the new coordinates is to use the DynacolorTool (software tool running on a laptop or PC), contact Barco for more information. 6.4.9 Blanking Blanking in the Image menu The blanking in general allows to blank unwanted video information (noise in the top or bottom of the image).
  • Page 75 6. Advanced Δ G ΔΒ Δ R Black level Image 6-53 The objective of input balancing The objective in input balancing is to “set” the same black level and the same white level for the three colors of a particular input source.
  • Page 76 6. Advanced An alternative to a full screen White/black pattern is the standard gray scale pattern, the white bar will be used for white balance and the black bar for black balance. Image 6-55 It is not necessary to adjust the black balance. Its value is automatically set to an optimal value. Performing White input balance 1.

  • Page 77: Agc On Video

    6. Advanced 9. Adjust the blue white level (gain) on a minimal value Note: this minimal value is not necessary , provided that the 2 other colors are not influencing too much the color to be adjusted, in fact the aim is to minimize the effect of the two other colors since there is a risk of reaching too soon the transition (bright spots) due to the contribution of these two other colors signals.

  • Page 78: Manual Gain Control

    6. Advanced Image 6-58 The AGC can be disturbing in case of Macrovision encoded signals, therefore the AGC can be disabled (OFF) at any time 6.4.12 Manual Gain Control What can be done ? Beside the AGC there is the possibility to manually set the gain of the incoming video signal. When the AGC is enabled (ON), the manual setting does not affect the gain, AGC must therefore be disabled.

  • Page 79: Tools

    6. Advanced A scroll bar is displayed Image 6-60 6. Use ← or →, the numeric keys on the remote, or the keypad to change the gain so as to obtain homogene white parts in the image. Tools 6.5.1 Introduction to PiP PiP stands for "Picture in Picture"...

  • Page 80: Pip Select

    6. Advanced • PiP layout 1–3 These are factory layouts, they can be edited and saved. • Personal layouts Beside the 2 fixed layouts and the 3 factory layouts, one can set 5 additional (personal) layouts. PiP dedicated buttons • PiP Adjust : this button allows to focus on one particular window, this is shown with a white frame surrounding the selected window.

  • Page 81: Pip Add Window

    6. Advanced A white bullet shows the active layout Image 6-63 The PiP configuration can also be selected via the dedicated PiP key on the RCU. 6.5.3 PiP add window What can be done ? It is possible to add a window to the existing windows (maximum 4), therefore a source must be selected. Sources which are already used are non selectable.

  • Page 82: Pip Remove Window

    6. Advanced 6.5.4 PiP remove window How to remove a window ? 1. Press MENU to activate the Tool bar 2. Press → to select the Tools item 3. Press ↓ to Pull down the Tools menu 4. Use ↑ or ↓ to select PiP remove window 5.

  • Page 83: Pip Rename Layout

    6. Advanced If save as has been selected, a dialog box is displayed Image 6-67 Use ← or →, the numeric keys on the remote, or the keypad to enter the name and exit with BACK or MENU. If save as has been selected, a message box is displayed Image 6-68 6.5.5.2 PiP rename layout...

  • Page 84: Pip Delete Layout

    6. Advanced A dialog box is displayed Image 6-70 Use ← or →, the numeric keys on the remote, or the keypad to enter the name and exit with BACK or MENU. 6.5.5.3 PiP delete layout What can be done ? The non fixed layouts (factory and personal layouts) can be deleted.

  • Page 85: Color Keying

    6. Advanced This can also be done by using the dedicated PiP Adjust key on the RCU Image 6-72 PiP adjust in case of 2by2 layout Data1 window has the focus, new settings will only affect Data1 window Video1 window has the focus, new settings will only affect Video1 window PiP adjust 1.

  • Page 86: Diagnostics

    6. Advanced Image 6-74 Image 6-75 Image 6-73 Full color image Result image after color keying Zebra on a single color The color keying function is only relevant when in presence of the Pro version, although present in the stan- dard version.

  • Page 87: Background

    6. Advanced Image 6-76 7. Press ENTER A white bullet shows the active effect. The next source switching will be done using the selected effect The Random mode will select a new switching mode at each source switching i.e. there will never be 2 suc- cessive source switchings with the same effect.

  • Page 88: Lamp Management

    6. Advanced 7. Press ENTER The logo display is only possible in the full screen mode, a logo can thus not be displayed (rescaled) in a window in the PiP mode. When there is no signal connected, the projector will also start its standby timer countdown (if enabled) and shuts down after the predetermined time.

  • Page 89: Single Mode Operation: Switching Principle

    6. Advanced When the lamp fails or reaches its maximum runtime the projector switches automatically to the other lamp without interrupting the projection.The failure is logged and the lamp will never be initialized in the future. Image 6-80 Single mode operation: switching principle Dual mode Both lamps are working.

