Chapter 4

Removing the Existing Processor Module

If you are upgrading an existing processor module, you must first remove the
existing module from the slot.
To remove a processor module:
1. Slide the blue plastic release levers to free the processor module, as shown
in Figure 4-4.
2. Remove the processor module from the processor mounting bracket.
Processor Module
Figure 4-4. Removing the Processor Module from HP NetServer E 60 or LPr
Slide Levers to Free
Processor Module
Processor Mounting Bracket
Installation in E 60 and LPr
41
