Intel
®
Server Board S2600KP Product Family
Intel
®
Compute Module HNS2600KP Product Family
Intel
®
Server Chassis H2000G Product Family
Spares/Accessories List and Configuration Guide
A reference guide to assist with ordering parts and accessories available to configure an Intel sever system based on the Intel
Server Board S2600KP Product Family.
Revision 2.21
Intel® Server Boards and Systems
®
April 2016
Advertisement
Table of Contents
Related Manuals for Intel S2600KP
Summary of Contents for Intel S2600KP
- Page 1 ® Server Chassis H2000G Product Family Spares/Accessories List and Configuration Guide A reference guide to assist with ordering parts and accessories available to configure an Intel sever system based on the Intel ® Server Board S2600KP Product Family. Revision 2.21 April 2016 Intel®...
- Page 2 <This page is intentionally left blank.>...
- Page 3 January 2016 Rev 2.10 Added Board and System “R” SKUs Added RS25GB008, RS25SB008 and AHWKPTP12GBGBIT Added support for Intel® Xeon® processor E5-2600 v4 product family Added support for 2400 MT/s RDIMMs and LRDIMMs March 2016 Rev 2.20 Fixed reference links...
- Page 4 No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document. Intel disclaims all express and implied warranties, including without limitation, the implied warranties of merchantability, fitness for a particular purpose, and non-infringement, as well as any warranty arising from course of performance, course of dealing, or usage in trade.
-
Page 5: Table Of Contents
® SAS RAID A NTEL ARDS ODULE CCESSORIES ..................................16 3.4.1 Intel® RAID Controller Add-in Cards ........................................16 3.4.2 Intel® RAID Accessoried Options .......................................... 18 3.4.3 Rack Mount kits ..............................................19 MISCELLANEOUS ACCESSORY OPTIONS ........................................20 SPARE AND REPLACEMENT PARTS (FRUS) ........................................21 EXTENDED WARRANTY .............................................. - Page 6 Table 3. Compute Module Product Family Summary ..............................4 Table 4. Server Chassis & Server System Product Family Summary ..........................4 Table 5. Intel® Server Board S2600KP Product Family SKUs ............................6 Table 6. Intel® Server Compute Module HNS2600KP Product Family SKUs ........................7 Table 7.
- Page 7 List of Figures Figure 1. Intel® Compute Module HNS2600KP Feature Set Identification ........................3 Figure 2. Intel® Server Chassis H2000G Feature Set Identification ..........................3 Figure 3. Installing the Front Bezel to the Chassis ................................ 11 Figure 4. Installing the Snap-on to the Front Bezel ..............................11...
-
Page 9: Intel® Server Family Overview
Intel® Server Family Overview This document is provided to assist Intel customers with identifying the right Intel® server system and available accessories, enabling them to create a unique server platform that meets their unique server requirements. The Intel® S2600KP product family is offered as building block. The product family consists of the following: Intel®... -
Page 10: Table 1. Product Family Reference Collaterals
Intel® Server Board S2600KP Technical Product Specification Intel® Server System H2000G Product Family Technical Product Specification Intel® Remote Management Module 4 (Intel® RMM4) and Integrated BMC User Guide Intel® Remote Management Module 4 Technical Product Specification For in-depth technical information about this product Intel®... -
Page 11: Figure 1. Intel® Compute Module Hns2600Kp Feature Set Identification
Figure 1. Intel® Compute Module HNS2600KP Feature Set Identification Label Description Front control panel Drive bays Power distribution module Power supply modules Hot-swap backplane (attached to the drive cage) Figure 2. Intel® Server Chassis H2000G Feature Set Identification... -
