Removing SFP modules

To remove an SFP:
1. Press and hold the cable release B , as shown in section 1 of Figure 12 on
2. Remove the cable from the SFP, as shown in section 2.
3. Pull the bail (wire handle) D in section 3 to release the SFP.
4. Grasping it by the bail, gently but firmly pull the SFP ( C in section 4) out of the
5. Repeat this procedure for the remaining ports, as required.
28
SAN40B-4 Installation, Service, and User's Guide
Item
C
page 29
port.
Attention: If the SFP you are removing does not have a bail, use a small
implement such as a screwdriver to press the release trigger beneath the port.
Non-bailed SFPs can be damaged by the removal process and are not
recommended. Refer to the interoperability matrix at the following web site:
www.ibm.com/servers/storage/support/san for a list of supported SFPs and
devices.
Description
Closed bale
