G1000H
™
Integrated Flight Deck
Cockpit Reference Guide for the Bell 407GX

Advertisement

Table of Contents
loading

Related Manuals for Garmin G1000H

Summary of Contents for Garmin G1000H

  • Page 1 G1000H ™ Integrated Flight Deck Cockpit Reference Guide for the Bell 407GX...
  • Page 3 FLIGHT INSTRUMENTS EICAS NAV/COM/TRANSPONDER/AUDIO PANEL AUTOMATIC FLIGHT CONTROL SYSTEM GPS NAVIGATION FLIGHT PLANNING PROCEDURES HAZARD AVOIDANCE ADDITIONAL FEATURES ABNORMAL OPERATION ANNUNCIATIONS & ALERTS APPENDIX INDEX...
  • Page 5 Garmin Corporation, No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan Tel: 886/02.2642.9199 Fax: 886/02.2642.9099 For after-hours emergency, aircraft on ground (AOG) technical support for Garmin panel mount and integrated avionics systems, please contact Garmin’s AOG Hotline at 913.397.0836. Web Site Address: www.garmin.com...
  • Page 6 warrant or make any representations regarding its accuracy, reliability, or otherwise. Under no circumstances including negligence, shall AOPA be liable for any incidental, special or consequential damages that result from the use or inability to use the software or related documentation, even if AOPA or an AOPA authorized representative has been advised of the possibility of such damages.
  • Page 7 Warnings, Cautions & Notes WARNING: Navigation and terrain separation must NOT be predicated upon the use of the terrain function. The G1000H Terrain Proximity feature is NOT intended to be used as a primary reference for terrain avoidance and does not relieve the pilot from the responsibility of being aware of surroundings during flight.
  • Page 8 WARNING: Use of the Stormscope is not intended for hazardous weather penetration (thunderstorm penetration). Stormscope information, as displayed on the G1000H MFD, is to be used only for weather avoidance, not penetration. WARNING: The Garmin G1000H, as installed in the Bell 407GX rotorcraft, has a very high degree of functional integrity.
  • Page 9 Warnings, Cautions & Notes WARNING: The illustrations in this guide are only examples. Never use the G1000H to attempt to penetrate a thunderstorm. Both the FAA Advisory Circular, Subject: Thunderstorms, and the Aeronautical Information Manual (AIM) recommend avoiding “by at least 20 miles any thunderstorm identified as severe or giving an intense radar echo.”...
  • Page 10 Warnings, Cautions & Notes NOTE: All visual depictions contained within this document, including screen images of the G1000H panel and displays, are subject to change and may not reflect the most current G1000H system and aviation databases. Depictions of equipment may differ slightly from the actual equipment.
  • Page 11 Record of Revisions Part Number Change Summary 190-01254-00 Initial release. Revision Date of Revision Affected Pages Description February, 2011 Production release. RR-1 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 12 Record of Revisions Blank Page RR-2 Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 13: Table Of Contents

    Direct-to Navigation ......................23 Activate a Stored Flight Plan ....................24 Activate a Flight Plan Leg ..................... 24 Stop Navigating a Flight Plan ....................25 Vertical Navigation (VNAV)....................25 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 14 ADDITIONAL FEATURES ......................55 Synthetic Vision ........................55 Terminal Procedure Charts ....................56 AOPA Airport Directory ......................58 Satellite Telephone and Data Link Services (Optional) ..........59 Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 15 Miscellaneous Message Advisories ..................99 Flight Plan Import/Export Messages ................103 APPENDIX ............................. 105 PFD Softkey Map ........................105 MFD Softkey Map ......................... 110 Loading Updated Databases ....................112 INDEX ............................Index-1 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 16 Table of Contents Blank Page Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 17: Flight Instruments

    2) Press the CDI Softkey again to change from VOR1 or LOC1 to VOR2 or LOC2. This places the light blue tuning box over the NAV2 standby frequency. 3) Press the CDI Softkey a third time to return to GPS. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 18: Enable/Disable Obs Mode While Navigating With Gps

    ‘ALN’ will be displayed to the left of the heading. When the magnetic heading has properly aligned, the heading value will be displayed in white and ‘ALN’ will no longer be displayed. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 19: Generic Timer

