Install the Voltage Regulator Module

If you are installing two processors, you must install a voltage regulator module
(VRM). Orient the VRM as shown and press it into the connector. Make sure
the plastic latches engage the VRM.
C
B
A
OM10677
16
STL2 Server Board Quick Start Guide
