Chapter 1

Processor Installation

Do not set the processor speed switches to a different speed from the one labeled
on the processor, as this can result in unreliable or intermittent performance, and
data integrity may also be at risk.

System Preparation

The installation procedure is the same for the rack-mount and the pedestal
NetServer once you gain access to the system board assembly.
1. Log off all users and, if necessary, backup the system.
2. Gracefully shut down the NOS according to directions in your NOS
documentation.
3. Press the power switch on the HP NetServer's control panel when
prompted by the NOS.
4. Disconnect the power cords and signal cables and, if necessary, label each
one to support reassembly.
CAUTION
The power supplies will continue to provide standby current to
the NetServer until the power cable is disconnected.
5. Gain access to the system board assembly for either model, rack-mounted
or pedestal, by following the instructions in the HP NetServer LH
6000/6000r Installation Guide.
NOTE In the LH 6000r, this assembly is under the right cover, in the
LH 6000, it is under the top cover.
6. Remove the two screws securing the system board assembly to the chassis.
7. Loosen the two captive fasteners securing the system board assembly to
the chassis.
8. Unlatch the blue retaining latches to release the assembly.
9. Pull the assembly out until it clears the chassis guides.
CAUTION
The system board assembly weighs approximately 30 lbs. (14
kgs.) and requires extra support as you remove it from the
chassis.
HP NetServer LH 6000/6000r Processor Upgrade
5
