LX-5_EN.book Page 1 Friday, July 4, 2008 9:35 AM
LX-5
Please study this instruction manual carefully before
starting to operate the unit, in order to use the unit correctly.
We take no responsibility for any problems resulting from
misuse of this unit by operating this equipment other than
instructed in this manual.
PROJECTOR

USER GUIDE

(lens is optional)
For Customer use :
Enter below the serial No. which is
located on the bottom side of the
cabinet. Retain this information for
future reference.
Model No. R9011221
Serial No.

Advertisement

Table of Contents
loading

Related Manuals for Barco D-ILA LX-5

Summary of Contents for Barco D-ILA LX-5

  • Page 1: User Guide

    LX-5_EN.book Page 1 Friday, July 4, 2008 9:35 AM PROJECTOR LX-5 USER GUIDE (lens is optional) For Customer use : Enter below the serial No. which is Please study this instruction manual carefully before located on the bottom side of the starting to operate the unit, in order to use the unit correctly.

  • Page 2: Getting Started

    CAUTION: immediately after moving from a low temperature to high temperature, as this causes condensation, which Changes or modification not approved by Barco may result in fire, electric shock, or other hazards. could void the user’s authority to operate the - Do not place this product on an unstable cart, stand, equipment.
  • Page 3 LX-5_EN.book Page 3 Friday, July 4, 2008 9:35 AM - The lens for this product is optional. Do not attach the - Do not look into the projection lens while the power cord when the lens is not attached. Turning on illumination lamp is turned on.

  • Page 4: Power Connection

    LX-5_EN.book Page 4 Friday, July 4, 2008 9:35 AM Getting Started Safety Precautions (Cont’d) IMPORTANT: The wires in the mains lead on this product are colored in accordance with the following cord: Green-and-yellow : Earth Blue : Neutral Brown : Live POWER CONNECTION As these colors may not correspond with the colored making identifying the terminals in your plug,...
  • Page 5 LX-5_EN.book Page 5 Friday, July 4, 2008 9:35 AM EMC Supplement - This equipment is in conformity with the provisions and protection requirements of the corresponding European Directives. This equipment is designed for professional projector appliances and can be used in the following environments. ●...

  • Page 6: Table Of Contents

    LX-5_EN.book Page 6 Friday, July 4, 2008 9:35 AM Getting Started Contents Operation and Settings Projecting Image ......28 Useful Features During Projection .

  • Page 7: Features

    LX-5_EN.book Page 7 Friday, July 4, 2008 9:35 AM Features User-friendly interface and high operability Equipped with DVI (Dual-Link) 4 input terminals Network-supported ● In addition to the conventional RS-232C, it also Ultra-high resolution, high contrast, provide support for connection using Ethernet. and high quality projector You can make adjustments or configure settings from the web browser on the PC without having to install...

  • Page 8: Check The Accessories/Optional Accessories

    ● Personal computers or computers are expressed as computers or PCs in this manual. For the EU market (3.3 m x 1) ● Contents of this manual are the copyright of Barco. All rights reserved. Unauthorized reproduction and duplication of this manual, in whole or in part, without the permission of Barco is strictly prohibited.

  • Page 9: Precautions During Use

    This product comes with replacement components required for maintaining the functions of this product, such as optical components, cooling fan and filters. The timing for replacing components varies considerably according to the frequency and environment of use. For details on replacement of components (except filters), please consult any nearby Barco servicing center.

  • Page 10: Names And Functions Of Parts

    LX-5_EN.book Page 10 Friday, July 4, 2008 9:35 AM Getting Started Names and Functions of Parts Front/Right Side Intake air Intake air Air Inlet/Filter Lens Mounting Bracket The air inlets absorb air to cool the interior of the Mount the optional projection lens. projector.
  • Page 11 LX-5_EN.book Page 11 Friday, July 4, 2008 9:35 AM Rear DVI 1 DVI 2 CONTROL Exhaust air DVI 3 STANDBY/ON OPERATE I/B LAMP DVI 4 WARNING RS-232C [DVI 1 to 4] Terminal [LAMP] Indicator This indicator lights up in yellow when the lamp time This is an input terminal for video signals.

  • Page 12: Connection And Installation

    LX-5_EN.book Page 12 Friday, July 4, 2008 9:35 AM Connection and Installation Installation Please read the following carefully when installing this unit. Optional projection lens Mount the optional projection lens (A Page 8). For details on mounting the lens, please consult your authorized dealer. Minimum Space Required Do not use a cover that may enclose this unit or block the air inlets/vent holes.