Page 12: Product Family Summary Chart
The S2600KPFR SKU offers an integrated InfiniBand*. The following tables provides an overview of available Intel product codes for building blocks within the Intel® S2600KP product family. Each line item identifies key features supported in the shipping Intel SKU. Additional order code information and full product descriptions for each option are provided in later sections. -
Page 13: Server Building Block Configuration
Server Building Block Configuration Server building blocks are offered to give Intel customers the option to configure and assemble a unique server system from the bare chassis up. Each building block component and optional accessory is purchased separately. At a minimum, building up a functional server system using building blocks will require the following: Intel®... -
Page 14: Intel® Server Board S2600Kp Product Family Skus
SAS module option 12.62 Kgs, 27.82 Lbs. Box includes: One server board Un-packaged Net Weight NOTE: All necessary mounting hardware, cabling, and shielding will ship with the Intel 0.9834 Kgs, 2.16 Lbs. chassis and optional accessory kits. MM# - 943790 Intel ®... -
Page 15: Intel® Compute Module Hns2000Kp Product Family Skus
Intel® Compute Module HNS2000KP Product Family SKUs Table 6. Intel® Server Compute Module HNS2600KP Product Family SKUs Intel Product Code (iPC) Order Information Product Description Product Type MM# - 943787 Intel ® Compute Module HNS2600KPR iPC - HNS2600KPR ® UPC - 00735858309271 (1) –... -
Page 16: Intel® Chassis H2000G Product Family Skus
Intel® Chassis H2000G Product Family SKUs The product tables found in this section provide order code information and detailed descriptions for each available Intel server chassis building block option. The lower sections of each table identify: The ship along components of the specified chassis product code – (product BOM) •... -
Page 17: Ipc - H2312Xxkr2
Intel® I/O Module – See Chapter 3.4 for options (1) - Pre-installed Standard Control Panel assembly an integrated InfiniBand* Intel® SAS RAID Card / Module – See Section 3.5 for options (board only) – iPC FH2000FPANEL2 iPC HNS2600KPFR – with an front system bezel ... -
Page 18: Ipc - H2216Xxkr2
Intel® I/O Module – See Chapter 3.4 for options (1) - Pre-installed Standard Control Panel assembly an integrated InfiniBand* Intel® SAS RAID Card / Module – See Section 3.5 for options (board only) – iPC FH2000FPANEL2 iPC HNS2600KPFR – with an front system bezel ... -
Page 19: Server System Configuration Options
The front bezel includes a keyd locking mechanism which can be used to prevent unauthorized access to installed storage devices and front I/O ports. Table 8. List of Front Bezel Accessory Kit Intel Product Code Order Information Product Description... -
Page 20: Intel® I/O Expansion Modules
Intel® I/O Expansion Modules The Intel® S2600KP product family includes supports for a number of optional Intel® I/O Module that install proprietary connectors on the server board leaving available PCIe* add-in cards slot available for other add-in cards options. Figure 5. Intel® I/O Module Installation... -
Page 21: Table 9. List Of Intel® I/O Expansion Mudules
• Server Board S2600TP Product Family. MOQ - 1 Dual Port Intel® 82599EB 10GbE I/O Module iPC - AXX10GBNIAIOM Dual SFP+ port 10GbE IO module based on Intel ® 82599 10 Gigabit MM# - 917905 Ethernet Controller. UPC - 735858241090 Accessory Kit •... - Page 22 Product Description Product Type Dual RJ-45 port 10GBASE-T IO Module iPC - AXX10GBTWLHW3 MM# - 941868 Dual RJ-45 port 10GBASE-T IO module, based on Intel® Ethernet UPC - 735858296649 Controller X540 –Available in early Q2 2015. Accessory Kit • EAN - 5032037072465...