  • Page 90: History

    6. Advanced A bullet shows the active mode. When switching from the dual mode to the single mode the lamp with the longest runtime is switched off. If the runtimes are equal (if the projector has always been operated in dual mode) then lamp1 is switched out. When switching to single mode, returning to the dual mode will not be possible in the first 60 seconds, Dual in the menu is greyed out and LED1 is flickering, thereby preventing hot restrike which may damage the lamp.

  • Page 91: Image Files Menu

    6. Use ←or →, the numeric keys on the remote, or the keypad to change the runtime warning setting. ARNING Lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. Image files menu Overview •...

  • Page 92: Auto Image

    6. Advanced Image 6-86 5. Press ENTER A dialog box is displayed Image 6-87 6. Use ↑ or ↓ to select the desired file Tip: For more info about the available image files and the specifications see the Image files section. 7.

  • Page 93: Edit File

    6. Advanced The measure of the total number of pixels per line can be done through 2 methods • Limited scan: a windowing is used to allow fast tracking. The operation takes about 20 seconds (depending on file) • Full scan: tracking is done over the full range. The operation takes about 1.5 minutes (depending on file) How to launch Auto Image? 1.
  • Page 94 6. Advanced 2. Press → to select the Image files item 3. Press ↓ to Pull down the Image files menu 4. Use ↑ or ↓ to select Edit Image 6-90 5. Press ENTER A dialog box is displayed 6. Use ↑ or ↓ to select the desired file Note: If in PiP mode the cursor is placed by default on the active file which has the focus.

  • Page 95: Which Items Can Be Adjusted

    6. Advanced A dialog box is displayed Image 6-92 9. Use ←or →, the numeric keys on the remote, or the keypad to edit and change the values, confirm with ENTER Note: greyed out fields can not be updated (total pixels) Which items can be adjusted ? The following items can be adjusted : •...

  • Page 96: Advanced Data Settings

    6. Advanced video signal video signal frame blanking egalisation Image 6-94 AGC Hold interval The Comb filter is by default enabled. The AGC hold interval is the time interval in which the AGC is inhibited (AGC hold = no update in video amplitude measurement), the advanced parameter allows to choose a short or long hold interval.

  • Page 97: Rename File

    6. Advanced • a progressive signal (32 kHz frequency video signal ) is connected to the BNC’s (select the source with Data on BNC’s in the Source selection menu). • one wants (in PiP mode) to visualize the component video signal in a Data window hereby adding a video image in the PiP layout.

  • Page 98: Copy

    6. Advanced A text box is displayed Image 6-99 Use ←or →, ↓ or ↑ the numeric keys on the remote, or the keypad to edit and change the values, confirm with ENTER. 6.8.5 Copy How to copy a file ? 1.

  • Page 99: Delete

    6. Advanced If the AutoImage function does not succeed in finding a file and no file is loaded (load list is empty), which means that the source is not displayed, then use the copy function: Copy a standard file (.std) which is not too different of the source to display, then edit this file to get the best image.

  • Page 100: Display Setup

    6. Advanced 2. Press → to select the Image files item 3. Press ↓ to Pull down the Image files menu 4. Use ↑ or ↓ to select Forced file load 5. Press → to open the menu Image 6-105 6.

  • Page 101: Startup Screen

    6. Advanced 7. Press ENTER The full screen representation will not guarantee the best image quality, therefore the Show native resolution has to be selected. The show native resolution function on the other hand forces to use the native resolution of the source. The Full screen representation function overrules the show native resolution function.

  • Page 102: Take Screenshot

    6. Advanced 6.9.4 Take screenshot What can be done ? A screenshot can be taken from an active projected image. This screenshot is then saved in a 4 MB RAM and can be used as background. Each new screenshot erases the previous logo therefore a warning message is displayed asking the user to confirm. How to take a screenshot ? 1.

  • Page 103: Sliderbox Position

    6. Advanced 2. Press → to select the Display setup item 3. Press ↓ to Pull down the Display setup menu 4. Use ↑ or ↓ to select Status bar position 5. Press ENTER 6. Use ↑ or ↓ to position the status bar 6.9.7 Sliderbox position What can be done ?

  • Page 104: Blanking

    6. Advanced A dialog box is displayed. Image 6-111 6. Use the arrow keys to select the desired item and press ENTER to activate or disactivate the item. How to perform AutoImage ? 1. Press AutoImage on the RCU A textbox showing a progress bar is displayed. During the AUTOIMAGE measuring process the data source disappears temporarily (logo is displayed if back- ground is set to logo ) 6.9.9...

