Supported SFPs and HBAs

When you receive the switch, your package contains at least 8 Brocade-branded
SFPs for the base configuration. Use only SFPs that are tested and supported. For
the most up to date list of supported SFPs and HBAs for the switch, refer to the
product interoperability matrix at the IBM SAN Support web pages at:
www.ibm.com/servers/storage/support/san
Table 15. Switch power supply specifications (continued)
Specification
System power consumption
Input voltage
Input line frequency
BTU rating
Inrush current
Value
48 watts nominal, 57 watts maximum
85 - 264 VAC, universal
47 - 63 Hz
277 BTU/hr
21.5 Amps at 240 VAC cold start
