Power Cords - HP StorageWorks 600 - Modular Disk System User Manual

For a complete list of supported cables, see the QuickSpecs on the HP website (http://www.hp.com).
To acquire different lengths, contact the nearest authorized HP reseller
40).

Power cords

The power cord should be approved for use in your country. The power cord must be rated for the
product and for the voltage and current marked on the electrical ratings label of the product. The voltage
and current rating for the cord should be greater than the voltage and current rating marked on the
product. In addition, the diameter of the wire must be a minimum of 1.00 mm
maximum length may be up to 3.66 m (12 ft).
WARNING:
Do not disable the power cord grounding plug. The grounding plug is an important safety
•
feature.
Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at
•
all times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
Do not route the power cord where it can be walked on or pinched by items placed
•
against it. Pay particular attention to the plug, electrical outlet, and the point where the
cord extends from the storage system.
To connect AC power cords:
Connect the power cords to the power supplies.
1.
Connect the power cords to the AC power source.
2.
To reduce the risk of electric shock or damage to the equipment:
("HP contact information" on page
2 or 18 AWG, your
Setup 23
