Switch Chassis

Switch Backplane

S 7700 C
WITCH
The chapter describes the following Switch 7700 components:
Switch Chassis
■
Switch Backplane
■
Fabric Module
■
Fabric 32 Submodules
■
I/O Modules
■
Power Module
■
Fan Assembly
■
Switch 7700 Specifications
■
Switch 7700 Software Features
■
There are three Switch 7700 Models, the 4-Slot, 7-Slot, and the 8-Slot. Table 3 lists
the hardware features of each model.
Table 3 Hardware Features of the Switch 7700 Models
4-Slot Chassis
Fabric slots 1
I/O module slots 3
Fan slot 1
AC Power module 2
slots
The Switch 7700 backplane is part of the integrated chassis and delivers
high-speed data transfer between the Fabric and I/O modules. The backplane
bandwidth capacity is 120 Gbps.
The backplane supports the following functions:
Interconnection of signals between modules
■
Provides communication channels
■
Hot swapping for modules
■
Auto-recognition of slots
■
Distribution of power and management of the power supply for the system
■
OMPONENTS
7-Slot Chassis
1
6
1
3
8-Slot Chassis
2
6
1
3
