Configuration Option - Cabletron Systems SmartSwitch 9000 Appendix

9X4XX Series Local Management
PHY Configuration (Full Duplex FDDI)
The PHY Configuration Screen, Figure 3, provides support for the DEC (Digital
Equipment Corporation) Full Duplex FDDI option.
Note: This screen is used only on the 9F4XX-series modules.
To access the PHY Configuration Screen, go to the Module Configuration Screen.
Then, select the FDDI Configuration option. Finally, select the PHY

Configuration option.

Module Name: 9F426-02
Slot Number: 10
SAVE
8
SmartSwitch 9000
PORT # REQUESTED MODE
1 AUTONEGOTIATE
2 AUTONEGOTIATE
SET ALL PORTS: AUTONEGOTIATE
Figure 3. PHY Configuration Screen
Local Management
PHY Configuration
Firmware Revision: 01.12.00
BOOTPROM Revision: 01.01.02
OPERATION MODE LINK STATE PORT STATUS
HALF DUPLEX - DAS No Link
HALF DUPLEX - DAS No Link
ENABLED
ENABLED
EXIT RETURN
