24309E—March 2002
10

Pin Descriptions

10.1

Pin Diagram and Pin Name Abbreviations

Chapter 10
Preliminary Information
Figure 14 on page 52 shows the staggered Pin Grid Array (PGA)
for the AMD Athlon™ XP processor model 6. Because some of
the pin names are too long t o fit in the g rid, they are
abbreviated. Figure 15 on page 53 shows the bottomside view of
the array. Table 19 on page 54 lists all the pins in alphabetical
order by pin name, along with the abbreviation where
necessary.
Pin Descriptions
AMD Athlon™ XP Processor Model 6 Data Sheet
51