    5) Use the small FMS Knob to enter the desired altitude. 6) Press the ENT Key. 7) To remove the window, press the CLR Key or the TMR/REF Softkey. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 20: Set Barometric/Radar Altimeter (Ra Optional) Minimum Descent Altitude

    2) Press the HSI FRMT Softkey. 3) Press the 360 HSI Softkey to display the full size HSI. Press the ARC HSI Softkey to display the arc style HSI. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 21: Engine Indication System

    Engine Indication & Crew Alerting System ENGINE INDICATION SYSTEM EIS Display (Reversionary) MFD EIS Display (Normal) 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 22 PSI) Total Fuel Quantity Displays total usable fuel quantity as a bar Gauge graph. Fuel Flow Indicator Displays fuel flow in pounds per hour (PPH) (FF PPH) Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 23: Engine Power And Speed Indications

    5 seconds. Takeoff Timer After the engine has been started, if Q or MGT are within the takeoff limitation ranges, the G1000H displays a 5-minute countdown timer inside the PSI gauge. The 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX...

  • Page 24: Power Assurance Check

    NOTE: Follow the procedures in the Rotorcraft Flight Manual (RFM) for configuring the helicopter for the power assurance check prior to activating the feature on the G1000H. 1) If the Particle Separator or Snow Baffle are installed, proceed to step 2.

  • Page 25: Crew Alerting System (Cas)

    MFD Alerts window containing CAS messages CAS Scrolling Softkeys (Enabled when more than 19 messages are displayed) Engine Page CAS Display (MFD) 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 26: Cas Message Prioritization

    CAS Window until either a newer message of the same priority appears or the condition(s) that caused the alert to display no longer exist. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 27: Nav/Com/Transponder/Audio Panel

    Frequencies in the standby field are displayed in either white or gray. The standby frequency in the tuning box is white. The other standby frequency is gray. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 28: Selecting A Nav Radio

    • GPS – If GPS Mode is selected, a magenta single line arrow (not shown) appears on the HSI and neither NAV radio is selected. Both active NAV frequencies are then displayed in white. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 29: Nav/Com Tuning

    The large knob enters MHz and the small knob enters kHz. 3) Press the Frequency Transfer Key to place the frequency into the active frequency field. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 30: Digital Clearance Recorder And Player (Optional)

    Pressing the small knob cancels the cursor. Manual Squelch Annunciator; Off for Automatic Squelch, On for Manual Relative Volume/ Squelch Squelch Scale Cursor Volume or Manual Squelch Volume/Squelch Control Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 31: Intercom Modes

    All Intercom Mode In ‘All Intercom’ mode the Pilot, Copilot, and Passengers hear each other and hear the aircraft audio. Aircraft Audio PILOT COPLT PASS ICS Keys Mode Operation 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 32 In ‘Passenger/Crew Isolate’ mode the Pilot and Copilot hear the aircraft audio and each other. The Passengers hear each other. Aircraft Audio PASS PILOT COPLT ICS Keys Mode Operation Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 33 In ‘All Isolate’ mode the Pilot and Copilot hear the aircraft audio. The Copilot has the option to use Split-COM mode. The Passengers hear each other. Aircraft Audio PASS PILOT COPLT Mode Operation ICS Keys 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 34 In ‘Copilot & Passenger Isolate’ mode the Pilot and Copilot can hear the aircraft audio. The Copilot has the option to use Split-COM mode. The Passengers hear each other. Aircraft Audio COPLT PASS PILOT ICS Keys Mode Operation Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 35: Passenger Address Mode (Pa Mode)

    Mode is annunciated by a rapid blinking of the SPKR annunciator. When in PA Mode the crew can use the PTT “Push-to-Talk” button to deliver announcements over the speaker, to the passenger headsets, or both depending on configuration. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 36: Split-Pa Mode

    PA announcements. To initiate Split-PA Mode, first enter Split-COM Mode by pressing more that one MIC Keys simultaneously, then press and hold the SPKR Key for 2 seconds. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 37: Automatic Flight Control System

    AFCS AUTOMATIC FLIGHT CONTROL SYSTEM Not available. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 38 AFCS Blank Page Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 39: Gps Navigation

    ENT Key to activate. To enter an altitude constraint, proceed to step 6. 6) Turn the large FMS Knob to place the cursor over the ‘ALT’ altitude field. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 40: Activate A Stored Flight Plan