  • Page 105: Soft Edge

    6. Advanced Note that here the blanking is only done on the display i.e. the setting is not saved in the image file. in other words only one type of blanking (setting) can be done independently of the source. How to blank the image ? 1.

  • Page 106: Why Soft Edge

    6. Advanced Image 6-114 Why Soft Edge? What is the Basic Principal of Soft Edge? The principle of edge blending is achieved by linear modulation of the light output in the overlap zone so that the light output in that zone equals the light output of the rest of the image.

  • Page 107: Soft Edge Overlap Zone (Horizontal Soft Edge)

    6. Advanced 6.9.10.2 Soft Edge overlap zone (horizontal Soft Edge) Definitions Image 6-116 Scenergix set up Overlap : number of pixels that overlap Horizontal resolution of 1 projector : 1400 for SXGA+ projectors. Total horizontal screen resolution : [(horizontal resolution of 1 projector) x 2] minus overlap. Horizontal Resolution source : number of active pixels of the source.

  • Page 108: Width Selections

    6. Advanced 2. Press → to select the Display setup item. Image 6-117 3. Press ↓ to pull down the Display setup menu. 4. Use ↑ or ↓ to select Soft Edge. 5. Press → to select the Soft Edge item. 6.

  • Page 109: Black Level Of The Images

    6. Advanced Set first the width of the first projector and repeat for the second one. Image 6-119 Width set up for projector 1 Image 6-120 Width set up for projector 2 Adjusting by entering the exact values. 1. When on an adjustable item, the input box background will be colored. Press ENTER. The value will change to a 3 digit value and the first digit is selected.

  • Page 110: Installation

    6. Advanced How to adjust 1. Press MENU to activate the menu bar. 2. Press → to select the Display setup item. Image 6-121 3. Press ↓ to pull down the Display setup menu. 4. Use ↑ or ↓ to select Soft Edge. 5.

  • Page 111: Lens Adjustments

    6. Advanced 6.10.1 Lens adjustments What can be done ? Motorized lenses can be adjusted in the installation menu or via the dedicated keys on the remote. The following parameters can be adjusted: • Zoom • Focus • Shift (also for non motorized lenses) How to Zoom/focus or shift ? 1.
  • Page 112 6. Advanced How to activate the security mode ? 1. Press MENU to activate the Tool bar 2. Press → to select the installation item 3. Press ↓ to Pull down the menu 4. Use ↑ or ↓ to select Security Image 6-126 5.
  • Page 113 6. Advanced A dialog box is displayed Enter your name, company name,... (this information is displayed in the identification menu) Image 6-128 9. Press ACCEPT A dialog box is displayed. Enter the PIN code, and confirm it. Image 6-129 An informative text box is then displayed. Press ENTER or BACK to escape. Image 6-130 How to disable the security mode ? 1.

  • Page 114: Change Password

    6. Use ← or → , the numeric keys on the remote , or the keypad to enter and confirm the new password. Each character is displayed as an asterisk. The new password is accepted if the new password and the confirmed password coincide. If the password is forgotten contact a Barco authorized technician. R59770134 ID LR-6 27/05/2011...

  • Page 115: Table Overview

    7. Image files 7. IMAGE FILES Table overview Table overview The following standard image files are pre-programmed in the projector. Name Resolution Fvert FHor Fpix Ptot Pact Ltot Lact 1600_48V 1600x600i 48,040 62,500 135,000 2160 1600 640x200i 59,924 15.700 14.318 COMPUSC4 1024x480i 29,945...
  • Page 116 7. Image files Name Resolution Fvert FHor Fpix Ptot Pact Ltot Lact IQPC_XGA_2 1024x768 48,485 65,164 1344 1024 IQPC_XGA_D 1024x768 49,005 65,863 1344 1024 MAC_3 512x384 60,147 24,480 15,667 MAC_4 560_384 60,147 24,480 17,234 MAC_5 512x342 60,158 22,259 16,670 MAC_6 832x624 74,546 49,722...
  • Page 117 7. Image files Name Resolution Fvert FHor Fpix Ptot Pact Ltot Lact SUNXGA70 1024x768 70,041 56,596 74,250 1312 1024 SUNXGA77 1024x768 77,069 62,040 84,375 1360 1024 SUP_MAC 1024x768 60,000 48,780 63,999 1312 1024 SVGA_56V 800x600 56,250 35,156 36,000 1024 SVGA_60V 800x600 60,317 37,879...
  • Page 118 7. Image files Name Resolution Fvert FHor Fpix Ptot Pact Ltot Lact XGA_43 1024x384 35,500 44,872 1264 1024 XGA_60 1024x768 60,000 48,360 64,996 1344 1024 XGA_70_1 1024x768 70,000 56,475 74,999 1328 1024 XGA_70_2 1024x768 70,000 57,052 78,047 1368 1024 XGA_72 1024x768 71,955 58,140...

