Page 1 IBM Storage Networking SAN256B-7 MTM Service information: 8961-F74 Installation, Service, and User Guide SC28-3149-00...
Page 2 “Notices” on page 215. Copyright © Portions Copyright 2020 Broadcom, Inc. All Rights Reserved. © Copyright International Business Machines Corporation 2020. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
Page 3 Rack relocation (19" rack)........................xxi Product recycling and disposal........................ xxii About this document..................xxiii Product documentation........................... xxiii Brocade documents..........................xxiii IBM and Brocade product matrix......................xxiii Chapter 1. Device overview..................1 Hardware components..........................2 Port-side view of the device........................3 Port-side slot numbering..........................4 Nonport-side view of the device .........................4...
Page 4 Assembling the rack hardware......................33 Installing the device in the rack......................35 Installing the 8U chassis 27-31-inch rail rack lit for four-post racks............36 Time and Items Required........................36 Parts List............................... 37 Assembling the Rack Hardware......................37 Installing the Device in the Rack......................39 Chapter 4.
Page 5 chassisShow............................97 errDump and errShow........................100 fanShow..............................100 haShow............................... 100 historyShow............................101 psShow............................... 102 sensorShow............................102 sfpShow.............................. 102 slotShow............................. 104 switchShow............................105 supportSave............................105 tempShow............................107 Running diagnostic tests......................... 107 Chapter 7. Port and extension blades..............109 FC32-X7-48 port blade overview......................109 FC32-X7-48 port blade numbering and trunking................109 FC64-48 port blade overview........................110 FC64-48 port blade numbering and trunking...................
Page 6 Chapter 10. WWN card..................145 WWN card location and numbering......................145 Precautions specific to WWN cards......................146 WWN card fault indicators........................146 WWN card replacement task guide......................147 Time and items required for replacement....................147 Using the wwnrecover utility........................148 Preparing for WWN card replacement....................149 Hot-swap replacement..........................150 Cold-swap replacement..........................
Page 7 Time and items required......................... 178 Preparing for replacement........................178 Recording critical device and SAN information.................179 Disconnecting from the network and fabric..................182 Removing components from the chassis....................183 Installing the replacement chassis......................183 Installing components into the chassis....................184 Synchronizing airflow direction on WWN cards..................185 Downloading the configuration.......................
Page 8 viii...
Page 9 Figures 1. Port Side of the SAN256B-7 Director (Example Configuration)..............3 2. Nonport Side of the SAN256B-7 Director (Example Configuration)............5 3. Airflow Diversion and Port-Side Exhaust Kit Assembly for 18-24 in. (45.72 to 60.96 cm) Racks... 18 4. Clip and Retainer Nut Locations on Rack Rails...................19 5.
Page 10 24. Using Clip Nuts and Retainer Nuts to Secure Screws to Rack Rails............39 25. Installing a Chassis into the Equipment Rack ..................40 26. Chassis Installed in Equipment Rack ...................... 41 27. QSFP to QSFP Standard Cables........................ 63 28. QSFP to SFP Breakout/Cables........................63 29.
Page 11 49. Fan Assembly LEDs........................... 95 50. FC32-X7-48 Blade Port Numbering....................... 109 51. FC64-48 Blade Port Numbering......................111 52. FC32-64 Blade Port Numbering......................112 53. SX6 Extension Blade Port Numbering....................115 54. Removing and Replacing a Port or Extension Blade................118 55. CR64-4 Core Routing Blade Port Numbering..................121 56.
Page 12 74. Removing and Installing a Fan Assembly....................167 75. Removing and Installing the Blade Filler Panel in an SAN256B-7 Director......... 170 76. Removing and Installing the Blade Filler Panel on an X7-4 Director............ 171 77. Cable Management Fingers Installed on Rack Uprights on an SAN256B-7 Director......173 78.
Page 13 Tables 1. Brocade and IBM product and model number matrix................xxiii 2. Facility Requirements ...........................8 3. Installation Tasks, Time, and Items Required ..................10 4. Installation Prerequisites..........................12 5. Installation and Basic System Configuration .................... 13 6. Hardware for Airflow Diversion and Port-Side Exhaust Kit for 18-24 in. (45.72 to 60.96 cm) Racks..17 7.
Page 14 24. AC Power Supply LED Descriptions ......................93 25. HVAC/HVDC Power Supply LED Descriptions ..................94 26. Fan Assembly LED Descriptions ......................95 27. Port Groups for Configuring Trunks......................110 28. Port Groups for Configuring Trunks......................111 29. Port Groups for Configuring Trunks......................113 30.
Page 15 Search for the product Machine type or product name. For Fabric OS Release Notes and access to Fabric OS firmware downloads, go to the IBM Support Portal www.ibm.com/supportportal. Search for the product Machine type or product name, and then follow links for Downloads.
Page 16 Vendor software This product includes certain vendor software that is not covered under the IBM license agreement. IBM makes no representation about the accessibility features of these products. Contact the vendor for the accessibility information about its products. Related accessibility information You can view the publications for this product in Adobe Portable Document Format (PDF) using the Adobe Acrobat Reader.
Page 17 Safety Notices publication that is shipped with this product. The following notices and statements are used in IBM documents. They are listed below in order of increasing severity of potential hazards. Follow the links for more detailed descriptions and examples of the danger, caution, and attention notices in the sections that follow.
Page 18 A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to you. Safety labels are also attached directly to products to warn of these conditions or situations. xviii IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 19 General Dangers DANGER: The procedures in this manual are for qualified service personnel. Dangers Related to Equipment Weight DANGER: Use safe lifting practices when moving the product. DANGER: Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over.
Page 20 • Wear a wrist grounding strap connected to chassis ground (if the switch is plugged in) or a bench ground. Note: For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. • Store ESD-sensitive components in antistatic packaging xx IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 21 Rack safety Rack installation DANGER: Observe the following precautions when working on or around your IT rack system: • Heavy equipment—personal injury or equipment damage might result if mishandled. • Always lower the leveling pads on the rack cabinet. • Always install stabilizer brackets on the rack cabinet. •...
Page 22 (R002) Product recycling and disposal Refer to the IBM Systems Environmental Notices and User Guide (Z125-5823) for translated environmental statements and information regarding product recycling and disposal. This document may be provided either in printed version or on the product documentation CD. A more current version may be available through this link ftp://public.dhe.ibm.com/systems/support/warranty/envnotices/...
Page 23 Brocade products. Table 1 on page xxiii provides a product matrix to correlate the Brocade products and models to the IBM product names and machine types and model numbers. Products withdrawn from marketing are not listed.
Page 24 Brocade 7800 IBM System Storage SAN06B-R 2498 Model R06 Brocade 7840 IBM System Storage SAN42B-R 2498 Model R42 Brocade 300 IBM System Storage SAN24B-4 2498 Models B24 and 24E xxiv IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 25 Chapter 1. Device overview The IBM SAN256B-7 offers the following features and capabilities • Redundant and hot-swappable SFP+, SFP28, QSFP+, and Gen 7 QSFP transceivers; port, extension, control processor (CP), and core routing (CR) blades; power supply assemblies, fan assemblies, and WWN cards that enable a high-availability platform and allow nondisruptive software upgrades for mission-critical SAN applications.
Page 26 – Two World Wide Name (WWN) cards located on the nonport side of the device behind the WWN card bezel. 2 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 27 – Port blades use small form-factor pluggable (SFP+, QSFP+, and QSFP28) optical transceivers. For details on supported transceivers per blade type, see “Supported transceivers and cables” on page – Core routing blades use QSFP56 optical transceivers. For a list of supported transceivers for these blades, see “Supported transceivers and cables”...
