Submodule Slot; Reset Button; Fixed Ports - 3Com 7700R - Switch Starter Kit Installation Manual

Table 4 lists Fabric specifications.
Table 4 Fabric Specifications
Item
Bandwidth
CPU
BootROM
SDRAM
Flash

Submodule slot

Dimensions (L x W) 366.7 mm x 340 mm (14.5 x 13.5 in)
External ports
Maximum power
consumption
Submodule Slot The submodule slot in the Fabric 32 offers extended Ethernet capacity using the
following submodules:
■
■
For more information on these submodules, see "Fabric 32 Submodules"on
page 13.

Reset Button

The reset button resets the entire system.

Fixed Ports

The Switch 7700 Fabric module provides the following fixed ports:
■
■
Console Port
The console port is connected to the configuration terminal using an RJ-45
connector. You can use the console port for system debugging, configuration,
maintenance, management, and loading application files.
The console port can also be connected to a modem for functions such as remote
system debugging, configuration, maintenance, and management. You can
configure the baud rate on the console port.
Table 5 lists console port specifications.
Table 5 Console Port Specifications
Specification
Port connector
Port standard
Fabric 64 (3C16857 or 3C16857R) Fabric 32 (3C16872)
64 Gbps
MPC8260 200 Mhz
1 MB
256 MB
16 MB
One console port that supports local and remote dial-up configuration
management of the switch.
One 10BASE-T/100BASE-TX port for upgrade and network management
80 W
4-port 1000BASE-X-GBIC submodule
4-port 10/100/1000BASE-T submodule
Console Port
Ethernet Port
32 Gbps
70 W (with submodule)
Description
RJ-45
Asynchronous EIA/TIA-232
Fabric Module
