5.16 Heat Sink

Heat sink
1. Prepare the notebook for disassembly (refer to
and remove the following components:
❏
❏
❏
❏
2. Remove the four T8M2.5×5.0 screws that secure the heat
sink bracket to the system board.
Removing the Heat Sink
Maintenance and Service Guide
Spare Part Number Information
Keyboard (refer to
Switch cover (refer to
Keyboard plate (refer to
Fan assembly (refer to
Removal and Replacement Procedures
Section 5.9)
Section 5.12)
Section 5.13)
Section 5.15)
344410-001
Section 5.3)
5–35
