Advantech PCM-3864 Startup Manual

PCM-3864/3860 386SBC with VGA/LCD
Start-up Manual
Packing list Packing list Packing list
Packing list Packing list
Before you begin installing your card, please make
sure that the following materials have been shipped:
• 1 PCM-3864/3860 All-in-one single board computer
• 1 Start-up manual
• 1 Floppy cable
• 1 3.5" IDE flat cable
• 1 DIN jack 5p-6p cable
• 1 secondary serial port cable (RS-232/422/485)
• 1 Parallel cable
• CD-ROM or Disks for utility, drivers, and manual (in
PDF format)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note: For detailed contents of the
PCM-3864/3860, please refer to the
enclosed CD-ROM or Disk (in PDF format).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our support
website at:
http://support.advantech.com
This manual is for the PCM-3864/3860
Part No. 2006000032
Printed in Taiwan
Specifications Specifications Specifications
Specifications Specifications
Standard SBC functions
• CPU with core logic: Ali M6117C, 40 MHz
80386SX processor
• BIOS: AMI 128 KB Flash memory
• RAM: One 72-pin SIMM socket. Supports FPM/
EDO DRAM 1 ~ 16 MB (accepts 1 / 4 / 16 MB
modules)
• Enhanced IDE hard disk drive interface:
Supports up to two enhanced IDE devices. BIOS
auto-detect
• Multi-mode parallel port: Configured to LPT1,
LPT2, LPT3 or disabled. Supports SPP/EPP/ECP
mode. D-SUB 25-pin connector on board
• Floppy disk interface: Supports up to two FDDs:
3.5" (720 KB or 1.44 MB) and/or 5.25" (360 KB or
1.2 MB)
• Serial ports: One serial RS-232 port, one serial
RS-232/422/485 port. Two 16C550 compatible
UARTs
• PS/2 Keyboard connector: Mini-DIN keyboard
connector
Digital I/O
• Digital input x 4: TTL compatible input voltage
High;
Low:
• Digital output x 4: TTL compatible output V
High:
low:
SVGA/flat panel interface
• Chipset: C&T 65545
• Display memory: 512 KB DRAM
• Hardware Windows acceleration: 16-bit graphic
engine. Hardware line drawing and 64 x 64 x 2
hardware cursor
• Resolution: Panel resolution up to 640 x 480 @
256 colors. Non-interlaced CRT monitors
resolution up to 1024 x 768 @ 16 colors
1st edition
July1999
2.0 V minimum
0.8 V maximum
source 0.4 mA @ 2.4 V min.
sink 8 mA @ 0.5 V max.