Page 28 The following figure shows the nonport-side view of the SAN256B-7 Director with all fan and power supply assemblies installed. 1. WWN Bezel (logo plate - WWN cards Behind) 2. Power Supply Assembly 3. Fan Assembly 4. 2AWG Panduit LCD2-14AF Lug for Building Ground Connection 4 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 29 Figure 2. Nonport Side of the SAN256B-7 Director (Example Configuration) 1. WWN Bezel (logo plate - WWN cards behind) 2. Power Supply Assembly 3. Fan Assembly 4. 2AWG Panduit LCD2-14AF Lug for Building Ground Connection Depending on the fans and the power supplies installed, airflow can be from the port side to the nonport side or from the nonport side to the port side of the chassis through the side air vent.
Page 30 6 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 32 Ensure that the air intake and exhaust vents have a minimum of 5.1 cm (2 in.) of air space. Ensure that the air intake temperature is less than 40°C (104°F) during operation. 8 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 33 Table 2. Facility Requirements (continued) Type Requirements Rack (when rack- Ensure that the following airflow requirements are met: mounted) • Plan to install the device with the air-intake side facing the cool-air aisle. The device can be installed facing either direction if serviceability and cooling requirements are met.
Page 34 Verifying and backing up the configuration. Installing transceivers as 20–30 minutes SFP+, QSFP28, or QSFP56 needed. optical transceivers as needed. Attaching fiber-optic cables, 2–3 hours cable ties, and cable guides. 10 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 35 Flash Drive • PNY Attache 3.0 4 USB 16GB Flash Drive These drives are not orderable from IBM but are generically- branded and can be purchased from other suppliers. Shipped items When unpacking the device, follow procedures under “Unpacking and transporting the device” on page 16.
Page 36 The initial setup includes mounting the device on a flat surface or in a rack and completing the configuration tasks necessary to bring the device online and verify the operation. 12 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 37 Table 5. Installation and Basic System Configuration Task Task Details or Additional Information Complet Install blades or power supply Install any blades or power supply assemblies that have shipped assemblies. separately from the chassis. Be sure to use a No.1 Phillips screwdriver for captive screws to lock these FRUs into place.
Page 38 Optional: Power off the devices. Enter the shutdowncommand and wait for the device to power down, and then unplug the power cords. See “Powering down the chassis” on page 58 for more information. 14 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 39 “Facility requirements” on page 8 are met. Note: The preceding rack mount kits are supported for these devices on the publication date of this guide. For current support information, contact IBM Support. Mounting precautions The following precautions specifically apply to mounting the device.
Page 40 These kits have a different function, depending on the device being installed in the rack and the airflow direction provided by fans and power supplies installed in the device. 16 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 41 Observe the following when mounting this device: • Installing this rack mount kit with an 8U chassis requires 9U of rack space. • Before mounting your device, review any specific installation and facility requirements in the Hardware Installation Guide for the device. •...
Page 42 9. 6 32 x .25 in. (.635 cm) Phillips Screw 10. Top rail mounting brackets for 18–20 in., (45.72–50.8 cm) 20–22-in. (50.8–55.88 cm), and 22–24.in (55.88-60.96 cm) racks 11. Shelf Saddle 18 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 43 Torque Requirements Use the following torque settings when tightening screws that secure the rack mount kit and device to the rack. Table 7. Torque Requirements for Mounting Screws Screw Size Torque 6-32 x .25 in. (.635 cm) Phillips screw 10 cm-kg (8.75 in.-lb) 10-32 x .63 in.
Page 44 4. Place the shelf (see the following figure) on the saddle then secure it to the rack rails using four 10-32 screws with washers shown in the following figure. Tighten the screws according to specifications under “Torque Requirements” on page 19. 20 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 45 a. Shelf b. 10-32 x .63 in.(1.60 cm) Phillips Screw with Washers Figure 6. Shelf Installed in Rack Note: For rails with round holes, use the clip nuts on the front rails for securing 10-32 screws. For rails with square holes, use the retainer nuts. 5.
Page 46 For rails with square holes, use the two standard 10-32 screws with blue Loctite on the threads and alignment washers on each end of the top rail assembly. Tighten the screws according to specifications under “Torque Requirements” on page 19. 22 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 47 1) Top Rail 2) Duct 3) 6-32 x .25 in. (.635 cm) Phillips Screws 4) 10-32 x .5 in. (1.27 cm) Phillips screws with blue Loctite on threads and alignment washers or 10-32 x .63 in.(1.60 cm) Phillips screw with square cone washer Figure 8.
Page 48 Table 8. Hardware for Airflow Diversion and Port-Side Exhaust Kit for 68.58 to 78.74 cm (27-31 in.) Racks Description Quantity Top rail Duct Shelf 10-32 x .5 in. (1.27 cm) Phillips Screw (blue Loctite on threads) 24 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 49 Table 8. Hardware for Airflow Diversion and Port-Side Exhaust Kit for 68.58 to 78.74 cm (27-31 in.) Racks (continued) Description Quantity 10-32 x .63 in.(1.60 cm) Phillips Screw with square cone washer 10-32 clip nut for racks that have rails with round holes 10-32 retainer nut for racks that have rails with square holes Alignment washer for racks that have rails with square holes 6-32 x .25 in.
Page 50 Note that the following figure shows relative positions for these nuts in the rack rails to mount the shelf and device. You may mount the shelf and device in 9U of rack space higher or lower in the rack than shown. 26 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 51 Figure 11. Clip and Retainer Nut Locations on Rack Rails 3. Install the shelf as shown in the following figure. a) The shelf can be adjusted to a length of between 68.58 and 78.74 cm (27 and 31 in.) to accommodate your rack size.
Page 52 6-32 screws, one screw on each side of the air duct assembly. Tighten the screws according to specifications under “Torque requirements” on page 26. 28 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 53 Figure 14. Securing Top Rail in Rack 6. Secure the top rail assembly to the rack with four 10-32 screws, two screws on each end of the top rail assembly. • For rails with round holes, use two 10-32 screws with washers on each end of the top rail assembly. Tighten the screws according to specifications under “Torque requirements”...
Page 54 “Torque requirements” on page 26. Note: Screws, clip nuts, and retainer nuts to secure the device to the rack are provided in the device hardware accessory kit. 30 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 55 Figure 15. Device and 27–31 in. (68.58 to 78.74 cm) Kit Installed in Rack Note: For rails with round holes, use the clip nuts on the rails for securing the 10-32 screws. For rails with square holes, use the retainer nuts. 6.
Page 56 4. 10-32 x .63 in.(1.60 cm) Phillips Screws with Square Cone Washer (for racks that have rails with round holes) 5. 10-32 Clip Nuts (for racks that have rails with round holes) 6. 10-32 Retainer Nuts (for racks that have rails with square holes) 32 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 57 7. Bracket Adjusting Screws Assembling the rack hardware Procedure 1. Loosen the two 10-32 adjusting screws securing each mid-mount bracket to the saddle (see the previous figure) and slide the brackets as far backward as possible. 2. Install the saddle to the equipment rack rails using the following steps while referring to the following figure.
Page 58 Refer to the following figure. Note: The following figure shows mounting brackets from XBR-DCX4S-0126. Mounting brackets from the XBR-X64-0126 kit install the same way. Figure 19. Telco Mid-Mount Brackets Installation 34 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 59 Installing the device in the rack About this task DANGER: Use safe lifting practices when moving the product. Procedure 1. Ensure that the door is removed from the port side of the device if installed. Refer to procedures for removing and replacing the device door in this guide. 2.
