Item Component
1 Audio line-out jack
2 Microphone jack
3 Hard drive bay
4 MultiBay device slot
5 Infrared port
6 Mute button
7 Volume control
buttons
8 Stereo speakers (2)
9 Display release latch
Maintenance and Service Guide
Table 1-3
Front and Left-Side Components
Function
Produces system sound when connected to
optional powered stereo speakers,
headphones, headset, or television audio.
Connects an optional monaural
microphone.
Holds the primary hard drive.
Holds a MultiBay device.
Provides wireless communication between
the notebook and an optional
IrDA-compliant device.
On: Mutes the system volume. A light
comes on when the button is pushed in and
the sound is muted.
Increase and decrease system volume.
Press the volume up button to increase
sound. Press the volume down button to
decrease sound.
Produce stereo sound.
Opens the notebook.