    3) Press the MENU Key, select the ‘Activate Leg’ option from the page menu and press the ENT Key. This step must be used when activating a leg from the PFD. 4) With ‘Activate’ highlighted, press the ENT Key. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 41: Stop Navigating A Flight Plan

    Small Light Blue Subdued Text Small White Text with Altitude Restriction Bar Cross AT or ABOVE 5,000 ft Cross AT 2,300 ft Cross AT or BELOW 3,000 ft 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 42 Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 43: Flight Planning

    3) The current ‘PAGE MODE’ is displayed at the top of the page: ‘AUTOMATIC’ or ‘MANUAL’. To change the page mode, press the AUTO or MANUAL Softkey. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 44 5) Turn the large FMS Knob to highlight the departure time (DEP TIME) field. NOTE: The departure time on the Trip Planning Page is used for preflight planning. Refer to the Utility Page for the actual flight departure time. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 45: Create A User Waypoint Defined By Latitude & Longitude

    2) Turn the small FMS Knob to select the User WPT Information Page. 3) Press the NEW Softkey. A waypoint is created at the current aircraft position. 4) Enter the desired waypoint name. 5) Press the ENT Key. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 46: Create A User Waypoint Defined By Radials From Other Waypoints

    8) Turn the small FMS Knob to select RAD/RAD (radial/radial). 9) Press the ENT Key. 10) The cursor moves to the ‘REFERENCE WAYPOINTS’ field. With the first Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 47 12) Press the ENT Key. 13) Repeat step 10 to enter the next waypoint name. 14) Press the ENT Key. The cursor is displayed in the ‘RAD’ (radial) field for the 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 48: Create A User Waypoint Defined By A Radial & Distance From Another Waypoint

    Turn the large FMS Knob to select the desired waypoint. c) Press the ENT Key. a) Turn the small FMS Knob to the left. Initially, a flight plan waypoint list Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 49: Delete A User Waypoint

    2) Turn the small FMS Knob to select the User WPT Information Page. 3) Press the FMS Knob to activate the cursor. 4) Turn the large FMS Knob to the place the cursor in the ‘USER WAYPOINT LIST’ field. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 50: Create A Flight Plan

    (Turning it clockwise displays a blank Waypoint Information Window, turning it counter-clockwise displays the Waypoint Information Window with a waypoint selection submenu allowing selection of active flight plan, nearest, recent, user, or airway waypoints). Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 51: Import A Flight Plan From An Sd Card

    INSERT A WAYPOINT IN THE ACTIVE FLIGHT PLAN 1) Press the FPL Key to display the active flight plan. 2) If required, press the FMS Knob to activate the cursor. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 52: Enter An Airway In A Flight Plan

    Airway Page is displayed. The LD AIRWY Softkey or the “Load Airway” menu item is available only when an acceptable airway entry waypoint has been chosen (the waypoint ahead of the cursor position). Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 53: Invert An Active Flight Plan

    3) Press the CLR Key to display a confirmation window. 4) With ‘OK’ highlighted, press the ENT Key to remove the selected procedure or airway. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 54: Store A Flight Plan

    FMS Knob to highlight ‘CANCEL’ and press the ENT Key. 5) Once all changes have been made, press the FMS Knob to remove the cursor. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 55: Invert And Activate A Stored Flight Plan

    6) With ‘OK’ highlighted, press the ENT Key to delete the flight plan. To cancel, turn the large FMS Knob to highlight ‘CANCEL’ and press the ENT Key. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 56: Graphical Flight Plan Creation

    5) Turn the large FMS Knob to highlight the flight plan to be exported. 6) Press the EXPORT Softkey. 7) Press the ENT Key to confirm the export. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 57: Procedures

    2) Turn the large FMS Knob to highlight ‘SELECT ARRIVAL’. 3) Press the ENT Key. The cursor is displayed in the ‘ARRIVAL’ field with a list of available arrivals. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 58: Activate An Arrival Leg

    1) Press the PROC Key. 2) Turn the large FMS Knob to highlight ‘SELECT APPROACH’. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 59: Activate An Approach In The Active Flight Plan

    ACTIVATE AN APPROACH IN THE ACTIVE FLIGHT PLAN 1) Press the PROC Key. 2) Turn the large FMS Knob to highlight ‘ACTIVATE APPROACH’. 3) Press the ENT Key. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 60: Activate A Vector To Final Approach Fix