Page 60 • Hardware devices illustrated in these procedures are only for reference and may not depict the device you are installing into the rack. Time and Items Required Allow approximately one hour to unpack and install a device in a rack. 36 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 61 The following tools are required to install the 8U Chassis 27-31 Inch Rail Rack Kit for Four-Post Racks. • Torque wrench with No. 2 Phillips screwdriver tip • Flathead screwdriver • Hydraulic or assisted lift with a minimum raise of 140 cm (55 in.) and a minimum capacity of 113 kg (250 lbs).
Page 62 Note: For rails with round holes, use the clip nuts on the rack rails for securing 10-32 x .63 in. screws. For rails with square holes, use the retainer nuts. See the following figure. 38 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 63 Figure 24. Using Clip Nuts and Retainer Nuts to Secure Screws to Rack Rails Installing the Device in the Rack Procedure 1. Ensure that the door is removed from the port side of the device if it is installed. See the procedures for removing and replacing the device door in this guide.
Page 64 6. Secure the device to the equipment rack racks with six 10-32 x .63 screws with square-cone washers, three screws on each side. Tighten the screws to a torque of 92 cm-kg (80 in-lb). See the following figure. 40 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 65 Figure 26. Chassis Installed in Equipment Rack 7. Reinstall the device door. For instructions, see procedures for removing and replacing the device door in this guide. Chapter 3. Mounting the switch 41...
Page 66 42 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 67 Customize the switch and chassis name for Use the switchNamecommand, followed by new name in the device. quote marks ( switchName"bigswitch".) Use the chassisname command followed by the new name in quote marks ( "chassis_002"). © Copyright IBM Corp. 2020...
Page 68 • Before connecting power, refer to the following sources of information: – Electrical caution and danger statements in “Safety precautions” on page 7 and “Facility requirements” on page 8 44 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 69 – Power supply specifications section in the Appendix A, “Product specifications,” on page 191 for power supply requirements of your device. • Connect each power supply to a different power source or circuit to provide full redundancy. • Route the power cords so they will be out of the way when connected to the power source. Ensure that the power cords have a minimum service loop of 15.2 cm (6 in.) and are routed to avoid stress.
Page 70 The connector on the power cord is keyed so that it only fits one way into the power supply connector. Note that the connector's latch should be positioned under the connector and will latch when the power cord connector is fully inserted into the power supply. 46 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 71 6. Attach the cable restraint cover under the power cord connector using its two torx head screws (see Step “4” on page 46). Note: This retainer cover protects the power cord from being accidentally unlatched and disconnected from the power supply. 7.
Page 72 Note that the connector's latch should be positioned under the connector and will latch when the power cord connector is fully inserted into the power supply. 48 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 73 Establishing a serial connection to the device About this task To establish a serial connection to the console port on the device, complete the following steps. Procedure 1. Verify that the device is powered on and that POST is complete by verifying that all power LED indicators on the power supplies, fans, and blades display a steady green light.
Page 74 • 10.77.77.75 / CP0 (the CP blade in slot 1 at the time of configuration) • 10.77.77.74 / CP1 (the CP blade in slot 2 at the time of configuration) 50 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 75 Use one of the following formats for IPv4 or IPv6 addressing when entering the IP address using the ipaddrset command: • If using an IPv4 IP address, enter the IP address in dotted-decimal notation as prompted. Ethernet IP Address: [192.168.74.102] •...
Page 76 You can use the fabricshow command on another device in the fabric to view domain IDs already assigned. Manually configure a unique domain ID using the configure command as in the following steps: 52 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 77 Procedure 1. Log on to the device using one of the following methods: • A serial console connection to the active CP blade. The active CP is indicated by an illuminated blue LED on the blade front panel. • A telnet session using the chassis management IP address. 2.
Page 78 – For Eastern Standard Time, enter tsTimeZone -5,0. Table 13. Example: tsTimeZone Command Parameter Selection for the U.S. Time Zones Local Time tsTimeZone Parameter (Difference from UTC) Atlantic Standard –4,0 Atlantic Daylight –3,0 Eastern Standard –5,0 54 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 79 Table 13. Example: tsTimeZone Command Parameter Selection for the U.S. Time Zones (continued) Local Time tsTimeZone Parameter (Difference from UTC) Eastern Daylight –4,0 Central Standard –6,0 Central Daylight –5,0 Mountain Standard –7,0 Mountain Daylight –6,0 Pacific Standard –8,0 Pacific Daylight –7,0 Alaskan Standard –9,0...
Page 80 This will list installed licenses and display a license key, such as aNYtMJg7tcMZrTZ9JTXBC4SXWLJMY3QfBKYHG. 4. Enter the license --show command on the active CP blade to obtain the license ID (the switchWwn, formerly chassis ID). 56 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 81 The chassis ID is required to obtain and activate licenses for the device. 5. Store and record the license key file for future reference. What to do next Refer to the Fabric OS Administration Guide for more information. Verifying correct operation About this task Perform the following steps to verify correct operation of the device.
Page 82 5. Enter the following commands for additional configuration information that you can save to files: • configShow • ipaddrShow • licenseShow • switchShow Powering down the chassis About this task Perform the following steps to power down the chassis. 58 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 83 Procedure 1. Shut down the chassis using the sysShutdowncommand. switch::admin> sysshutdown This command will shutdown the operating systems on your switch. You are required to power-cycle the switch in order to restore operation. Are you sure you want to shutdown the switch [y/n]?y HA is disabled Stopping blade 1 Shutting down the blade..
Page 84 60 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 85 16Gb/s SFP+, SWL, LWL, ELWL Autonegotiate 4, 8, and 16Gb/s port blade 10Gb/s SFP+, SWL, LWL Fixed 10Gb/s 32Gb/s, SWL, LWL, ELWL Autonegotiate 8, 16, and 32Gb/s FC64-48 port blade 10Gb/s SFP+, SWL, LWL Fixed 10Gb/s © Copyright IBM Corp. 2020...
Page 86 4x32Gb/s and 4x16Gb/s operation. Use the appropriate ICL kit to meet SAN256B-7 or SAN512B-7 QSFP requirements. Contact your SAN256B-7 or SAN512B-7 representative for ordering information. The following figures show examples of QSFP to QSFP and QSFP breakout cables. 62 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 87 1. QSFP Quad Connector Figure 27. QSFP to QSFP Standard Cables This is only useful for ICLs if connecting to a patch panel. 1. QSFP MPO Connector 2. SFP Connectors Figure 28. QSFP to SFP Breakout/Cables DANGER: Use only optical transceivers that are qualified by Broadcom and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825.
Page 88 A separate fiber optic cable connects to the transceiver. Some QSFP transceivers have an integrated pull tab that releases the transceiver from the port. 64 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 89 Figure 31. QSFP Cable and Transceiver with Bail Open 1. Fiber-Optic Cable 2. Bail 3. Transceiver Core routing blades QSFPs installed in core routing blades are used for connecting inter-switch links (ICLs) between SAN256B-7 and SAN512B-7 Directors or between SAN256B-7/SAN512B-7 and SAN256B-6/SAN512B-6 or SAN384B-2 and SAN768B-2 Directors.
Page 90 4×28.05Gb/s. This is a multi-rated CWDM4 QSFP28 transceiver with a duplex LC connector, as in the following illustration. It supports up to 2-km link length using duplex single-mode fiber. a Figure 33. QSFP28 Transceiver 1. Pull Tab 2. QSFP Cable 3. QSFP Transceiver 66 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 91 All 16 ICL ports can be used for 2 km distances when 20 buffer credits are configured per virtual channel. Time and items required The installation or replacement procedure for one transceiver takes less than 5 minutes. Ensure that the following items are available: •...