  • Page 13: Projector Installation Angle

    LX-5_EN.book Page 13 Friday, July 4, 2008 9:35 AM Installing the Projector Projector Installation Angle and Screen You can install this projector between 90 . Images will be properly displayed if the horizontal angle is between the range of It is recommended that this projector be installed at right angle to the screen.

  • Page 14: Installing The Projector

    LX-5_EN.book Page 14 Friday, July 4, 2008 9:35 AM Connection and Installation Movable Range of Projected Image Installing the Projector LXD (1.5 - 1.9) Zoom lens and Screen (Cont’d) Projected Image 100 % 50 % 50 % When shift amount in the right direction is +50 % Install the projector such that the center of the lens is aligned with the 1/4 position from the left edge of the...
  • Page 15 LX-5_EN.book Page 15 Friday, July 4, 2008 9:35 AM Overlaying projected images (when zoom When light passes through the glass of lens is in use) projection booth Projecting images by stacking projectors The lens shift feature enables you to use up to three stacked projectors at the same time.

  • Page 16: Screen Size And Projection Distance

    LX-5_EN.book Page 16 Friday, July 4, 2008 9:35 AM Connection and Installation Installing the Projector and Screen (Cont’d) Screen Size and Projection Distance Adjust the distance from the lens to the screen to achieve your desired screen size. LXD (1.5 - 1.9) Zoom lens Projection distance Projection Screen Size Image Width...
  • Page 17 LX-5_EN.book Page 17 Friday, July 4, 2008 9:35 AM LXD (1:1) Short focal length lens Projection Screen Size Image Width Projection distance (Diagonal Length) 50" (Approx. 1.27 m) 1.10 m 1.16 m 60" (Approx. 1.52 m) 1.31 m 1.41 m 70"...

  • Page 18: Connecting Video Signals Of The Computer

    LX-5_EN.book Page 18 Friday, July 4, 2008 9:35 AM Connection and Installation Connecting Video Signals of the Computer Connection During Single-Screen Mode Display The single-screen mode displays signals (up to four signals) from a computer as a single video image. To select to the single-screen mode, set “Display Mode”...
  • Page 19 LX-5_EN.book Page 19 Friday, July 4, 2008 9:35 AM Normal 2 Stripes DVI 1 DVI 1 DVI 3 4 Stripes Cross DVI 1 DVI 2 DVI 3 DVI 4 DVI 1 DVI 2 DVI 3 DVI 4 Connection During Single-Screen Mode Display Below is the connection example for four-channel signals from the computer.

  • Page 20: Connection During Two-Screen/Four-Screen Mode Display

    LX-5_EN.book Page 20 Friday, July 4, 2008 9:35 AM Connection and Installation Connecting Video Signals of the Computer (Cont’d) Connection During Two-Screen/Four- Screen Mode Display The two-screen/four-screen mode enables simultaneous display of signals from two or four computers. To select the two-screen mode, set “Display Mode” in the Setting menu to “Double”. To select the four-screen mode, set it to “Cross”.
  • Page 21 LX-5_EN.book Page 21 Friday, July 4, 2008 9:35 AM Connection Example During Two-Screen Mode Desktop Computer To DVI Terminal DVI 1 DVI-D Cable (Sold Separately) DVI 2 Laptop Computer CONTROL DVI 3 OPERATE I/B STANDBY/ON LAMP DVI 4 WARNING RS-232C To DVI Terminal Connection Example During Four-Screen Mode Desktop Computer...

  • Page 22: Network Settings

    LX-5_EN.book Page 22 Friday, July 4, 2008 9:35 AM Network Settings Connection Using a LAN Specifications of PC for Cable Controlling this Projector Windows XP Professional SP2 / Windows XP Home Edition SP2 Pentium3 1 GHz or higher Connect this projector, the computer for controlling this projector, and the switching hub using LAN cables, Memory 256 MB and above...

  • Page 23: Turning On The Main Power

    LX-5_EN.book Page 23 Friday, July 4, 2008 9:35 AM Turning On the Main Power Check to ensure that this projector, computer, and switching hub are properly connected Connect the power cord to the power input terminal of this projector CAUTION: Power Cord ●...

  • Page 24: Ip Address Settings

    LX-5_EN.book Page 24 Friday, July 4, 2008 9:35 AM Network Settings IP Address Settings Set the IP address for this projector. There are 2 methods to set the IP address. Assigning a static IP address Assigning an IP address from the DHCP Server Assigning a static IP address The IP Address Setting of this projector is set to Static IP (the DHCP client function is OFF) by default.
  • Page 25 LX-5_EN.book Page 25 Friday, July 4, 2008 9:35 AM Setting (Changing) the IP address of this Check if the Active scripting of the Internet projector Explorer is disabled A Click Tools and select Internet Options Launch the Internet Explorer on the B Click in the order of Security Trusted Sites computer...
  • Page 26 LX-5_EN.book Page 26 Friday, July 4, 2008 9:35 AM Network Settings IP Address Settings Click Network in the main menu (Cont’d) host PJ-1 user: root Logout Power Latest Error Main Image STANDBY Setting Signal Status Temperature Assigning a static IP address Convergence Rate(Hz) Pixel H...