    2) Turn the large FMS Knob to highlight ‘ACTIVATE MISSED APPROACH’. 3) Press the ENT Key. A confirmation window is displayed. 4) With ‘ACTIVATE’ highlighted, press the ENT Key. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 61: Hazard Avoidance

    4) Press the LEGEND Softkey to view the legends for the selected products. If necessary, turn either FMS Knob to scroll through the list. Press the small FMS Knob or the ENT Key to return to the map. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 62 Surface Analysis. The lower symbol depicts City Forecast. The age of the displayed data for each is shown at the right. The selected forecast period is shown at the bottom. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 63: Status Icons

    ICING POTENTIAL - The age of the displayed data is shown at the right. The altitude selection is shown at the bottom. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 64: Traffic Systems

    (GTS 800 only). Traffic Symbol Description Traffic Information Service (TIS) NOTE: If the G1000H is configured to use a Traffic Advisory System (TAS), TIS is not available for use. NOTE: Traffic Information Service (TIS) is only available when the aircraft is within the service volume of a TIS capable terminal radar site.
  • Page 65 6) Rotate the Joystick clockwise to display a larger area or rotate counter- clockwise to display a smaller area. 7) Press the FLT ID Softkey to enable or disable Flight ID displayed with the intruder information. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 66: Terrain Awareness & Warning System (Htaws) Display

    HTAWS is intended only to enhance situational awareness. NOTE: The data contained in the HTAWS databases comes from government agencies. Garmin accurately processes and cross-validates the data but cannot guarantee the accuracy and completeness of the data. NOTE: Terrain data is not displayed when the aircraft latitude is greater than 75 °...
  • Page 67 HTAWS Obstacle Colors and Symbology Potential Impact Example Alert Type Point Symbol Annunciation Warning Caution HTAWS Potential Impact Point Symbols with Alert Types 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 68 2) Press the INHIBIT Softkey to inhibit or enable HTAWS (choice dependent on current state). 1) Press the MENU Key. 2) Select ‘Inhibit HTAWS’ or ‘Enable HTAWS’ (choice dependent on current state) and press the ENT Key. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 69 5) Turn the small FMS Knob to select the maximum altitude at which VCO alerts will be enabled from (from 50 to 500 feet), or select NONE to disable all VCO alerts. 6) When finished, press the FMS Knob. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 70 Hazard Avoidance Blank Page Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 71: Additional Features

    Synthetic Vision System (SVS) functionality is offered as an enhancement to the G1000H Integrated Flight Deck System. SVS is primarily comprised of a computer-generated forward-looking, attitude aligned view of the topography immediately in front of the aircraft from the pilot’ s perspective.

  • Page 72: Terminal Procedure Charts

    Pressing the DCLTR Softkey (declutter) once removes the taxiway markings and airport identification labels. Pressing the DCLTR Softkey twice removes VOR station ID, the VOR symbol, and intersection names if within the airport plan view. Pressing Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...
  • Page 73 2) Press the DP, STAR, APR, WX, and NOTAM softkeys to access charts for departures, arrivals, approaches, weather and NOTAMs Note that NOTAMS are only available with ChartView. 3) Press the GO BACK Softkey to return to the previous page. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 74: Aopa Airport Directory

    AOPA AIRPORT DIRECTORY AOPA Airport Directory adds enhanced airport information when viewing airports on the WPT-Airport Information Page. This database is updated four times per year. Check fly.garmin.com for the current database. View Airport Directory Information While viewing the WPT-Airport Information Page, if necessary, press the INFO-1 Softkey to change the softkey label to display INFO-2.