  • Page 119: Troubleshoot

    8. Troubleshoot 8. TROUBLESHOOT Using the OSD What can be done ? The projector bus allows the diagnostic of different hardware components divided in two main groups. • C diagnostics : a number of internal electronic boards can be diagnosed and a graphical interface shows whether an error is •...
  • Page 120 8. Troubleshoot A text box is displayed Image 8-3 For Barco certified service technicians only: For more information on possible hardware failures refer to the Service Manual. R59770134 ID LR-6 27/05/2011...

  • Page 121: Maintenance

    9. Maintenance 9. MAINTENANCE Cleaning the lens To minimize the possibility of damage to optical coatings, or scratches to lens surfaces, we have developed recommendations for cleaning. FIRST, we recommend you try to remove any material from the lens by blowing it off with clean, dry deionized air.

  • Page 122: Cleaning

    9. Maintenance Image 9-1 location of the filters lamp filter 1 lamp filter 2 x-cube filter input filter 9.2.2 Cleaning How to clean the dustfilters ? 1. Place the projector so as to access easily the filter to be cleaned 2.

  • Page 123: Input Filter Removal

    9. Maintenance Image 9-5 Input filter removal Image 9-6 Input filter removed 4. Clean the dust filter with a dry cloth. 5. Re-insert the dust filter by sliding it back in the filter housing. If the airflow is falling under a predetermined treshold value a warning will be displayed on the screen. Image 9-7 At that time it is strongly recommended to replace or clean the dustfilter under the X-cube.

  • Page 124: The Uhp Lamp

    The lamp runtime should only be reset when placing a new lamp. ARNING Lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. How to reset the lamp runtime in the iQ/iD ? 1.

  • Page 125: Removing The Lamp Unit(S)

    8. Use ←or →, the numeric keys on the remote, or the keypad to change the serial number of the lamp (serial number 0000000 will not be accepted). ARNING Lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. 9.3.2...

  • Page 126: Unlock The Lamp

    9. Maintenance Image 9-11 2. Pull the lamp locking handle to unlock the lamp Image 9-12 Unlock the lamp 3. Take out the lamp unit R59770134 ID LR-6 27/05/2011...

  • Page 127: Mounting The Lamp Unit(S)

    9. Maintenance Image 9-13 Image 9-14 Lamp removed 9.3.3 Mounting the lamp unit(s) What has to be done ? The lamp has to be mounted The lamp has to be connected. Perform the procedure for both lamps if both lamps have to be replaced. In this procedure lamp 1 is replaced, the procedure being the same for lamp 2.
  • Page 128 9. Maintenance AUTION Always insure that the lamp is well mounted, locked and in line with the optical frame. If the lamp is misaligned, this will cause damage (by UV radiation) to the optical frame ! In some projectors, the lamp mounting mechanism may be more tight . Handle always in a gentle way, never force the lamp locking mechanism, as this may misalign the lamp and damage the projector (see Caution above).

  • Page 129: Glossary

    Glossary GLOSSARY Automatic Gain Control: allows an automatic amplitude (gain) control of the incoming video signal CEE7/7 European power plug to connect the power cord to the wall outlet. Component Video In Component Video the term component describes a number of elements that are needed to make up the video picture, these components are PR/Y/PB.
  • Page 130 Glossary R59770134 ID LR-6 27/05/2011...

  • Page 131: Index

    Index INDEX address Gain 73–74 automatic control Address manual control Projector address General 44, 46–48 Adjustments audio lens Audio 46–47 advanced settings source selection setup Advanced identification Standby Timer Audio General menu connection freeze Auto Image pause AutoImage getting started Setup adjust automatic startup...
  • Page 132 Index Maintenance Packaging Menu 30–31, 33–34, 41, 49–53, 57–58, 73–80, 82–84, 86–87, Password 89, 93–99, 107, 110, 120 change password Image files menu 87, 89, 93–95 76–80 copy file add window delete file adjust edit file layout load file Layout 78–80 rename file delete...
  • Page 133 Index Composite Video manual gain control Unpacking S-Video Video 19–20, 73–74 White peaking R59770134 ID LR-6 27/05/2011...
  • Page 134 Index R59770134 ID LR-6 27/05/2011...

  • Page 135: List Of Images

    List of images LIST OF IMAGES location of the lens handle ................... 11 3-10 source input section with optional SDI layer.

This manual is also suitable for:

Id lr-6

Table of Contents
