Troubleshooting The Fan; Troubleshooting The Modules - 3Com 7700R - Switch Starter Kit Installation Manual

62 C 6: T
HAPTER ROUBLESHOOTING
Troubleshooting the
Fan
Troubleshooting the
Modules
Table 37 describes power LEDs on the Fabric. (continued)
Table 37 Power LEDs on the Fabric
LED
OK
FAIL
If the fan OK LED is off, check that:
The fan has been installed in the correct position for normal communication
■
with the backplane.
Every heat dissipation fan is working normally.
■
There is nothing blocking the vent of the chassis.
■
The blanking plates are installed on the chassis where no module is inserted.
■
Table 38 describes fan LEDs on the Fabric. (continued)
Table 38 Fan LEDs on the Fabric
LED
OK
FAIL
The Fabric and I/O module LEDs show the status of the FABRIC and the I/O
modules, as described in Table 39.
If the LED ALM of the module remains green or green flashing, it indicates
■
there is something wrong with the module.
During the process of resetting the module, the ALM LED remains on. After
■
normal booting, it is off.
When resetting the module, if the ALM LED remains off, the module may not
■
be connected to the power source. Check that the module has been properly
installed in the correct position. (continued)
Table 39 Module LEDs on the Fabric
LED
RUN
ALM
Status Description
On — The power is working normally.
Off — The power has failed or has not been installed.
On — The power has failed.
Off — The power is working normally or has not been installed.
Status Description
On — The fan is working normally.
Off — The fan has failed or has not been installed.
On — The fan has failed.
Off — The fan is working or has not been installed
Status Description
Green/Off — The module has failed or has not been inserted.
Green flashing — The module is working normally.
Off — The module is working or has not been inserted.
Green or green flashing— The module has failed.