  • Page 75: Satellite Telephone And Data Link Services (Optional)

    5) Press the MENU Key. The Page Menu window is now displayed. 6) Select ‘Register With GFDS’ in the menu list. 7) Press the ENT Key. The Garmin Flight Data Service Registration window is now displayed. 8) Enter the Access Code provided by Garmin Flight Data Services.
  • Page 76 2) Turn the small FMS Knob to select the AUX-TELEPHONE Page. Internal External Description Phone Phone Phone is Idle Phone is ringing Phone has a dial tone (off hook) or connected to another phone Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 77: Incoming Calls

    In addition to the pop-up alert, a ringing phone symbol will be displayed to the right of the MFD page title. Also, the voice alert “Incoming Call” will be heard on the selected cockpit audio. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 78: Answering An Incoming Call

    1) Press the TEL Key on the audio panel. 2) Select the DIAL Softkey on the MFD. 3) Enter the desired telephone number (country code first) by selecting the number softkeys on the MFD. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 79 3) If necessary, press the SMS Softkey to display the AUX-TEXT MESSAGING Page. Message Symbol Description Received text message that has not been opened Received text message that has been opened 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 80 2) Turn either FMS Knob to place the cursor on ‘Disable New Message Popups’ or ‘Enable New Message Popups’. 3) Press the ENT Key. The pop-up alert will not be displayed when an incoming text message is received. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 81 Press the CANCEL Softkey to delete the message. Predefined Text Messages Time and effort can be saved in typing text messages that are used repeatedly by saving these messages as a predefined message. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 82 10) Press the MENU Key to display the Page Menu. 11) Turn either FMS Knob to place the cursor on ‘Stop Editing Predefined Message’. 12) Press the ENT Key. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 83 Turn either FMS Knob to place the cursor on ‘Show Inbox Messages’. c) Press the ENT Key. The message box selected for viewing is indicated at the bottom left of the list window. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 84 Turn either FMS Knob to place the cursor on ‘Sort By Date/Time’. c) Press the ENT Key. The sorting selection is indicated at the bottom center of the list window. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...
  • Page 85 Turn either FMS Knob to place the cursor on ‘View Selected Message’. c) Press the ENT Key. 5) To close the text message, press the CLOSE Softkey. a) Press the MENU Key to display the Page Menu. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 86 Press the MENU Key to display the Page Menu. b) Turn either FMS Knob to place the cursor on ‘Delete Selected Message’. c) Press the ENT Key. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...
  • Page 87 To connect the selected network without saving: a) Turn the large FMS Knob to move the cursor to highlight ‘CONNECT’. b) Press the ENT Key. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 88 2) Turn either FMS Knob to highlight the network to be deleted. 3) Press the DELETE Softkey. The selected network is removed from the list. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 89: System Data Logging (Optional)

    Additional Features SYSTEM DATA LOGGING (OPTIONAL) NOTE: An account must be established with Garmin Flight Data Services to make full use of the System Data Logging feature. Control and monitoring of report transmissions is accomplished through the AUX- REPORT STATUS Page.

  • Page 90: Xm ® Radio Entertainment (Optional)

    2) Turn the small FMS Knob to select the displayed AUX - XM Information Page. 3) Press the RADIO Softkey to show the XM Radio Page where audio entertainment is controlled. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 91: Selecting A Category

    3) Press the numbered softkeys located on the bottom of the display to directly select the desired channel number. 4) Press the ENT Key to activate the selected channel. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 92: Auxiliary Video (Optional)

    0 to 100%. 5) Press the BACK Softkey to return to the previous softkey level. Press the RESET Softkey to return the display to the default settings. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A...

  • Page 93: Input Selection

    Knob to control the range setting of the map display. Pressing the softkey to display VID ACTV allows the RANGE Knob to control the zoom setting of the video display. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 94 Additional Features Blank Page Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 95: Abnormal Operation

    Abnormal Operation ABNORMAL OPERATION REVERSIONARY MODE Should a system detected failure occur in either display, the G1000H automatically enters reversionary mode. In reversionary mode, critical flight instrumentation is combined with engine instrumentation on the remaining display. Reversionary display mode can be manually activated by pressing the DU BACKUP Button on the instrument panel.

  • Page 96: Unusual Attitudes

    Window – Flight Plan • Wind Data – Messages • Selected Heading Box – Procedures • Selected Course Box – DME Tuning • Transponder Status • Barometric Minimum Descent Altitude Box Extreme Pitch Indication Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 97: Dead Reckoning

    Abnormal Operation DEAD RECKONING While in Enroute or Oceanic phase of flight, if the G1000H detects an invalid GPS solution or is unable to calculate a GPS position, the system automatically reverts to Dead Reckoning (DR) Mode. In DR Mode, the G1000H uses its last-known position combined with continuously updated airspeed and heading data (when available) to calculate and display the aircraft’...
  • Page 98 • Current Track Indicator • All Bearing Pointer Distances • Active Flight Plan distances, bearings, and ETE values Also, while the G1000H is in DR Mode, HTAWS is disabled. Additionally, the accuracy of all nearest information (airports, airspaces, and waypoints) is questionable. Finally, airspace alerts continue to function, but with degraded accuracy.

