Lexmark 4227 - Forms Printer B/W Dot-matrix Service Manual page 135

4227-300
Asm- Part
Index number
6 -1 40X3040
2 40X3023
3 40X3024
4 40X2985
5 40X3128
6 40X2928
7 40X3133
8 40X3127
9 40X2927
10 40X3134
11 40X3136
12 40X2891
13 40X2892
14 40X2891
Description
Support, cut sheet with guides
Roller, feed (upper)
Roller, feed (lower)
Roller, pickup (left and right)
Hopper (left)
Support, paper (left)
Support, paper (center)
Hopper (right)
Support, paper (right)
Cover (left)
Gear and bushing kit, ASF
Spring kit, ASF
Screw kit, ASF
Spring
7-13
Parts catalog
