cl= n ; n means which group of GPIO you want to set
;
bl= the n group of gpio config
;
bit 0 = gpio 0 , 0 => output pin; 1 => input pin
;
bit 1 = gpio 1 , 0 => output pin; 1 => input pin
;
.....
;
bit 7 = gpio 7 , 0 => output pin; 1 => input pin
; output:
;
ax=5E78
mov ax,5E87h
mov bx,02AAh
mov cl,01
INT15
;
Set GPIO 0,2,4,6 as output, GPI 1,3,5,7 as input
;===============================================================
;===============================================================
;
Get GPIO status
; Input:
;
ax=5E87h
;
bh=03h
;
cl= n ; n means which group of GPIO you want to get
; output:
;
ax=5E78
;
bl= the n group of gpio status
;
bit 0 = gpio 0 , 0 => Low; 1 => High
;
bit 1 = gpio 1 , 0 => Low; 1 => High
;
.....
;
bit 7 = gpio 7 , 0 => Low; 1 => High
mov ax,5E87h
mov bh,03h
mov cl,01h
INT15
;
You will get GPIO value from bl
;===============================================================
;===============================================================
;
Set GPIO status
; Input:
;
ax=5E87h
;
bh=04h
;
cl= n ; n means which group of GPIO you want to set
;
bl= the n group of gpio status
;
bit 0 = gpio 0 , 0 => Low; 1 => High
PCM-3362 User Manual
;function success, other value means function fail
;function success, other value means function fail
78
