24309E—March 2002
3
Logic Symbol Diagram
Data
Probe/SysCMD
Request
Power
Management
and Initialization
Figure 2. Logic Symbol Diagram
Chapter 3
Preliminary Information
Figure 2 is the logic symbol diagram of the processor. This
diagram shows the logical grouping of the input and output
signals.
Clock
SYSCLK
SDATA[63:0]#
SDATAINCLK[3:0]#
SDATAOUTCLK[3:0]#
SDATAINVALID#
SDATAOUTVALID#
SFILLVALID#
AMD Athlon™ XP
SADDIN[14:2]#
SADDINCLK#
Processor Model 6
SADDOUT[14:2]#
SADDOUTCLK#
PROCRDY
CLKFWDRST
CONNECT
STPCLK#
RESET#
Logic Symbol Diagram
AMD Athlon™ XP Processor Model 6 Data Sheet
SYSCLK#
VID[4:0]
COREFB
COREFB#
PWROK
FID[3:0]
FERR
IGNNE#
INIT#
INTR
NMI
A20M#
SMI#
FLUSH#
THERMDA
THERMDC
PICCLK
PICD[1:0]
Voltage
Control
Frequency
Control
Legacy
Thermal
Diode
APIC
7
