Chapter 4

Install the Processor Modules

See Figure 4-1 or 4-2 for the location of the processor positions and system
switches on the system board.
Secondary
Processor
Position
Figure 4-1. HP NetServer E 60 System Board
Secondary Processor
Module Position
Primary
Processor
Module
VRM for
Primary
Processor
Figure 4-2. HP NetServer LPr System Board
Installation in E 60 and LPr
VRM Socket for
Secondary Processor
Primary
Processor
Module
System
Switches
System Switches