Page 92 • If the transceiver has a bail latch mechanism (10GbE transceivers), ensure that the bail (wire handle) is in the unlocked position, grasp the transceiver, and push it into the port until firmly seated. Close the bail to latch the transceiver in the slot. 68 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 93 Figure 35. Installing an SFP+ Transceiver with a Bail Latch into a Blade Port Transceivers are keyed so that they can be inserted only with the correct orientation. If a transceiver does not slide in easily, ensure that it is correctly oriented. 2.
Page 94 Insert the cable into the transceiver until the latching mechanism clicks. Cables are keyed so that they can be inserted in only one way. If a cable does not slide in easily, ensure that it is correctly oriented. 70 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 95 Installing a QSFP transceiver About this task The device supports only transceivers qualified for Brocade devices. If you use an unqualified transceiver, the switchshow command output shows the port in a Mod_Inv state. The operating system also logs the issue in the system error log. Also, note the following: •...
Page 96 Note: Cables are keyed so that they can be inserted in only one way. If a cable does not slide in easily, ensure that it is correctly oriented. 5. Organize cables to avoid covering LEDs and air vents. See “Cable management” on page 67. 72 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 97 Verifying the operation of new transceivers About this task You can use the following commands to verify if the transceivers are working correctly: • errDump • fabricShow • sfpShow • switchShow • switchshow -qsfp • switchshow -slot, where slot is the slot number For output examples and additional information on Fabric OS commands, see “Using monitoring commands”...
Page 98 74 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 99 1. Blade Power LED 2. Blade Status LED 3. Status LED for Upper FC port 4. Status LED for Lower FC port The following table describes the port blade LED patterns and the recommended actions for those patterns. © Copyright IBM Corp. 2020...
Page 100 Fast-flashing amber (on Environmental range has Check for out-of-bounds 1/2 second, then off 1/2 been exceeded. environmental second) conditions and correct them. 76 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 101 Table 15. Port Blade LED Descriptions (continued) LED Purpose Color Status Recommended Action FC port Status No light (LED is off) Port has no incoming Verify that the power power, or there is no LED is on, check the light or signal carrier transceiver and cable.
Page 102 Ensure that the blade is powered on. firmly seated, with ejectors pushed in fully to the center of blade and ensure that the captive screw for each ejector is fully tightened. 78 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 103 Table 16. Port Blade LED Descriptions (continued) LED Purpose Color Status Recommended Action Status No light (LED is off) The blade is either Verify that the power healthy or does not have LED is on. power. Steady amber The blade is faulty. Ensure that the blade is firmly seated and check the status by entering...
Page 104 Interpreting FC32-64 port blade LEDs See the following figure and table to interpret the LED patterns for the FC32-64 blade. The LED patterns temporarily change during POST and other diagnostic tests. 80 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 105 1. Blade Power LED 2. Blade Status LED 3. Status LEDs for QSFP+ Ports Figure 42. FC32-64 Port Blade LEDs 1. Blade Power LED 2. Blade Status LED 3. Status LEDs for QSFP+ Ports The following table describes the blade LED patterns and the recommended actions for those patterns. Note: When the QSFP is operating in breakout mode, each of the four LEDs above the QSFP+ port indicates the status of an individual breakout port.
Page 106 Fast-flashing amber (on Environmental range has Check for out-of-bounds 320 ms second, then off been exceeded. environmental 320 ms) conditions and correct them. 82 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 107 Table 17. Port Blade LED Descriptions (continued) LED Purpose Color Status Recommended Action QSFP port Status No light (LED is off) Port has no incoming Verify that the blade power, or there is no power LED is on, check light or signal carrier the transceiver and detected.
Page 108 4. Lower 40GbE QSFP (Port 1) status LED 5. Upper 1 or 10GbE Port Status LED 6. Lower 1 or 10GbE Port Status LED 7. Upper FC Port Status LED 84 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 109 8. Lower FC Port Status LED The following table describes the extension blade LED patterns and the recommended actions for those patterns. Table 18. Extension Blade LED Descriptions LED Purpose Color Status Recommended Action Power Steady green The blade is operational. No action is required. No light (LED is off) The blade is not Ensure that the blade is...
Page 110 Alternating green and The port is bypassed. Reset the port from the amber workstation using the portEnable or portCfgPersistentE nable command. 86 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 111 Interpreting control processor blade LEDs See the following figure and table to interpret the LED patterns on the CPX7 blade. The LED patterns temporarily change during POST and other diagnostic tests. Figure 44. Control Processor Blade (CPX7) 1. Blade Status LED 2.
Page 112 When an X6-4 Director has been upgraded in the field to a Gen 7 Director, the chassis will have CPX6 control processor blades that were installed for use with that chassis. Occasionally, the LED patterns for 88 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 113 the CPX6 blade differ from those found on the CPX7 blade. See the following figure and table to interpret the LED patterns on the CPX7 blade. Table 21. LED Descriptions for 10/100/1000Mb/s Ethernet Ports: CPX6+ (Upgraded Chassis) Inactive link 10Mb/s 100Mb/s 1000Mb/s Ethernet link status...
Page 114 1 and WWN card 2 are located on the WWN card (logo) bezel between the power supplies on the nonport side of the device. The LED patterns may temporarily change during POST and other diagnostic tests. 90 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 115 Figure 46. WWN Card LEDs on Bezel 1. Power LED for WWN Card 1 2. Status LED for WWN Card 1 3. Power LED for WWN Card 2 4. Status LED for WWN Card 2 Table 23. WWN Card LED Descriptions LED Purpose Color Status...
Page 116 In the unlikely event of a faulty power supply, the status LED will flash in a coded pattern to provide additional fault information. Record the sequence of flashes and status as defined in the table to provide to your support representative along with supportsave output data. 92 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 117 Table 24. AC Power Supply LED Descriptions LED Purpose Color Status Recommended Action Power status No light (LED is off) The power supply does Ensure that the power supply is not have incoming firmly seated, the power cable is power and is not connected, and the power cable providing power to the is connected to the power...
Page 118 See the following figure and table to interpret the LED patterns on fan assemblies. The LED patterns may temporarily change during POST and other diagnostic tests. The SAN256B-7 Director has two fan assemblies. 94 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 119 Figure 49. Fan Assembly LEDs 1. Power LED 2. Status LED Table 26. Fan Assembly LED Descriptions LED Purpose Color Status Recommended Action Power No light (LED is off) The fan assembly does Ensure that the fan not have power. assembly is firmly seated and has power.
Page 120 1. The digital signature of the signed image in Boot Flash flash code is validated against a pre- programmed public key in the CPU to ensure integrity of the code prior to proceeding with the boot sequence. 2. Universal port configuration is performed. 96 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 121 3. Links are initialized. 4. The fabric is analyzed. If any ports are connected to other switches, the device participates in a fabric configuration. 5. The device obtains a domain ID and assigns port addresses. 6. Unicast routing tables are constructed. 7.
Page 122 Factory Part Num: 60-1003373-01 Factory Serial Num: EAL0339L009 Manufacture: Day: 24 Month: 10 Year: 2015 Update: Day: 12 Month: Year: 2016 Time Alive: 66 days Time Awake: 0 days 98 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 123 SW BLADE Slot: 8 Header Version: Power Consume Factor: -420W Power Usage: -264W Factory Part Num: 60-1003373-01 Factory Serial Num: EAL0339L009 Manufacture: Day: 24 Month: 10 Year: 2015 Update: Day: 12 Month: Year: 2016 Time Alive: 66 days Time Awake: 0 days POWER SUPPLY Unit: 1...