  • Page 99: Annunciations & Alerts

    FADEC is in manual operating mode. FLOAT ARM Floats Arm switch is in the armed position. FUEL FILTER External fuel filter is partially blocked before impending bypass. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 100 R/FUEL XFR Right fuel transfer pump has failed. T/R CHIP T/R Chip Detector has detected debris. XMSN CHIP Transmission Chip Detector has detected debris in transmission oil. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 101: Advisory Messages

    SAFE OPERATING ANNUNCIATION Annunciation Text Description FLOAT TEST Float system is in test mode. QUIET MODE ON Engine Quiet Mode is on. Aircraft is on the ground. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 102: Htaws Alerts

    Voice Callout (VCO) None None “Five Hundred” “Four Fifty” “Four Hundred” “Three Fifty” “Three Hundred” “Two Fifty”, “Two Hundred” “One Fifty” “One Hundred” “Fifty” HTAWS Alerts Summary Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 103: Htaws System Status Annunciations

    HTAWS audio fault No GPS position “HTAWS Not NO GPS POSITION Available” “HTAWS Available” when GPS position returns. and HTAWS is not inhibited. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 104: Voice Alerts

    “TAS System Test Played when the GTS 800 TAS system fails a pilot-initiated self test. Failed” “One o’clock” through Intruder bearing (GTS 800 only) “Twelve o’clock” or “No Bearing” Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 105: Mfd & Pfd Message Advisories

    Config service req’d. be serviced. SW MISMATCH – GDU software The MFD and PFD have different software versions version mismatch. Xtalk is off. installed. The system should be serviced. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 106: Database Message Advisories

    Ensure that the terrain card is properly inserted in display. Replace terrain card. If PFD1 DB ERR – PFD1 terrain problem persists, the system should be serviced. database error exists. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 107 The PFD and MFD have different navigation database versions or types (Americas, European, database mismatch. Xtalk is off. etc.) installed. Crossfill is off. Install correct navigation database version or type in all displays. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 108: Gma 350H Message Advisories

    Certain audio functions may still be avail- service. Return unit for repair. able, and the audio panel may still be usable. The system should be serviced when possible. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 109: Gia 63H Message Advisories

    MANIFEST – GIA1 software mismatch, communication halted. The GIA1 and/or GIA 2 has incorrect software installed. The system should be serviced. MANIFEST – GIA2 software mismatch, communication halted. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 110 Abort approach due to loss of GPS navigation. navigation. Abort approach. APR DWNGRADE – Approach Vertical guidance generated by SBAS is downgraded. unavailable, use LNAV only minimums. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 111: Gea 71H Message Advisories

    Config service req’d. G1000H system should be serviced. MANIFEST – GEA1 software The #1 GEA 71 has incorrect software installed. mismatch, communication halted. The G1000H system should be serviced. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 112: Gtx 33H Message Advisories

    AHRS1 SRVC – AHRS1 Magnetic- The #1 AHRS earth magnetic field model is out of date. Update magnetic field model when practical. field model needs update. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 113: Gmu 44 Message Advisories

    A fault has occurred in the #1 GMU 44. Heading is flagged as invalid. The AHRS uses GPS for fault has occurred. backup mode operation. The G1000H system should be serviced. MANIFEST – GMU1 software The GMU 44 has incorrect software installed.

  • Page 114: Gdl 69Ah Message Advisories

    A failure has been detected in the GDL 59H router. router has failed. The system should be serviced. REGISTER GFDS – Data services are The GDL 59H is not registered with Garmin Flight Data Services, or it’s current registration data has inoperative, register w/GFDS. failed authentication.

