Adjusting Color on the Trailing Edge of Sheets

If printed sheets are affected by banding in different colors toward the end of the sheet (about 20-30 mm from
the edge), try adjusting the feed amount of the trailing edge of sheets.
Note
•
If printed documents (including documents printed on rolls) are affected by banding in different colors
not only toward the end of the sheet but throughout the printed area, try adjusting the overall feed
amount. (→P.577)
•
This adjustment is only possible when feeding paper from the Top Paper Feed Slot that can be set up
with a margin on the trailing edge of 3 mm (0.12 in). If you use paper for which you cannot specify a
trailing margin of 3 mm, it will be automatically ejected, and adjustment is not possible.
1.
Load a sheet of unused paper A4/Letter-sized or larger.
Note
•
Always make sure the loaded paper matches the media type setting on the printer. Adjustment
cannot be completed correctly unless the setting value matches the loaded paper.
•
We recommend using the type of paper you use most often for adjustment.
2.
Press the Menu button to display MAIN MENU.
3.
Press ▲ or ▼ to select Adjust Printer, and then press the ► button.
4.
Press ▲ or ▼ to select Adj Far Ed Feed, and then press the ► button.
5.
Press ▲ or ▼ to select Yes, and then press the OK button.
A test pattern is printed for adjustment.
C1 is displayed on the Control Panel.
6.
Examine test pattern C1 for adjustment. After you determine the pattern in which streaks are
least noticeable, press the ▲ or ▼ to choose the pattern number, and then press the OK button.
C2 is displayed on the Control Panel.
Adjusting the feed amount
Adjustments for Better Print Quality 585