Page 124 • Heartbeat (up or down). • Health of standby CP. • HA synchronization status. The following is an example of haShow output: chassisX7:admin> hashow Local CP (Slot 1, CP0): Active, Warm Recovered 100 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 125 Remote CP (Slot 2, CP1): Standby, Healthy HA enabled, Heartbeat Up, HA State synchronized Note the following about this output: • A warm recovery typically does not disrupt traffic flow. • A cold recovery is usually a result of a reboot of the active CP, which disrupts traffic. •...
Page 126 0: id (sw) Vendor: BROCADE Serial No: JAF3154200000VJ Speed: 8,16,32_Gbps Slot 3/Port 1: -- Slot 3/Port 2: -- Slot 3/Port 3: -- Slot 3/Port 4: -- Slot 3/Port 5: -- 102 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 127 Slot 3/Port 6: -- Slot 3/Port 7: -- Slot 3/Port 8: -- Slot 3/Port 9: -- Slot 3/Port 10: -- Slot 3/Port 11: -- Slot 3/Port 12: -- Slot 3/Port 13: -- Slot 3/Port 14: -- Slot 3/Port 15: -- Slot 3/Port 16: -- Slot...
Page 128 6 SW BLADE 216 FC64-48 ENABLED 7 CORE BLADE 215 CR64-8 ENABLED 8 CORE BLADE 215 CR64-8 ENABLED 9 AP BLADE 186 SX6 ENABLED 10 SW BLADE 204 FC32-64 ENABLED 104 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 129 11 SW BLADE 204 FC32-64 ENABLED 12 AP BLADE 186 SX6 ENABLED Upgraded-X6-8:admin> slotshow -m Slot Blade Type ID Model Name Status -------------------------------------------------- 1 CP BLADE 175 CPX6 ENABLED 2 CP BLADE 175 CPX6 ENABLED 3 SW BLADE 178 FC32-48 ENABLED 4 SW BLADE 216 FC64-48 ENABLED 5 SW BLADE 178 FC32-48 ENABLED 6 SW BLADE 178 FC32-48 ENABLED...
Page 130 Saving support information for switch:ras010, module:AMS_MAPS_LOG... Saving support information for switch:ras010, module:FLOW_VISION_LOG... Saving support information for switch:ras010, module:MP_LOG... Saving support information for switch:ras010, module:DM_FTR_FFDC......Saving support information for switch:ras010, module:CORE_FFDC... 106 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 131 No core or FFDC data files found! Saving support information for switch:ras010, module:RAS_POST....SupportSave completed. tempShow Use the tempShow command to display temperature readings of blade temperature sensors. The command displays the following information: • Sensor ID (an index number) •...
Page 132 For more information about diagnostic tests and how to run them, refer to the Fabric OS Administration Guide and the Fabric OS Command Reference Manual. For information about system error messages (errShow or errDump), refer to the Fabric OS Troubleshooting and Diagnostics Guide. 108 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 133 Figure 50. FC32-X7-48 Blade Port Numbering 1. FC ports 0-23 (numbered right to left) 2. FC ports 24-47 (numbered right to left) See Supported Transceivers and Cables for a list of qualified transceivers for blade ports. © Copyright IBM Corp. 2020...
Page 134 • Green blade power LED • Amber blade status LED • Bicolor green/amber FC port status LEDs For details on interpreting LED operation, see “Interpreting FC64-48 port blade LEDs” on page 78. 110 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 135 FC64-48 port blade numbering and trunking The following figure shows how ports are numbered on the blade. Figure 51. FC64-48 Blade Port Numbering 1. FC ports 0-23 (numbered right to left) 2. FC ports 24-47 (numbered right to left) See Supported Transceivers and Cables for a list of qualified transceivers for blade ports. The following table defines the eight-port Fibre Channel port groups for configuring trunk groups or "trunks."...
Page 136 The physical QSFP+ ports are numbered 0-15 from right to left. See “Supported transceivers and cables” on page 61 for a list of qualified transceivers for blade ports. 112 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 137 The following table defines the eight-port Fibre Channel port groups for configuring trunk groups or "trunks." Color coding on the physical blade identifies the port groups. On the blade, ports belonging to the same port group are indicated with the same color border beneath the port on the blade label. Ports belonging to the same ASIC are indicated by a border with a similar color tone.
Page 138 • Extended distance Fibre Channel supports long-distance native FC connectivity. • Extension tunnels and circuits: 114 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 139 – A maximum of 8 circuits can be configured per tunnel. – A maximum of 20 tunnels (VE_Ports) can be configured for all GbE ports. – The maximum committed rate of a single circuit is 10Gb/s, whether configured on a 10GbE or 40GbE port.
Page 140 • SFP, SFP+, or SFP28 transceivers (as needed) • Optical and copper cables (as needed) Note: For information about the transceivers that are qualified for this Brocade device, see Supported Transceivers and Cables. 116 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 141 Removing a blade Before you begin Before removing the blade, consider the following: • Before removing any cables from a blade, note the cable order (identify each cable by its physical port). • It is a good practice to create a table of cable-to-port mapping for reference. •...
Page 142 When the blade face is about 2.54 cm (1 in.) from the chassis, you should feel resistance as the blade connectors meet the backplane connectors. 118 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 143 b) Continue pushing the blade into the slot using your thumbs or fingers until the ejectors move in toward the blade slightly, indicating that the connectors are engaged. c) Simultaneously push both ejector handles in toward the blade center with even pressure until the blade completely seats in the slot.
Page 144 120 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 145 Each numbered QSFP port on the blade provides four Gen 7 ICL FC ports. The following table shows the mappings from the numbered QSFP ports on the face of the core blade to the individual FC port numbers as shown by the slotShow command. © Copyright IBM Corp. 2020...
Page 146 The recommended topology is the "parallel" type where at least four QSFP cables connect between both core routing blades on any two directors. This provides ICL trunking between 122 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 147 directors, ensuring redundancy. Although the following illustrations show SAN256B-6 and SAN512B-6 Directors, the discussion applies to SAN256B-7 or SAN512B-7 Directors as well. Following are the maximum numbers of directors that you can connect using 4x Gen 7 QSFP ICLs: • Up to nine SAN256B-7 or SAN512B-7 directors can be connected in a full-mesh topology. •...
Page 148 • Gen 6 QSFPs (4x32G QSFPs) must be used on Gen 7 ICL ports to connect to a Gen 6 or Gen 5 chassis through an ICL port for connections up to 100m. 124 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 149 • Gen 6 QSFPs (4x32G 2-km QSFPs) must be used on Gen 7 ICL ports to connect to a Gen 6 chassis through an ICL port for connections up to 2 km. 16G 2-km QSFPs are not supported on Gen 7 ICL ports. The SAN256B-7 or SAN512B-7 Director can be connected in a core-edge configuration.
Page 150 Note: For information about the transceivers that are qualified for this Brocade device, see the Supported Transceivers and Cables discussion in this guide. Replacing a core routing blade Use the following procedures in this section to replace routing blades: 126 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 151 • Preparing for replacement. Use these procedures to ensure that traffic is not disrupted through existing ICL connections when you are replacing a core routing blade. If ICLs are not connected to the blade or traffic through ICL ports has ceased, you can skip these procedures, and then go to “Removing a core routing blade”...
Page 152 12. Continue pulling the blade from the slot by the blade edges. As you slide out the blade, place one hand under it for support. Do not support the blade by the injector handles after removal. 128 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 153 Figure 60. Removing and Installing a Core Routing Blade on an SAN256B-7 Director 13. If the blade is not being replaced by another blade, install a filler panel and reinstall the chassis door. The filler panel is required for proper chassis cooling. The door is required to meet EMI compliance. Installing a core routing blade About this task Complete the following steps to install a core routing blade into an empty slot.