  • Page 115: Gts 800 Message Advisories

    S address configured or the mode S address does not match both XPDR mode S addresses. MANIFEST – GTS software The GTS has incorrect software installed. The G1000H system should be serviced. mismatch, communication halted. MISCELLANEOUS MESSAGE ADVISORIES Message Comments FPL WPT LOCK –...
  • Page 116 SLCT FREQ – Select appropriate The system notifies the pilot to load the approach frequency for the appropriate NAV receiver. frequency for approach. Select the correct frequency for the approach. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 117 Do not use GPS to navigate to the selected non-WGS84 waypoint. FAILED PATH – A data path has failed. A data path connected to the GDU, or the GIA 63H has failed. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 118 HDG PRESET MODE – Magnetic The magnetometer has detected a magnetic anomoly that could affect heading indications. anomoly detected. HPM is available. Heading Preset Mode may be used. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 119: Flight Plan Import/Export Messages

    The flight plan has been imported, but must be edited within the system before it can be activated for use. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 120 The stored flight plan was not successfully exported to the SD card. The SD card may not have sufficient available memory or the card may have been removed prematurely. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 121: Appendix

    CAS ↑ Moves the cursor up through the displayed messages CAS ↓ Moves the cursor down through the displayed messages 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 122 Inset Map (optional feature) XM LTNG Displays XM lightning information on Inset Map (optional feature) METAR Displays METAR flags on airport symbols shown on the Inset Map (optional) Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 123 Displays rectangular boxes representing the horizontal and vertical flight path of the active flight plan SYN TERR Enables synthetic terrain depiction HRZN HDG Displays compass heading along the Zero-Pitch line 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 124 Enables Heading Preset Mode HDG SYNC Synchronizes heading to the selected heading HDG - Slews heading counterclockwise HDG + Slews heading clockwise HPM OFF Manually disables Heading Preset Mode Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 125 Selects Standby Mode (transponder does not reply to any interrogations) Selects Mode A (transponder replies to interrogations) Selects Mode C – Altitude Reporting Mode (transponder replies to identification and altitude interrogations) 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 126: Mfd Softkey Map

    (optional) (optional) (optional) (optional) TRAFFIC TOPO AIRWAYS NEXRAD XM LTNG BACK METAR LEGEND AIRWY ON AIRWY LO AIRWAY HI MFD Softkeys Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 127 Displays METAR flags on airport symbols shown on the Navigation Map LEGEND Displays the legend for the selected weather products. Available only when NEXRAD, XM LTNG, and/or METAR softkeys are selected. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...

  • Page 128: Loading Updated Databases

    Power interuption during the database loading process could result in main- tenance being required to reboot the system. In some cases it may be necessary to obtain an unlock code from Garmin in order to make the database product functional. It may also be necessary to have the system configured by a Garmin authorized service facility in order to use some database features.
  • Page 129 1) With system power OFF, remove the MFD database card from the bottom card slot of the MFD. 2) Update the Garmin databases on the MFD card. 3) Insert the MFD database card into the bottom card slot of the MFD.
  • Page 130 2) Verify that an SD card is inserted in the bottom slot of each PFD and the MFD. 3) Turn the system ON. A prompt is displayed. Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 131 19) Press the Display Database Selection Softkey to show standby navigation database information for each display (MFD1 DB, PFD1 DB). Verify the correct standby navigation database cycle information is shown for each display. 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 132 Appendix Blank Page Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...

  • Page 133: Index

    Dead Reckoning 81 METAR 45 Declutter 80, 106, 112 Minimums 88 Direct-to 23 Mode S 110 DME 11 Mode selection softkeys 11 DR mode 81, 82 Index-1 190-01254-00 Rev. A Garmin G1000H Cockpit Reference Guide for the Bell 407GX ™...
  • Page 134 Standby frequency field 11 Standby Navigation Database 114 XM lightning 106, 111 Store Flight Plan 38 XM weather 45 SVS 55, 102 Synchronization 113 SYNC Status 115 Index-2 Garmin G1000H Cockpit Reference Guide for the Bell 407GX 190-01254-00 Rev. A ™...
  • Page 136 Liberty House, Bulls Copse Road Hounsdown Business Park Southampton, SO40 9RB, U.K. p: 44/0870.8501241 f: 44/0870.8501251 Garmin Corporation No. 68, Jangshu 2nd Road Shijr, Taipei County, Taiwan p: 886/2.2642.9199 f: 886/2.2642.9099 www.garmin.com 190-01254-00 Rev A © 2011 Garmin Ltd. or its subsidiaries...

Table of Contents
