Screw Listing
mm
Where used:
1
Two screws that secure the hard drive frame to the hard drive
(documented in
mm
Where used:
2
Two screws that secure the hard drive frame to the hard drive
(documented in
mm
Where used:
3
Two alignment pins that secure the hard drive frame and connector to the
hard drive (documented in
C–2
Table C-1
Torx T5M3.0×4.0 Screw
Color
Silver
Section 5.3)
Table C-2
Phillips PM3.0×3.5 Screw
Color
Silver
Section 5.3)
Table C-3
Hex M2.0×10.0 Alignment Pin
Color
Silver
Section
Qty. Length
2 4.0 mm
Qty. Length
2 3.5 mm
Qty. Length
2 10.0 mm
5.3)
Maintenance and Service Guide
Head
Thread Width
3.0 mm 5.0 mm
Head
Thread Width
3.0 mm 5.0 mm
Head
Thread Width
2.0 mm 4.0 mm