Page 154 For output examples and additional information on Fabric OS commands, see Using Monitoring Commands and the Fabric OS Command Reference Manual. For more information on error messages, refer to the Fabric OS Message Reference Manual. 130 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 155 • To display beaconing status: chassisX7:admin> chassisbeacon Value = 0 For details on LED location and operation, see Interpreting Control Processor Blade LEDs. CPX7 port identification The following figure identifies connector ports on the CPX7 blade. © Copyright IBM Corp. 2020...
Page 156 CAUTION: If you do not install a module or a power supply in a slot, you must keep the slot filler panel in place. If you run the chassis with an uncovered slot, the system will overheat. 132 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 157 CAUTION: Static electricity can damage the chassis and other electronic devices. To avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them. CAUTION: Before plugging a cable into any port, be sure to discharge the voltage stored on the cable by touching the electrical contacts to ground surface.
Page 158 Fabric OS Command Reference Guide. c) In a FICON environment, log on as root and enter configupload --map to upload port-to-area mapping information. Specify a folder name, when prompted. 134 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 159 This command saves the port-to-area addressing mode configuration files to the folder specified. Be sure to upload the configuration using the -map option for a FICON-enabled device if port- bound addressing is used. For more information, refer to the Fabric OS Command Reference Guide. 2.
Page 160 9. Continue pulling the blade from the slot by the blade edges. As you slide out the blade, place one hand under it for support. Do not support the blade by the injector handles after removal. 136 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 161 Figure 62. Removal and Replacement of the Control Processor Blade (CPX7) on an SAN256B-7 Director 10. If the blade is not being replaced by another blade, install a filler panel and reinstall the chassis door. The filler panel is required for proper chassis cooling. The door is required to meet EMI compliance. Installing a blade About this task Note: Read all of the instructions for replacing the CP blade before beginning the procedure.
Page 162 6. Perform one of the following tasks to download firmware: • If you are using an FTP server to download the firmware, skip to the procedure for downloading firmware from an FTP server. 138 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 163 • If you are using a USB device to download the firmware, skip to the procedure for downloading firmware from a USB device. If the firmware on the standby CP blade is more than one level down from the level on the active CP blade, you must have formatted USB devices for each of the versions you will need to upgrade.
Page 164 INIT: Sending processes the TERM signal Chassis_1:admin> HAMu Heartbeat down, stop FSS Unmounting all ##exiting due to signal: 9, pending signals: 0x20000, 0x0 ilesystems. Please stand by while rebooting the system... Restarting system. The system is coming up, please wait... 140 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 165 Fri Jun 17 14:53:13 2016: Doing firmwarecommit now. Please wait ... Fri Jun 17 14:55:27 2016: Firmware commit completes successfully. Validating the filesystem ... Fri Jun 17 22:36:05 2016: Doing firmwarecommit now. Please wait ... Fri Jun 17 22:36:48 2016: Firmware commit completes successfully. 2016/06/17-14:56:50, [SULB-1004], 908, SLOT 2 | CHASSIS, INFO, Brocade_X6, Firmwarecommit has completed.
Page 166 12. Verify that each blade's power LED is green. If they are not green, ensure that the CP blade has power and is firmly seated and that the ejectors are in the locked position. 142 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 167 Completing the replacement About this task Complete the following steps to complete the CP blade replacement procedure. Procedure 1. Enter haEnable to re-enable HA on the active CP blade. Note: The haEnable command will cause the standby CP blade to reboot. Wait until POST completes —when the status LED on the CP blade returns to a steady green state—before moving to the next step.
Page 168 See Using Monitoring Commands and the Fabric OS Command Reference Manual for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Fabric OS Message Reference Manual. 144 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 169 The WWN cards are located behind the WWN bezel (logo bezel) on the nonport side of the device between the power supplies. The bezel must be removed to access the card trays. The following figure illustrates the WWN card location and numbering. Figure 64. WWN Card Location and Numbering 1. WWN Card 1 © Copyright IBM Corp. 2020...
Page 170 WWN unit fails to power on. <timestamp>, [EM-1004], <sequence-number>, CRITICAL, <system-name>, WWN # failed to power onor<timestamp>, [EM-1043], <sequence-number>, WARNING, <system-name>, Can't power <FRU Id> <state (on or off)>. 146 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 171 Table 31. Messages That May Indicate WWN Card Failure (continued) Type of Message Sample Error Message WWN unit is faulted. 0x24c (fabos): Switch: switchname , Critical EM-WWN_UNKNOWN, 1, Unknown WWN #2 is being faultedor<timestamp>, [EM-1003], 40, SLOT 7 | FFDC | CHASSIS, CRITICAL, Brocade_Chassis, WWN 2 has unknown hardware identifier: FRU faultedor<timestamp>, [EM-1034], <sequence-number>, ERROR,...
Page 172 Recovery is not possible. Please The license ID on the two WWN cards does not contact Brocade Technical Support for match. replacement of the corrupted or inaccessible WWN(s). 148 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 173 The wwnrecover utility must be used to maintain data integrity when replacing one or both WWN cards using instructions in the WWN card removal and replacement section. To run wwnrecover, log on as admin and enter the following command: switch:admin# wwnrecover For more information on wwnrecover and command syntax, refer to the Fabric OS Command Reference Manual.
Page 174 IP addresses on installed WWN cards do not match, follow instructions in the message to recover the IP address so that both cards use the same address. 5. Determine the active CP blade by entering the haShow command. 150 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 175 6. On the active CP blade, run the wwnrecover command and specify the WWN card that you replaced (WWN 2 or WWN 1) when prompted. 7. If wwnrecover messages prompt for a system reboot, reboot both CP blades to ensure the system is running with valid WWN card data.
Page 176 Insert and tighten both screws using a Phillips screwdriver. 15. Pack faulty WWN card assemblies in the packaging provided with the replacement cards, and return them to Brocade Support for failure analysis (FA). 152 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 177 Removing the WWN card and bezel About this task Two WWN cards are located behind the WWN bezel. As you face the bezel on the nonport side of the device, WWN 1 is located on the left side, and WWN 2 is on the right. When cards have been determined faulty and the replacement WWN cards have been received, complete the following steps to remove the bezel and faulty WWN cards.
Page 178 For information on interpreting LED patterns, see “Interpreting WWN card LEDs” on page 90. 2. Enter the errDump command. This displays the system error log. Refer to the Fabric OS Messages Reference Manual for more information on the messages in this log. 154 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 179 Power supplies can be removed and replaced without special tools. If replacing one power supply, the device can continue operating during replacement if procedures are followed in this guide. Power cords for these power supplies are available from Brocade that meet your site and country requirements. © Copyright IBM Corp. 2020...
Page 180 The following figure illustrates power supply assembly components. Figure 67. HVAC/HVDC Power Supply Assembly 1. Fan 1 2. Fan 2 3. Handle 4. Status LED 5. HVAC/HVDC Power Cable Receptacle 6. Airflow Label 7. Captive Screw 156 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 181 8. Power Cable Restraint Cover Consider the following information when connecting AC power: • The SAN256B-7 Director has two power supplies installed. The use of the high-voltage line (200 to 277 VAC) is advised because of better power conversion efficiency. See "Power Supply Requirements" in the Brocade X7 Director Technical Specifications for minimum power supplies required for AC low and high voltage line operation, redundancy in case of power supply failure, and other specifications.
Page 182 Note: A device with slots for eight port blades can have up to four power supplies installed. If you are adding additional power supplies, you can use the procedures in this section under “Installing a power 158 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 183 supply” on page 161 to install the new power supplies. Be sure to follow the steps on those procedures to enable sending notifications if the additional power supplies should fail. Note: Make sure that captive screws securing power supply assemblies to chassis are tightened. If not, high pressure from fans' operation may unseat power supply assemblies from chassis connectors.