  • Page 27: Assigning Ip Address From The Dhcp Server

    LX-5_EN.book Page 27 Friday, July 4, 2008 9:35 AM Using the Mail Delivery Assigning IP Address from the Feature DHCP Server The IP address is automatically assigned by the DHCP server. After connecting, turn on the main power. This feature enables delivery of mail (error message) to ●...

  • Page 28: Operation And Settings

    LX-5_EN.book Page 28 Friday, July 4, 2008 9:35 AM Operation and Settings Adjust the zoom ratio (screen size) (when Projecting Image zoom lens is in use) You can adjust the focus using the Zoom item of the Lens menu. host PJ-1 user: root If setting for this projector is not completed, refer to the Logout...

  • Page 29: Useful Features During Projection

    LX-5_EN.book Page 29 Friday, July 4, 2008 9:35 AM Adjust the focus Turn the main power at the rear of the projector unit to off [O] You can adjust the focus using the Focus item of the ● The [STANDBY/ON] indicator on the projector unit Lens menu.

  • Page 30: Main Menu

    LX-5_EN.book Page 30 Friday, July 4, 2008 9:35 AM Operation and Settings Setting Menu (Cont’d) After installation and connection are complete, perform the necessary adjustment and setting. Operate the menus using the computer’s browser to make adjustments and configure settings. Main Menu This menu displays the ON/OFF status of the power supply and information on signals input to the projector.
  • Page 31 LX-5_EN.book Page 31 Friday, July 4, 2008 9:35 AM Item Setting Value Description Power For turning the power ON/OFF. ON : Turns on the power. OFF : Turns off the power. NOTE: ● The following operating modes of the projector are displayed to the right of the OFF button.

  • Page 32: Image Menu

    LX-5_EN.book Page 32 Friday, July 4, 2008 9:35 AM Operation and Settings Setting Menu (Cont’d) Image Menu This menu is used for adjusting the picture quality. host PJ-1 user: root Logout Brightness Main Image Setting Green Convergence Blue Lens Option Contrast Network Mail...

  • Page 33: Setting Menu

    LX-5_EN.book Page 33 Friday, July 4, 2008 9:35 AM Setting Menu This menu is used for specifying the input level of the terminal and the display mode. host PJ-1 user: root Logout Input Level Main Standard Enhanced Image Setting Display Mode Convergence Lens Option...

  • Page 34: Convergence Menu

    LX-5_EN.book Page 34 Friday, July 4, 2008 9:35 AM Operation and Settings Setting Menu (Cont’d) Convergence Menu This menu is used for correcting color shifts in the optical system. host PJ-1 user: root Logout Blue Main Image Setting Convergence Lens Option Network Mail...

  • Page 35: Lens Menu

    LX-5_EN.book Page 35 Friday, July 4, 2008 9:35 AM Lens Menu This menu is used for adjusting the projection lens. host PJ-1 user: root Logout Zoom Focus Shift Main Image Setting Convergence Lens Option Network Mail Item Setting Value Description Zoom —...

  • Page 36: Option Menu

    LX-5_EN.book Page 36 Friday, July 4, 2008 9:35 AM Operation and Settings Setting Menu (Cont’d) Option Menu This menu is used for specifying settings for flipping images and screen displays. host PJ-1 user: root Logout Flip Main Horz. Vert. Image Setting Lamp Power Convergence...

  • Page 37: Network Menu

    LX-5_EN.book Page 37 Friday, July 4, 2008 9:35 AM Network Menu For configuring the network settings. host PJ-1 user: root Logout Host Name Setting Main Host Name LZZZZZZZ Image Setting IP Address Setting Convergence DHCP Client DHCP Static IP Lens IP Address 192.168.0.2 Option...

  • Page 38: Mail Menu

    LX-5_EN.book Page 38 Friday, July 4, 2008 9:35 AM Operation and Settings Setting Menu (Cont’d) Mail Menu This menu is for configuring the mail settings, which sends out an error message to the computer of the preset address when error occurs on this projector. host PJ-1 user: root Logout...
  • Page 39 LX-5_EN.book Page 39 Friday, July 4, 2008 9:35 AM indicates the factory default Item Setting Value Description E-Mail Setting For configuring the e-mail feature. E-Mail : Use the mail feature. : Do not use the mail feature. E-Mail — For specifying the destination e-mail address. Address (Default Value: user@localhost) NOTE:...

