Chapter 3
Terminator Board
Retaining Latches
Terminator Board
Secondary Processor Position
Figure 3-15. Install the Terminator Board in a Single-Processor
2. Insert the terminator board into the upper (secondary) processor position.
3. Verify that the terminator board is installed completely in the slot. When
the terminator board is installed completely, the retaining latches (see
Figure 3-15) will be closed.
HP NetServer LC 3 or LH 3/3r
Installation in LC 3 and LH 3/3r
Primary Processor
Module
31