Page 184 • If you can leave the chassis in operation and replace a power supply, unplug the power cord from the power supply assembly that you are replacing. 160 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 185 Note: Be sure to replace the power supply as soon as possible. 3. Loosen the captive screw on the right side of the power supply assembly until the screw releases from the chassis. The captive screw is located just below the airflow label on the right side of the power supply assembly.
Page 186 See Using Monitoring Commands and the Fabric OS Command Reference Manual for output examples and additional information on Fabric OS commands. For more information about error messages, refer to the Fabric OS Message Reference Manual.. 162 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 187 FRU, contains either NPI or NPE. If a mismatched power source or fan assembly is installed by mistake, a RASlog message occurs indicating that a mismatch in fan or power supply airflow has occurred and the FRU is faulted. © Copyright IBM Corp. 2020...
Page 188 FRUs from chassis connectors. Fan assembly numbering The following figure illustrates the location and number identification of fan assemblies in the chassis. 164 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 189 Figure 73. Fan Assembly Numbering 1. Fan Assembly 1 2. Fan Assembly 2 Precautions specific to fan assemblies Observe the following precautions when replacing fan assemblies. Note: Each fan assembly contains two fans for a total of four fans for two installed fan assemblies. The device requires 3 fans out of 4 functioning fans for operation.
Page 190 Time and items required The replacement procedure for each fan assembly takes less than 5 minutes. The following items are required for the blower assembly replacement: • Replacement fan assembly 166 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 191 • No. 1 Phillips screwdriver Removing a fan assembly About this task Complete the following steps to remove a fan assembly from the chassis. Procedure 1. Before removing a fan assembly, refer to “Precautions specific to fan assemblies” on page 165 to verify whether you can remove the power supply and leave the chassis operating (hot-swap replacement).
Page 192 4. Push in on each captive screw and tighten with a No. 1 Phillips screwdriver to secure the fan assembly to the chassis. Note: Be sure that captive screws are tightened. If not, high pressure from fan operation may unseat fan from chassis connectors. 168 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 193 This action moves the latches away from the ends of the slot to unlatch the cover from chassis. 3. Using the latch pull tabs as handles, pull the filler panel out of the chassis. © Copyright IBM Corp. 2020...
Page 194 Try unlatching both ends, pushing the cover firmly into the slot, and then latching both ends again. Note: Be sure filler panels are securely latched. If not, high pressure from fan operation may unseat blade from chassis connectors. 170 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 195 Figure 76. Removing and Installing the Blade Filler Panel on an X7-4 Director 4. Reinstall the chassis door. The door must be installed to meet EMI compliance. Chapter 13. Blade filler panels 171...
Page 196 172 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 197 Complete the following steps to remove the cable management finger assemblies from rack uprights. Cable management finger assemblies are shown installed in the following figure. Figure 77. Cable Management Fingers Installed on Rack Uprights on an SAN256B-7 Director 1. Cable Management Finger Assemblies © Copyright IBM Corp. 2020...
Page 198 1. Cable Management Finger Assemblies 2. Arrange the cables along with the cable management finger assembly. 3. If necessary, repeat steps 1 and 2 for the other cable management finger assembly. 174 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 200 2. Align the six ball stud attachment holes in the back of the door with the six ball studs in the chassis and push the door into place. It will snap onto the studs. Figure 81. Installing Chassis Door 176 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 201 The following are the basic tasks for removing and replacing the chassis with its backplane: Note: The device must be removed from the fabric and powered off to perform these tasks. Contact your support provider if you have any questions about whether the chassis requires replacement. © Copyright IBM Corp. 2020...
Page 202 This includes information on licenses, IP addresses, WWNs, serial numbers, switch IDs, location of 178 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 203 configuration files, and fabric details. It also includes information that might be required by Technical Support. “Recording critical device and SAN information” on page 179 instructs you to run the following commands and record specific output: • chassisShow • configUpload - all •...
Page 204 File Name [config.txt]: config-switch0.txt Password: Upload complete switch:admin> 3. Record the WWN value: Enter wwn, and then copy the command output into a file named config- miscinfo.txt. switch:admin> wwn 10:00:00:60:69:00:00:0a 180 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 205 4. Enter ipAddrShow, and then copy the command output into the config-miscinfo.txt file. switch:admin> ipaddrshow Chassis Ethernet IP Address: 10.33.60.85 Ethernet Subnetmask: 255.255.240.0 Ethernet IP Address: 10.33.60.86 Ethernet Subnetmask: 255.255.240.0 Host Name: cp0 Gateway IP Address: 10.33.48.1 Ethernet IP Address: 10.33.60.87 Ethernet Subnetmask: 255.255.240.0 Host Name: cp1 Gateway IP Address: 10.33.48.1...
Page 206 You must power-cycle the switch in order to restore operation. Are you sure you want to shutdown the switch [y/n]?y HA is disabled Stopping blade 1 Shutting down the blade..Stopping blade 2 Shutting down the blade..182 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 207 Stopping blade 8 Shutting down the blade..Broadcast message from root (pts/1) Tue April 12 14:23:06 2008... The system is going down for system halt NOW !! DANGER: Disconnect the power cord from all power sources to completely remove power from the device.
Page 208 7. Verify that the device is powered on and POST is complete (all power LED indicators on the blades should be a steady green). 184 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 209 8. Verify that all components are functioning correctly by checking their LEDs. If the LEDs do not indicate correct operation, try reinstalling the corresponding component. Synchronizing airflow direction on WWN cards An airflow direction mismatch may occur if the airflow direction, nonport-side intake (NPI) or nonport- side exhaust (NPE), for installed fan and power supply assembly FRUs does not match the airflow direction set on the new WWN cards shipped with replacement chassis.
Page 210 The following example shows the mismatch of the system airflow and the airflow direction in the installed fan and the power supply. POWER SUPPLY Unit: 1 Power Source: Fan Direction: Non-portside Intake 186 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 211 Unit: 2 Fan Direction: Non-portside Intake Unit: 1 System AirFlow: Non-portside Exhaust Unit: 2 System AirFlow: Non-portside Exhaust The WWN units should indicate "Non-portside Intake." If there is a mismatch of airflow direction, RASlog messages will indicate a mismatch between the system airflow direction and the airflow direction of fan in power supply or fan assembly.
Page 212 • If there are any mechanical problems, try re-seating the associated component. • If the configuration information is not correct for the device, modify as required. • If other issues exist, contact your support provider. 188 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 213 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call.
Page 214 6. Recycle the battery as appropriate, following local regulations. Refer to the Environmental Notices and User Guide shipped with the product for more information on battery recycling and disposal. 190 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 215 400: HVAC/HVDC power supply. Power from nonport side, all power supplies. Power supplies: Up to two modular, hot-swappable 3000 W AC power supplies (100-240 VAC SAN256B-7 Director autosensing or HVAC/HVDC autosensing), 1 + 1 redundancy. © Copyright IBM Corp. 2020...
Page 216 VE_Port on GbE. Note: Self-discovery is based on switch type (U_Port) with an optional port type control. Data traffic types Fabric switches supporting unicast, multicast (255 groups), and broadcast. 192 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 217 1000Base-SX/LX/CWDM SFP, 10GbE SR/LR SFP+, 10GbE tunable DWDM 80- km SFP+, and 40GbE SR4/LR4/ER4 QSFP. CR64-4 and CR64-8 core routing blades: Supports IBM, hot-pluggable Gen 7 ICL SWL QSFP, 4x32 Gb/s SWL QSFP and 4x32 Gbp/ 2KM QSFP for ICL connections.
