Install the hard drive.
6.
WARNING:
drive drawers.
When all drives have been installed, close the hard drive drawer.
7.
Installation
Be sure the hard drive drawer is closed all the way.
1.
Release the I/O blank handle.
2.
Push the I/O blank handle down until it ejects the I/O blank.
3.
Remove the I/O blank.
4.
Install the I/O module into the enclosure.
5.
Pinch hazard—Keep hands out of front and rear of chassis when closing hard
Setup 21