-
Page 23: Intel® Bridge Board Options
Intel® Bridge Board Options The Intel® compute module HNS2600KP include a 6Gb/s bridge board which have the following options. Table 10. Intel® SAS Bridge Board Intel Product Code Order Information Product Description Product Type Spare 12Gb SAS Bridge Board AHWKPTP12GBGBIT (SAS without RAID) -
Page 24: Intel® Sas Raid Add-In Cards, Module, And Accessories
Intel® SAS RAID Add-in Cards, Module, and Accessories Intel® RAID offers a broad portfolio of RAID solutions designed to address the storage-related challenges of the modern day datacenter as well as the small business. The Intel® S2600KP product family include support for the latest generation of 12Gb/s SAS Intel® RAID add-in cards, modules, expanders, and accessories. - Page 25 Intel Product Code Order Information Product Description Product Type Intel® RAID Controller RS25GB008 iPC - RS25GB008 Intel® RAID Controller RS25GB008 for Intel® Compute Module MM# - 919566 HNS2600KPR or HNS2600KPFR only and, H2312XXKR2 or H2216XXKR2 chassis only. UPC - 735858219877 Accessory Kit Low Profile, half length, (MD2 Compliant) PCIe* add-in card •...
-
Page 26: 3.4.2 Intel® Raid Accessoried Options
LSI* SWR5), Black. Intel® RAID SSD Cache with Fast Path *I/O iPC - AXXRPFKSSD2 MM# - 915316 Upgrade Key to enable SSD Cache with Fast path I/O for Intel’s RAID UPC - 73585822201467 RS25 family of ROC products. Accessory Kit •... -
Page 27: Rack Mount Kits
Rack Mount kits The Intel® Server Board S2600KP product family provides the upgrade option to the rack mount kits. CAUTION: Exeeding the rail kit’s specified maximum weight limit or misalignment of the server in the rack may result in failure of the rack rails, resulting in damage to the systems or personal injury. -
Page 28: Miscellaneous Accessory Options
Miscellaneous Accessory Options Table 14. List of Miscellaneous Accessory Options Intel Product Code Order Information Product Description Product Type iPC - AXXRMM4LITE MM# - 911660 UPC - 735858219297 Activation key for advanced management features. Accessory kit • EAN - 503203702014946... -
Page 29: Spare And Replacement Parts (Frus)
® Compute Module MOQ – 1 HNS2600TP Product Family. Spare 12Gb SAS/SATA 12 x 3.5" Backplane iPC - FHW12X35HS12G 12 x 3.5’’ spare backplane for Intel ® Server Chassis H2312XXKR2. MM# - 935567 UPC - 735858288446 Spare FRU for •... - Page 30 UPC - 735858288460 cables, a bus pair and supporting bracket, for Common Spare FRU • EAN - 5032037067782 Redundant Power Supply 1600W of Intel ® Server Chassis MOQ - 1 H2000G Product Family. iPC - FPWRCABLENA North American Power Cord Spare...
- Page 31 Intel Product Code Order Information Product Description Product Type iPC - FXX4056DRFAN2 MM# - 935566 UPC - 735858288439 40x56mm Dual Rotor Fan spare. Spare FRU • EAN - 5032037067751 MOQ - 1 iPC - BXSTS200P MM# - 915972 UPC - 735858221795 1U Standard Boxed Cu/Al 91.5mm x 91.5mm Heat Sink...
- Page 32 MOQ - 8 Spare Front Control Panel Kit iPC - FH2000FPANEL2 Spare front control panel kit (2 mini-front panel boards and MM# - 935578 rack handle assembly) for Intel ® Server Chassis H2000G UPC - 73585828842015 Product Family. Spare FRU •...
-
Page 33: Extended Warranty
Table 16. Extended Warranty Image Oder Information Description iPC - SVCEWHWSY Extended Warranty for complete system (1x Intel® Server Chassis H2000G + 4x Intel® Compute Module MM# - 923113 HNS2600KP), Single. MOQ - 1 iPC - SVCEWHWB MM# - 914905 Extended Warranty for single node (1x Intel®... -
Page 34: Glossary Of Terms
FDR Infiniband Fourteen Data Rate Infiniband RMFBU RAID Maintenance Free Backup Unit Field Replaceable Unit RMM4 Lite Intel® Remote Management Module 4 Lite Activation key Input/Output Module RAID on Chip Intel Product Code RSTe Intel® Rapid Stroage Technology Intel Product Number...