  • Page 40: Rs-232C Interface

    LX-5_EN.book Page 40 Friday, July 4, 2008 9:35 AM Operation and Settings RS-232C Interface You can control this projector by connecting the computer to this unit using a RS-232C cross cable (D-sub 9 pins). The commands to control this unit and the response data format against the received commands are explained here. For details, please consult your authorized dealer.
  • Page 41 LX-5_EN.book Page 41 Friday, July 4, 2008 9:35 AM Parameters used for the data format The following 2 types of parameters are used for command and response data: (1) ON/OFF (2) Special Parameter Each parameter is as follows: (1) ON/OFF Shows the status (ON or OFF) of the unit, such as POWER and HIDE.

  • Page 42: Others

    LX-5_EN.book Page 42 Friday, July 4, 2008 9:35 AM Others Maintenance Turn off the power of the projector unit, and unplug the power cord when cleaning or replacing the filter. Cleaning and Replacing the Filter Clean the filter regularly. If the filter is soiled, air intake efficiency may deteriorate, thus resulting in malfunction of the product. Replace with a new one if the filter fails to remove dust thoroughly or if it is damaged.

  • Page 43: Routine Servicing

    LX-5_EN.book Page 43 Friday, July 4, 2008 9:35 AM Remove the filter cover Routine Servicing The filter is located at the front and side of the projector unit. Clean dirt on the cabinet Remove the sponge and filter Do this with a soft cloth. In case of heavy soiling, soak a Hold the center of the filter using your fingers, and pull cloth in neutral detergent diluted with water, wring dry the filter toward you to remove it.

  • Page 44: Troubleshooting

    LX-5_EN.book Page 44 Friday, July 4, 2008 9:35 AM Others ● Device noise is heard from the interior of the projector Troubleshooting ● There is color bleeding on the screen When the projector fails to run properly due to external noises, perform the following operations. Check to ensure that the power is shut down.
  • Page 45 LX-5_EN.book Page 45 Friday, July 4, 2008 9:35 AM Symptom Probable Cause Corrective Action Reference Page ● Is the brightness level properly ● Adjust accordingly using Brightness A Page 32 Image is unusually dark adjusted? of the Image menu. A Page 36 or bright ●...

  • Page 46: What To Do When These Messages Are Displayed

    LX-5_EN.book Page 46 Friday, July 4, 2008 9:35 AM Others What to do when these messages are displayed Messages are displayed when the lamp life has expired and when there is input of signals that cannot be used. Message Lamp Time Over Message Cause (Details) ●...

  • Page 47: Warnings Using Indicators

    LX-5_EN.book Page 47 Friday, July 4, 2008 9:35 AM Warnings Using Indicators The lamp time and warning mode are indicated using the indicator. For details on indicator displays during normal operation, refer to the note below. Indicator Description STANDBY/ON LAMP WARNING About time to replace lamp (Lamp time has exceeded 1400 hours)

  • Page 48: Latest Error

    LX-5_EN.book Page 48 Friday, July 4, 2008 9:35 AM Others Latest Error The latest error number appears in the Main Menu when an error occurs in the projector. Error details are as follows: Error Number Meaning The lamp does not turn on. Accumulated lamp time has exceeded 1500 hours.

  • Page 49: Specifications

    LX-5_EN.book Page 49 Friday, July 4, 2008 9:35 AM DVI clock to 165 MHz (Single) Specifications (Rx clock) to 330 MHz (Dual) Display resolution 4096 2400 Terminal Video input DVI-D (dual link) 24 pins (supports 12-bit extended input) General (supports HDCP Power supply AC 110 V to 120 V, RJ45...
  • Page 50 LX-5_EN.book Page 50 Friday, July 4, 2008 9:35 AM Others Specifications (Cont’d) Pin Assignment RS-232C Terminal Pin No. Signal Operation Signal Direction This Projector  PC Incoming Data Outgoing Data This Projector Signal Ground 1,4,6 to 9 DVI-D Terminal Pin No. Signal Pin No.

  • Page 51: Dimensional Outline Drawing

    LX-5_EN.book Page 51 Friday, July 4, 2008 9:35 AM Dimensional Outline Drawing (Unit: mm) Side 827 (Including the optional projection lens) M10 hole (x 12) Tightening depth: 10 to 20 (Projection lens is optional) Front Rear Center of lens DVI 1 DVI 2 CONTROL DVI 3...
  • Page 52 LX-5_EN.book Page 52 Friday, July 4, 2008 9:35 AM © 2008 Barco Presentation and Simulation...
