Table 5.

Configuration Utilities

Utility
BIOS Setup
Changing Boot Device
Priority
Adaptec SCSISelect
Direct Platform Control
(DPC) Console
System Setup Utility (SSU)
and
Client System Setup Utility
(CSSU)
FRU/SDR Load Utility
BIOS Update Utility
Firmware Update Utility

Hot Keys

Use the numeric pad of the keyboard to enter numbers and symbols.
Table 6.

Hot Keys

To Do This:
Secure your system immediately.
Enter the Adaptec SCSI Utility during POST.
Enter the Promise Technology IDE RAID Utility.
Enter BIOS Setup during POST.
Abort memory test during POST.
Display a menu for selecting the boot device.
To remove the splash screen.
42
Description and brief procedure
Use for system configuration of onboard resources, setting boot
device priority, or setting system security options.
You can move the CMOS jumper on the system board from the
default setting (Protect CMOS memory) to the Clear setting; this
will allow most system configurations to boot.
Use this option to change the boot device priority temporarily or
permanently.
†
Utility Use to configure or view the settings of the SCSI host adapters and
onboard SCSI devices in the system.
Use to access and monitor the server remotely.
Use for viewing and configuring server management options,
viewing the system event log (SEL), setting boot device priority, or
setting system security options.
The SSU can run either from the configuration software CD or from
a set of bootable diskettes. You can create the diskettes from
the CD.
The CSSU is run from the service partition via the DPC console. It
provides the same functionality as the SSU, but from a remote
console.
Information entered via the SSU/CSSU overrides information
entered via BIOS Setup.
Use to update the Field Replacement Unit (FRU) and Sensor Data
Record (SDR) flash components.
NOTE
: You must run the FRU/SDR Load utility whenever the
BMC is updated or if you change your processors.
Use to update the BIOS or recover from a corrupted BIOS update.
Use to update BMC flash ROM or other firmware.
Press These Keys
<Ctrl+Alt>+hot key (Set your hot key combination
with the SSU or BIOS Setup.)
<Ctrl+A> (SCSI model only)
<Ctrl+F> (ATA model only)
<F2>
<ESC> (Press while BIOS is updating memory size
on screen.)
<ESC> (Press anytime after memory check.)
<ESC>
Intel Server Board SCB2 Product Guide
Page
43
43
54
56
57
75, 79
75, 77
75, 79
