5.21 LED Board

LED board (includes cable)
1. Prepare the notebook for disassembly (refer to
and remove the following components:
❏
❏
❏
❏
❏
❏
❏
❏
2. Turn the top cover upside down, with the front facing you.
Maintenance and Service Guide
Spare Part Number Information
Keyboard (refer to
Memory shield (refer to
Switch cover (refer to
Keyboard plate (refer to
Fan assembly (refer to
Heat sink (refer to
Display assembly (refer to
Top cover (refer to
Removal and Replacement Procedures
Section 5.9)
Section 5.11)
Section 5.12)
Section 5.13)
Section 5.15)
Section 5.16)
Section
Section 5.19)
346884-001
Section
5.18)
5.3)
5–49
