Back Panel Connectors
Description
A
B
C
E
H
A.
USB 1 connector
B.
Video connector
C. SCSI connector (SCSI server board only)
D. NIC 2 RJ-45 connector
E.
Green Status LED
F.
Yellow Status LED
G. NIC 1 RJ-45 connector
H. Green Status LED
I.
Yellow Status LED
J.
PS/2 keyboard/mouse connector
K.
RJ-45 serial port
L.
USB 2 connector
Figure 2. Back Panel Connectors
J
K
L
D
F
I
G
OM11713
9
