Slot Configuration

The Slot Configuration Screen, Figure 5, allows a user to configure IP addresses
for individual 9X4XX series modules, which support firmware version 1.12.00 or
greater.
To access the Slot Configuration Screen, go to the Module Menu Screen. Then,
select the Slot Configuration option.
Note: Each slot's Module IP Address field and Subnet Mask field become
read-only once an IP address is assigned to a module.
Module Name: 9F426-02
Slot Number: 10
SAVE
SmartSwitch 9000
SLOT # MODULE Name
1 9T122-24
2 9T122-24
3 9A426-02
4 9T122-08
5
6 9T122-24
7
8 9T425-16
9 9E423-24
<10> 9F426-02
11
12
13
14 9T428-16
Figure 5. Slot Configuration Screen
9X4XX Series Local Management
Local Management
Slot Configuration
Firmware Revision: 01.12.00
BOOTPROM Revision: 01.01.02
Module IP Address
xxx.xxx.xxx.xxx 255.255.0.0
xxx.xxx.xxx.xxx 255.255.0.0
EXIT
Subnet Mask
RETURN