Page 218 Unicolor (green) displaying power-off and power-on condition. Unicolor (amber) fault LED. Fan status Unicolor (green) displaying power-off and power-on condition. Unicolor (amber) displaying four different LED states based on fan operation. 194 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 219 System Component Description Power supply status Unicolor (green) displaying nine different LED states based on power supply operation. Management Connectors System Component Description RJ-45 to DB9 adapter The RS-232 cable has an adapter at one end that can be removed to provide an RJ-45 style connector for the serial port.
Page 220 Random vibration is 5-10Hz @ +5db/ Random vibration is 3–10Hz @ +5db/ Oct; 10-200Hz @ 0.0005 Grms; Oct; 10-200Hz @ 0.0065 Grms; 200-500Hz @ -5db/Oct. Scale 0.05 200-500Hz @ -5db/Oct. Scale 1.12 Grms Grms 196 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 221 Condition Operational Nonoperational (Storage) Air flow SAN256B-7 Maximum: 953 cmh (561 cfm) SAN256B-7 Nominal: ~486 cmh (~286 cfm) Heat dissipation SAN256B-7: refer to Watts and Btu/hr values under VAC inputs in Typical, Idle, and Maximum Power Consumption tables. Power Supply 80 Plus Platinum Efficiency Operating noise...
Page 222 200–277 HVAC (high line) 240–380 HVDC 200–240 VAC 3 (N+1) (high line) 200–277 HVAC (high line) 240–380 HVDC 200–240 VAC 4 (N+N) (high line) 200–277 HVAC (high line) 240–380 VDC 198 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 223 Model Name Configured Input Connection Minimum Number of Ports Power Power Supplies for Supplies for Operation Redundancy 200–240 VAC 3 (N+1) (high line) 200–277 HVAC (high line) 240–380 HVDC 200–240 VAC 4 (N+N) (high line) 200–277 HVAC (high line) 240–380 HVDC Power Consumption for AC Power Supplies (Typical 1 Configuration) The typical power consumption configuration features fans at nominal speed and the FC32-X7-48 port blade configured with 32G optics operating in 50% of the ports, an ambient temperature of 25C, and fans...
Page 224 HA (redundant) configuration. 1209W 1182W Same power supplies as Same supported above. configuration as 4126 Btu/hr 4036 Btu/hr above, but port blades are FC64-48. 200 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 225 40°C (104°F). Maximum power is used for all supported optics. Power specifications do not include the power draw for the SX6 extension blade. Note: Volt-ampere (VA) power measurement is provided only for power consumption using the maximum chassis configuration. For VA power measurements for your configuration, contact your IBM representative. Model...
Page 226 The typical power consumption configuration features fans at nominal speed and the FC32-X7-48 port blade configured with optics operating at 50 percent line rate and random packets (does not include the power draw for the SX6 extension blade). 202 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 227 Input Input @ 240 or 277 VAC Input SAN256B-7 1407 W 1376 W 1 power supply for DC input (192-400 IBM SAN256B-7 VDC) Director fully 4802 4696 BTU/hr loaded: 2 CP Btu/hr 2 power supplies for AC low line (100–...
Page 228 40°C (104°F), and maximum power is used for all supported optics. Power specifications do not include the power draw for the SX6 extension blade. Note: Volt-ampere (VA) power measurement is provided only for power consumption using the maximum configuration. 204 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 229 Name Input Input @ 240 or 277 VAC Input SAN256B-7 2889W 2385W 1 power supply for DC input (192–400 IBM SAN256B-7 VDC) Director fully 9681 8139 Btu/hr loaded: 2 CP Btu/hr 2 for AC low line (100–120 VAC) 2484 VA...
Page 230 Typical 1 = TBD Typical 2 = 203W Maximum = 387W WWN card World Wide Name card Idle = 1W Typical 1 = 1W Typical 2 = 1W Maximum = 1W 206 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 231 Module Name Module Description Power Consumption Fan assembly Fan assembly containing two fans 4000 RPM = 25W 5000 RPM = 40W 6000 RPM = 65W 10000 RPM = 220W,X7-4 12000 RPM = 375,X7-8 Fibre Channel Data Transmission Ranges Port Speed Cable Size Short Wavelength Long Wavelength...
Page 232 E, F, D, M, and EX Fibre Channel ports using four SX6 extension blades. 4x16Gb/s E, F, D, M, QSFP+ and EX Fibre Channel ports using eight FC32-64F ibre Channel port blades. 208 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 233 Model Port Type Number Description of Ports 32Gb/s E, F, D, M, SFP+ and EX Fibre Channel ports using eight FC64-48, FC32- X7-48, FC32-48 Fibre Channel port blades. E, F, D, M, and EX Fibre Channel ports using eight SX6 extension blades.
Page 234 EX operation Fibre only) Channel ports using eight FC64-48, FC32- X7-48, FC32-48F ibre Channel port blades. E, F, D, M, and EX Fibre Channel ports using four extension blades. 210 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 235 Data Port Specifications (Ethernet) Model Port Type Number of Description Ports SAN256B-7 40GbE Up to 64 40GbE ports supported with 4 FC64-48 port blades for FCoE applications using QSFP-to-QSFP connections. 25GbE Up to 256 25GbE ports supported with 4 FC32-X7-64 port blades for FCoE applications.
Page 236 Class 1M Transceiver Specifications Specification Standards Approval Description Class 1M Pass Radiation output and standards information < 3.1 mW Max output of laser radiation Pulse duration 840–860 nm Emitted wavelength(s) 212 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 237 Specification Standards Approval Description IEC 60825-1:2007 Pass The name and publication date of the standard IEC 60825-2:A2/2010 Serial Port Specifications (Pinout RJ-45) Signal Description Not supported Not supported UART1_RXD Receive data Logic ground Logic ground UART1_TXD Transmit data Not supported Not supported Serial Port Specifications (Protocol) Parameter...
Page 238 • SJ/T 11363 – 2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364 – 2006 Marking for the Control of Pollution Caused by EIPs (China). 214 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 239 Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe on any IBM intellectual property right may be used instead.
Page 240 International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the web at Copyright and trademark information atwww.ibm.com/legal/copytrade.shtml Adobe, the Adobe logo, PostScript, and the PostScript logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States, and/or other countries.
Page 241 Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.
Page 242 This topic contains the product service contact information for Taiwan. IBM Taiwan Product Service Contact Information: IBM Taiwan Corporation 3F, No 7, Song Ren Rd., Taipei Taiwan Tel: 0800-016-888 218 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 243 Japan Voluntary Control Council for Interference (VCCI) Notice Japan Electronics and Information Technology Industries Association (JEITA) Notice This statement applies to products less than or equal to 20 A per phase. This statement applies to products greater than 20 A, single phase. This statement applies to products greater than 20 A per phase, three-phase.
Page 244 Korea Notice Russia Notice 220 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 245 215 boot results 96 trademarks 216 POST 96 IBM contacts xv director of licensing, address 215 IBM Publications Center xv documentation IBM Support Portal xv Brocade xxiii Fabric Operating System (FOS) xxiii installing 65 installation tasks 9 intellectual property 215...
Page 246 189 blade filler panel 169 chassis 177 QSFP cables 65 transceivers 61 safety notices xvii rack installation xxi rack relocation xxi safety labels xix SAN256B-7 library xxiii 222 IBM Storage Networking SAN256B-7: SAN256B-7 Installation, Service, and User Guide...
Page 248 IBM® Part Number: 03GM362 SC28-3149-00...

IBM Storage Networking SAN256B-7 Installation, Service And User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for IBM Storage Networking SAN256B-7

Summary of Contents for IBM Storage Networking SAN256B-7
