Supported SFPs and HBAs

Use only SFPs that are tested and supported. For the most up to date list of
supported SFPs and HBAs for the switch, refer to the product interoperability matrix
at the IBM SAN Support web pages at: http://www.ibm.com/servers/storage/support/
san

System specifications

Table 17 lists the system specifications for the switch.
Table 16. Switch power supply specifications (continued)
Specification
System power consumption
Input voltage
Input line frequency
BTU rating
Inrush current
Table 17. General specifications
Specification
Autoconfiguring port types
System architecture
System processor
ANSI Fibre Channel protocol
Modes of operation
Fabric initialization
FC-IP (IP over Fibre Channel)
Aggregate switch I/O bandwidth
Port-to-port latency
Value
84 watts nominal, 91 watts maximum
85 - 264 VAC, universal
47 - 63 Hz
406 BTU/hr
15 Amps to 35 Amps Maximum
Descriptions
E_Port, F_Port, FL_Port, M_Port, and
EX_Port
Nonblocking shared-memory switch
IBM PowerPC 440EPx, 667 MHz CPU
FC-PH (Fibre Channel Physical and
Signalling Interface standard)
Fibre Channel Class 2, Class 3, Class F
Complies with FC-SW-3 Rev. 6.6
Complies with FC-IP 2.3 of FCA profile
640 Gbps if all 40 ports are running at 8
Gbps, full duplex
700 nanoseconds
Appendix. Product specifications
